Quick Installation Guide
AC2100 Wireless MU-MIMO
VDSL/ADSL Telephony Modem Router
Archer VR2100v
1
Set up the Modem Router
Phone Jack
2
Connect the DSL splitter to the phone jack.
Note: If you won't use the traditional landline phone service, you
can directly connect the modem router to the phone jack.
DSL Splitter
Power adapter
3
Connect the modem router to
the DSL splitter.
U S
B
W P
S
W LA
N
4
Push in to turn on the
modem router.
5
Wait about 1 minute until the DSL LED
turns solid on.
Note: If the DSL LED is still flashing after one minute
please wait a little longer. If the DSL LED still does
not turn solid on, please refer to Q3 of the FAQ.
2
Connect your analog phones to the Phone ports on the modem router's
back panel. You may connect up to two.
1
Attach the antennas.
e2
on
Ph
e1
on
Ph
DS
L
se t
Re
Modem Router
Connect the Phone
Phone1 or 2
e2
Phon
e1
Phon
DSL
Reset
Advertisement
Related Manuals for TP-Link Archer VR2100v
Summary of Contents for TP-Link Archer VR2100v
- Page 1 Quick Installation Guide Attach the antennas. AC2100 Wireless MU-MIMO VDSL/ADSL Telephony Modem Router Archer VR2100v Set up the Modem Router se t Power adapter W LA Modem Router Push in to turn on the modem router. Wait about 1 minute until the DSL LED turns solid on.
- Page 2 SSID:TP-Link_XXXX SSID:TP-Link_XXXX_5G You can easily manage your network through the TP-Link Tether app. Download and install Launch a web browser and type in http://tplinkmodem.net or 192.168.1.1. the Tether app. Search for Tether on the Apple App Store or Google Play, or simply scan Create a login password and get started.
