TP-Link Archer VR26007 Quick Installation Manual

Quick Installation Guide

AC2600 Wireless Gigabit VDSL/ADSL Modem Router
Connect the Hardware
Configure the Modem Router
Enjoy the Internet
Power Adapter
VR2600
3
7106505864 REV1.0.0
4
1
Connecting your computer to the modem router via a wired or wireless
connection
Wired
Wireless
Connect wirelessly by using the SSID
(network name) and Wireless Password
printed on the product label at the bottom of
the modem router.
Now you can enjoy your Internet.
If you want more advanced settings, please refer to the User Guide on TP-LINK official website at www.tp-link.com.
Modem Router
Push in to turn on
the modem router.
Verify that the following LEDs are on
and stable before continuing with
the configuration.
Power On DSL On
Note: The DSL LED takes about 1 to 2 minutes to stabilize.
Ethernet Cable
2 1
PHONE MODEM
Phone Cable
If you don't need the phone service, just directly connect the
modem router to the phone jack with the provided phone cable,
then follow steps 3 and 4 to complete the hardware connection.
2
Configuring the modem router via a web browser
A Launch a web browser and type in http://tplinkmodem.net or 192.168.1.1.
Create a new password (1-15 characters) and click Save.
Note: If the login page does not appear, please refer to FAQ->Q1.
http://tplinkmodem.net
New Password
Low Middle High
Confirm Password
Save
B Enter the password you set and click Log in.
Note: For subsequent logins, you only need to enter the password that you have set to log in.
C Select your Region and Time Zone, then click Next. Then follow the step-by-step
instructions of the Quick Setup to complete the initial configuration.
Note: Per FCC regulations, all Wi-Fi products marketed in the U.S. must be fixed to the U.S. region only.
Phone Jack
DSL Splitter
Phone (Optional)
