- Page 1 Installation, Operation and Service Manual Bluezone® PK-220 Air Purification System Bluezone Products, Inc. 225 Wildwood Ave, Woburn, MA 01801 ● ● 781-937-0202 www.Bluezonefresh.com support@bluezonefresh.com...
- Page 2 Document #: BPI-PM013-00 Do not operate the Bluezone PK-220 while IMPORTANT SAFEGUARDS fogging with chlorine bleach or other READ AND SAVE THESE INSTRUCTIONS disinfectant solutions. Turn off the Bluezone Units if disinfectant fogging or cleaning is Safety underway. This manual contains important instructions and safety information about the Bluezone Air •...
- Page 3 Specifications The specifications of the Bluezone PK-220 are shown in Table 1. Please note that the 120V and 230V models of the PK-220 are different units and can only be used at the voltage listed on the asset tag. Table 1: Bluezone PK-220 Specifications...
- Page 4 Document #: BPI-PM013-00 Key Components Figure 1: Bluezone PK-220 Key Components...
- Page 5 Document #: BPI-PM013-00 Electrical System A wiring diagram of the PK-220 is shown in Figure 2. Figure 2: Wiring Diagram of the PK-220...
- Page 6 Document #: BPI-PM013-00 For an additional 3 ACH, use one PK-220 Installation Guidelines for every 550 square feet of floor space. The Bluezone PK-220 offers variable installation options with no additional If multiple Bluezone PK-220 units are being cabinetry required. Units can be mounted to...
- Page 7 Document #: BPI-PM013-00 Installation Bluezone PK-220 can be mounted to the floor, mounted to the wall, or installed into a 2’ X 4’ drop ceiling opening. Floor/Wall Mounting: Overview The Bluezone PK-220 unit can be mounted the floor or mounted to a wall with the cleat provided.
- Page 8 All fasteners must be rated for 120lbs or greater. For floor placement, mount the cleat 41 ½” off the floor. The installation of the wall mounting cleat is required to prevent the PK-220 from tipping. Failure to secure the PK-220 with the mounting cleat can result in injury.
- Page 9 For wall mounting, Bluezone recommends mounting the cleat at 46” or greater off the floor for 4” or greater of clearance from the base of the PK-220 to the floor. Provide a minimum distance of 6 in from the top of cleat to the ceiling.
- Page 10 Document #: BPI-PM013-00 Hang the PK-220 mounting bracket on the wall mounting cleat. Adjust the Bluezone PK-220 to center it onto the mounting cleat. Figure 7: Hang the PK-220 Mounting Bracket on the Mounting Cleat...
- Page 11 Document #: BPI-PM013-00 Figure 8: PK-220 Floor Mounted Figure 9: PK-220 Wall Mounted...
- Page 12 Ceiling Mounting: Overview The PK-220 is designed with the option to be installed onto a 2’ X 4’ opening in the grid frame of a standard suspended ceiling with 2’ X 2’ or 2 X 4’ tiles. Only mount the PK-220 to a properly installed and structurally strong suspended ceiling with structural members above the ceiling tiles to attach support wires.
- Page 13 Document #: BPI-PM013-00 Installation into Ceiling Grid 1. Install the four included Z-brackets onto the PK-220 by removing the back most screws of the inlet and outlet mufflers and using them to secure the Z-brackets. Orient the Z-brackets as shown in Figure 10. The Z-brackets are for use with 12-gauge hanger wire.
- Page 14 2. Carefully angle and push assembly through the opening in the ceiling. Figure 11: Insert the PK-220 Sideways and Upwards into the Ceiling Grid 3. Orient the PK-220 with louver openings facing down and rest the frame on the ledge of the ceiling grid.
- Page 15 Document #: BPI-PM013-00 Mechanical Installation A drawing showing nominal dimensions of the PK-220 is provided in Figure 13. Figure 13: Bluezone PK-220 Nominal Dimensions (units in inches)
- Page 16 6’ long, IEC C-13 power cord. Plug the power cord into the power entry module. Once the PK-220 is secured in the space, plug the cord into the nearest electrical outlet rated to the voltage on the unit’s Model Label.
- Page 17 5. Connect the main service to the pig tail in the junction box as shown in Figure 14. Figure 14: Main Service Connections 6. Attach cover (provided) to junction box. 7. Connect the plug end of the IEC power cable provided to the PK-220 power entry module.
- Page 18 High/Low Speed: The Bluezone PK-220 has two fan speeds: high and low. Press the speed control button once to change fan speed. (The same button is used to reset the bulb counter when bulbs are serviced).
- Page 19 Document #: BPI-PM013-00 Figure 15: Display Sequence in Time...
- Page 20 Document #: BPI-PM013-00 Warnings, Fault Conditions and Fault Codes If there are issues with the operation of the PK-220, the Bluezone Logo Status Panel will indicate the nature of the problem. Operation status is indicated by the color of the Logo Status Panel defined in Table 3.
- Page 21 Document #: BPI-PM013-00 Troubleshooting If the Bluezone Logo Status Panel is not Check whether the unit’s circuit illuminated, then the PK-220 is not being powered. Check the following list breaker has tripped. for possible causes and solutions: a. Visually check the circuit breaker on the side of the 1.
- Page 22 Document #: BPI-PM013-00 Cover latch Cover switch Cover switch Figure 16: Bluezone PK-220 Cover Switch and Cover Latch...
- Page 23 Bulbs contain a small amount of mercury Bulb handling should be similar to that used for fluorescent or compact fluorescent bulbs. Bluezone Products, Inc. recommends that you take advantage of available local recycling options for CFLs. Lists of recycling facilities are available at: www.earth911.org.
- Page 24 Document #: BPI-PM013-00 Service BULBS NEED TO BE REPLACED AFTER 8,800 HOURS OF USE. BULB KITS MUST BE PURCHASED DIRECTLY FROM BLUEZONE PRODUCTS OR AN AUTHORIZED PARTNER AS THEY ARE PROPRIETARY BULBS. Bulbs must be replaced at 8,800 hours of Partner.
- Page 25 Document #: BPI-PM013-00 Instructions for Bulb Replacement: Slide the top end of the bulb into the bulb support bracket. See Figure 21. Hold replacement bulbs by the ceramic end and push the pins into Toggle the power switch located on the unit’s control panel to OFF.
- Page 26 Document #: BPI-PM013-00 Figure 17: Remove Service Cover Figure 18: Remove Bulb Clip Screws...
- Page 27 Document #: BPI-PM013-00 Figure 19: Remove Bulbs from Bulb Sockets and Bulb Support Figure 20: Remove Bulb Clips from Bulbs and Save for use with New Bulbs...
- Page 28 Document #: BPI-PM013-00 Figure 21: Slide Bulb with Bulb Clip into the Bulb Support Bracket...
- Page 29 Document #: BPI-PM013-00 Figure 22: Install Bulbs into Sockets Figure 23: Install Service Cover...
- Page 30 Document #: BPI-PM013-00 Instructions to Clean Up Broken UV bulb Items Needed to Clean Up a Small Mercury Spill: • Zip locking plastic bags (4 to 5 as needed) • Trash bags (2 to 6 mils thick) • Rubber, nitrile, or latex gloves •...
- Page 31 Document #: BPI-PM013-00 Technical Support is provided by: Bluezone Products, Inc. 225 Wildwood Ave Woburn, MA 01801 (781) 937-0202 support@bluezonefresh.com...
