- Page 1 Installation, Operation and Service Manual Bluezone® Model 2400 Air Purification System Bluezone Products, Inc. 225 Wildwood Avenue Woburn MA 01801 ● ● 781-937-0202 www.BluezoneFresh.com Support@BluezoneFresh.com...
- Page 2 Document #: BZ2400-0XX Turn off Bluezone units and cover with plastic Safety if the room is being hosed with water or This operation and service manual contains steam. important instructions and safety information about the Bluezone Air Purification System. Do not operate the Bluezone Model 2400...
-
Page 3: Specifications
91cm X 51cm X 51cm in cold storage and large walk-in coolers. Shipping Weight 28 lbs/13 kg The Model 2400 can be hung or mounted to the ceiling or wall, or located on a shelf. 34°F – 104°F Operating Environment 1C –... - Page 4 Document #: BZ2400-045 Key Components...
-
Page 5: Electrical System
Document #: BZ2400-045 Electrical System A wiring diagram of the Model 2400 is show in Figure 1. Figure 1: Wiring Diagram of Model 2400 Unit... -
Page 6: Installation
Installation Guidelines practice. Warning: Hang the units from the Place the Model 2400 in the room so that air ceiling, mount to the wall or on a flow from the HVAC system, fans or other shelf/rack to avoid unintended bumping air flow systems does not blow directly into of the units. -
Page 7: Mechanical Installation
A drawing of the mounting locations on the ceiling or placed on a shelf. A ceiling mount Model 2400 is provided in Figure 2. kit and a shelf mounting kit are available for purchase. Figure 2: Bluezone Model 2400 Mount Dimensions (units in inches) - Page 8 Document #: BZ2400-0XX Figure 3: Illustration of the Ceiling Mount and Shelf Mount...
-
Page 9: Electrical Installation
Document #: BZ2400-0XX Electrical Installation The Bluezone unit is equipped with a 6’ (1.8 permanent location such as an electrical m) power cord. The unit may be hardwired junction box. Ensure that all local safety into an AC junction box or plugged into an regulations are adhered to when installing appropriate AC receptacle. -
Page 10: Normal Operation
Bulb Counter Reset Button Figure 4: Control Panel on Bluezone Unit Once the Model 2400 is mounted and wired, it can be turned ‘On’ using the power switch on the control panel. In the view shown in Figure 4, pressing the switch up is “On”. - Page 11 Document #: BZ2400-0XX Fault Conditions and Fault Codes If there are issues with the operation of the Model 2400, the onboard diagnostics will indicate the nature of the problem. Display Screen codes are shown in Table 3.
- Page 12 Document #: BZ2400-0XX Table 3: Display Screen Status Indicator Fault Codes Display Color Display Text Fault Operation Action to Take Bluezone M2400 Green System operating Unit conditions Operates None Background properly. scrolling Freezing Unit is off and will Bluezone M2400...
- Page 13 Power “Off” unit by pressing the power switch located on The Bluezone will not turn on if the cover switch is not engaged. Make sure the cover switch is inside the cover switch opening. Danger DO NOT activate the cover switch without the cover on. UV light will be emitted.
- Page 14 Document #: BZ2400-0XX Cover switch Cover switch hole Figure 5: Bluezone Cover Switch and Cover Switch Hole...
-
Page 15: New Equipment Warranty
Bulbs contain a small amount of mercury Bulb handling should be similar to that used for fluorescent or compact fluorescent bulbs. Bluezone Products, Inc. recommends that you take advantage of available local recycling options for CFLs. Lists of recycling facilities are available at: www.earth911.org. - Page 16 Document #: BZ2400-0XX Service BULBS NEED TO BE REPLACED AFTER 8,000 HOURS OF USE. BULB KITS MUST BE PURCHASED DIRECTLY FROM BLUEZONE PRODUCTS AS THEY ARE PROPRIETARY BULBS. Bulbs must be replaced at 8,000 hours of Please call (781) 937-0202 or email operation.
- Page 17 Put Bulb Clips over new bulbs and use screws to tighten Bulb Clips in Wait 15 minutes for the ozone to place. clear from the Bluezone reaction Thread Bulb Support Wires through zone. bulbs and use screws to tighten Bulb Support Wires in place.
- Page 18 Document #: BZ2400-045 Figure 6: Unscrew 14 Screws on Bluezone M2400 Cover Bulb Support Wires to be removed 5/16 screws to be removed Figure 7: Remove 5/16 Screws Holding Bulb Support Wires...
- Page 19 Document #: BZ2400-0XX Figure 8: Remove Bulb Support Wires and Place Aside 5/16 screws to remove Figure 9: Remove 5/16 Screws on Bulb Support Clips...
- Page 20 Document #: BZ2400-0XX Figure 10: Carefully Slide off Bulb Clips using Nitrile Gloves...
- Page 21 Document #: BZ2400-0XX Figure 11: Completed Bulb Assembly Figure 12: Bulb counter reset button...
- Page 22 Document #: BZ2400-0XX Appendix A: Bluezone Unistrut Channel Mount Installation Bluezone Shelf Mount Installation...
- Page 23 Document #: BZ2400-0XX Bluezone Unistrut® Channel Mount Installation The Bluezone Model 2400 can be mounted to the ceiling using existing your facility’s existing Unistrut® metal framing system, and the Bluezone Mounting Kit as shown below. EXISTING UNISTRUT IN FACILITY MOUNTING KIT...
- Page 24 Steel mounting plate, 12 AWG, 18” x 18” with rivet nuts installed Threaded rod ½” – 2-foot standard size, custom lengths available Strut channel nut with spring, ½” Washer ,½” Hex head screw, ½” Split lock washer, ½” Hex nuts, ½” Not included in kit... • Unistrut channel • Bluezone unit...
- Page 25 Document #: BZ2400-0XX Instructions 1. Insert 2 channel nuts 12” apart in Unistrut® channel. Please note Unistrut channel is existing in client facility. 2. Attach mounting plate to Unistrut channel by inserting hex screws with washer and lock washer into channel nuts.
- Page 26 Document #: BZ2400-0XX 3. Insert (4) threaded rods into rivet nuts. Threaded rods should hang Bluezone at the level of the grow lights. Ensure all threaded rods are completely inserted. Custom lengths available...
- Page 27 4. Attach ½” hex nuts onto all threaded rods, ~1” up threaded rod. 5. Secure Bluezone to threaded rods using lock washer, washer and hex nut. This step requires two workers… one to hold the Bluezone and one to attach hardware.
- Page 28 Document #: BZ2400-0XX Figure 12: Completed Assembly...
-
Page 29: Shelf Mount
Document #: BZ2400-0XX Shelf Mount Materials Included in kit… • Wall mount shelf • Mounting brackets • Installation screws and anchors... - Page 30 Document #: BZ2400-0XX...
- Page 31 Document #: BZ2400-0XX Vendor Contact Information: Technical Support is provided by: Bluezone Products, Inc. 225 Wildwood Ave Woburn, MA 01801 (781) 937-0202 support@bluezonefresh.com...
