Page 1: Digital Camera
Digital Camera User’s Guide Thank you for purchasing this CASIO product. • Before using it, be sure to read the precautions contained in this User’s Guide. • Keep the User’s Guide in a safe place for future reference. • For the most up-to-date information about this product, visit the official EXILIM...
Page 2: Unpacking
Unpacking As you unpack your camera, check to make sure that all items shown below are included. If anything is missing, contact your original retailer. Digital camera * The shape of the power cord plug varies according to country or geographic area.
Page 3: Read This First
CASIO COMPUTER CO., LTD. is forbidden under copyright laws. • CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost profits suffered by you or any third party due to the use or malfunction of this product.
Page 4: Table Of Contents
What is a digital camera? ........14 What you can do with your CASIO camera ......15 First, charge the battery prior to use..
Page 5 Continuous Shutter Precautions ........58 Recording Movies To record a movie .
Page 6 Shooting with Quick Shutter ......(Quick Shutter) . . 102 Displaying the On-screen Grid ......(Grid) . . 102 Turning on Image Review .
Page 7 Printing Printing Snapshots..........133 Connecting Directly to a PictBridge Compatible Printer .
Page 8 Formatting Built-in Memory or a Memory Card ....(Format) . 170 Resetting the Camera to Factory Defaults ....(Reset) . 170 Configuring Monitor Screen Settings Turning Display Information On and Off .
Page 9: General Guide
General Guide The numbers in parentheses indicate the pages where each item is explained. . Camera Front 1 2 3 4 Mode dial (pages 25, 33) Zoom controller (pages 25, 46, 114) Shutter button (page 25) Flash (page 44) Microphones (page 60) Front lamp (pages 94, 98) Lens...
Page 10: Charger Unit
Bottom Charger Unit Battery/memory card slots (pages 17, 21, 181, 182) Speaker Tripod hole Use this hole when attaching to a tripod. Contacts [CHARGE] Lamp AC jack...
Page 11: Monitor Screen Contents
Monitor Screen Contents The monitor screen uses various indicators, icons, and values to keep you informed of the camera’s status. • The sample screens in this section are intended to show you the locations of all the indicators and figures that can appear on the monitor screen in various modes. They do not represent screens that actually appear on the camera.
Page 12: Movie Recording
. Movie Recording . Snapshot Viewing Recording mode (page 59) Audio recording disabled (page 62) Remaining movie memory capacity (page 59) Movie recording time (page 59) Movie recording in progress (page 59) Movie quality (HD/STD movie) (pages 59, 62)/ Recording speed (high speed movie) (page 62) File type Protect indicator (page 128) Snapshot image size (page 36)
Page 13: Movie Playback
. Movie Playback 1 3 4 . CS Image Viewing No audio data available File type Protect indicator (page 128) Folder name/file name (page 158) Movie recording time (page 108) Movie quality/speed (pages 59, 62, 62) YouTube (page 66) Date/time (page 165) Battery level indicator (page 18) Current image number/number of images in the group (page 109)
Page 14: Quick Start Basics
Quick Start Basics What is a digital camera? A digital camera stores images on a memory card, so you can record and delete them a countless number of times. Record Delete Play You can use the images you record in a variety of different ways.
Page 15: What You Can Do With Your Casio Camera
What you can do with your CASIO camera Your CASIO camera is packed with a powerful selection of features and functions to make recording of digital images easier, including the following three main functions. High Speed CS/Prerecord CS Now you can shoot up to 30 continuous high- resolution images at the amazing speed of 40 images per second (maximum).
Page 16: First, Charge The Battery Prior To Use
Note that the battery of a newly purchased camera is not charged. Perform the steps under “To charge the battery” to bring the battery to a full charge. • Your camera requires a special CASIO rechargeable lithium ion battery (NP-90) for power. Never try to use any other type of battery.
Page 17: To Load The Battery
Other Charging Precautions • Use the special charger (BC-90L) to charge the special lithium ion battery (NP-90). Never use any other type of charger device. Attempting to use a different charger can result in unexpected accident. • A battery that is still warm due to normal use may not charge fully. Give the battery time to cool before charging it.
Page 18 Close the battery cover. Close the battery cover and then shift the slider towards LOCK. • For information about how to replace the battery, see page 181. Checking Remaining Battery Power As battery power is consumed, a battery indicator on the monitor screen indicates remaining power as shown below.
Page 19: Configuring Basic Settings The First Time You Turn On The Camera
Configuring Basic Settings the First Time You Turn On the Camera The first time you load a battery into the camera, a screen appears for configuring the display language, date, and time settings. Failure to set the date and time correctly will cause the wrong date and time data to be recorded with images.
Page 20: Preparing A Memory Card
Ultra High Speed Type SD memory card is recommended. Note, however that CASIO makes no guarantees about the operation of any Ultra High Speed Type SD memory card used with this camera.
Page 21: To Load A Memory Card
• Never insert anything besides a supported memory card (page 20) into the memory card slot. • Should water or any foreign object ever get into the card slot, immediately turn off the camera, remove the battery, and contact your retailer or nearest CASIO authorized service center. Front...
Page 22: To Format (Initialize) A New Memory Card
To format (initialize) a new memory card You need to format a new memory card before using it for the first time. Turn on the camera and press [MENU]. On the “Set Up” tab, select “Format” and then press [6]. Use [8] and [2] to select “Format”...
Page 23: Turning The Camera On And Off
Turning the Camera On and Off To turn power on To enter the REC mode, press [ON/OFF] (Power) or [r] (REC). To enter the PLAY mode, press [p] (PLAY). The back lamp will light (green) momentarily and the camera will turn on. If you are entering the REC mode, the lens will extend from the camera at this time.
Page 24: Holding The Camera Correctly
Holding the Camera Correctly Your images will not come out clearly if you move the camera when you press the shutter button. When pressing the shutter button, be sure to hold the camera as shown in the illustration, and keep it still by pressing your arms firmly against your sides as you shoot.
Page 25: To Shoot A Snapshot
IMPORTANT! • Take care to ensure that your fingers are not blocking or are not too close to the flash. Fingers can cause unwanted shadows when using the flash. To shoot a snapshot The following procedure describes how to shoot a single snapshot. For information about shooting a series of shots (Continuous Shutter), see page 49.
Page 26 Half-press the shutter button to focus the image. When focus is complete, the camera will beep, the back lamp will light green, and the focus frame will turn green. • If the current aperture, shutter speed, ISO sensitivity, or Auto Exposure is not correct, the setting will turn orange when you half-press the shutter button.
Page 27 Recording a Movie Press [0] (Movie) to start movie recording. Press [0] (Movie) again to stop movie recording. See the following pages for details. Standard movie (STD movie): page 59 High-definition movie (HD movie): page 62 High speed movie (HS movie): page 62 .
Page 28: Viewing Snapshots
Viewing Snapshots Use the following procedure to view snapshots on the camera’s monitor screen. • For information about how to play back movies, see page 108. • For information about images recorded using continuous shutter (CS), see page 109. Press [p] (PLAY) to enter the PLAY mode.
Page 29: Deleting Images
Deleting Images If memory becomes full, you can delete images you no longer need in order to free up storage and record more images. IMPORTANT! • Remember that a file (image) delete operation cannot be undone. • For information about images recorded using continuous shutter (CS), see page 110.
Page 30: To Delete Specific Files
To delete specific files Press [p] (PLAY) to enter the PLAY mode and then press [2] ( Use [ ] and [2] to select “Delete Files” and then press [SET]. • This displays a file selection screen. Use [ ], [2], [4], and [6] to move the selection boundary to the file you want to delete, and then press [SET].
Page 31: Snapshot Shooting Precautions
Snapshot Shooting Precautions Operation • Never open the battery cover while the back lamp is flashing green. Doing so can result in the image you just shot being saved incorrectly, damage to other images stored in memory, malfunction of the camera, etc. •...
Page 32: Auto Focus Restrictions
Auto Focus Restrictions • Any of the following can make proper focus impossible. – Solid color wall or other very low contrast subject – Strongly back lit subject – Very shiny subject – Blinds or other subject with a repeating horizontal pattern –...
Page 33: Snapshot Tutorial
Snapshot Tutorial Selecting the Exposure Mode Your camera has a variety of different exposure modes. Before recording an image, rotate the mode dial to select the exposure mode that suits the type of image you are trying to record. BEST SHOT Simply select one of a collection of built-in sample scenes and the camera sets up automatically for beautiful images every time (page 68).
Page 34 IMPORTANT! • The aperture and shutter speed setting control panels both have two-level displays. The upper level value is for snapshots, while the lower value is for movies. • You may not be able to achieve the brightness you want when shooting an image that is very dark or very bright.
Page 35: Using The Control Panel
Using the Control Panel The control panel can be used to configure camera settings. In the REC mode, press [SET]. Use [8] and [2] to select the setting you want to change. This will select one of the control panel icons and display its settings.* Image size/Quality* ISO sensitivity (page 41) White balance (page 42)
Page 36: Changing The Image Size
Changing the Image Size (Size) . Pixels A digital camera image is a collection of small dots called “pixels”. The more pixels there are in an image, the more detail there will be. However, you generally can do with fewer...
Page 37 Image Size Selection Tips Note that larger images have more pixels, so they take up more memory space. More detail, but takes up more memory. Best Large Number when you plan to print large-size prints (such of Pixels as A3 size). Small Number Less detail, but takes up less memory.
Page 38 Suggested Print Image Size Size and (Pixels) Application RAW+JPEG (Select when you RAW+ want to process image data yourself.) Poster Print (3648 2736) Poster Print (3648 2432) 16:9 HDTV (3648 2048) A3 Print (3456 2592) A3 Print (3072 2304) A4 Print (2304 1728) 3.5"...
Page 39 • The initial factory default image size setting is 10M (10 million pixels). • Selecting “3:2” records images with an aspect ratio of 3:2, which matches the standard aspect ratio of print paper. • The letters “HDTV” stand for “High Definition Television”. An HDTV screen has an aspect ratio of 16:9, which makes them wider than the usual 4:3 aspect ratio of television screens of the past.
Page 40 This image size can be selected only in the High Speed CS mode or when using some BEST SHOT scenes*. Switching to another mode from the High Speed CS mode or selecting some BEST SHOT scenes* while “9M” is selected will cause the image size setting to change to “10M”...
Page 41: Specifying Iso Sensitivity
Specifying ISO Sensitivity (ISO) ISO sensitivity is a measure of sensitivity to light. In the REC mode, press [SET]. Use [8] and [2] to select the second control panel option from the top (ISO Sensitivity). Use [4] and [6] to select the setting you want and then press [SET]. AUTO Adjusts sensitivity automatically according to conditions Lower...
Page 42: Adjusting White Balance
Adjusting White Balance (White Balance) You can adjust white balance to match the source of light available where you are shooting and avoid the blue cast that results when shooting outdoors when it is cloudy, and the green cast that results when shooting under fluorescent lighting. In the REC mode, press [SET].
Page 43: Correcting Image Brightness
• When “‡ Auto WB” is selected for the white balance setting, the camera automatically determines the white point of the subject. Certain subject colors and light source conditions can cause problems when the camera tries to determine the white point, which makes proper white balance adjustment impossible.
Page 44: Using Flash
Using Flash (Flash) In the REC mode, press [2] ( once. Use [4] and [6] to select the flash setting you want and then press [SET]. Auto Flash > Flash Off Flash On < Red Eye ¥ Reduction Press the shutter button to shoot. Back lamp Flashes red while the flash is charging to indicate that image recording is disabled.
Page 45 NOTE • Take care so your fingers and the strap do not block the flash. • The desired effect may not be obtained when the subject is too far away or too close. • Flash charging time (page 199) depends on operating conditions (battery condition, ambient temperature, etc.).
Page 46: Changing The Control Panel Date/Time Style
Changing the Control Panel Date/Time Style In the REC mode, press [SET]. Use [8] and [2] to select the bottom control panel option (Date/Time). You can use [4] and [6] to select date or time display. NOTE • You can select either of two display styles (page 165) for the date: Month/Day or Day/Month.
Page 47: Optical Zoom/Digital Zoom Switch Point
NOTE • The higher the digital zoom factor, the coarser the recorded image. Note that the camera also has a function that lets you record using digital zoom without image deterioration (page 48). • Use of a tripod is recommended to protect against image blur due to camera movement when shooting with telephoto.
Page 48 Undeteriorated digital zoom Undeteriorated image quality range Optical/digital zoom switch point 10X optical zoom point • An image deterioration icon (Ù) will appear on the monitor screen at the point where image deterioration starts. • The deterioration point depends on the current image size setting (page 36).
Page 49: Using Continuous Shutter
Using Continuous Shutter Pressing Õ (Continuous Shutter) toggles between the Continuous Shutter mode and the Single Shot mode (page 25). Using Normal-speed Continuous Shutter The number of consecutive images you can shoot is theoretically unlimited, as long as there is memory available to store them. Also note that the maximum shooting speed of Normal Speed CS is limited by the type of memory card you are using and the camera setup.
Page 50 IMPORTANT! • For Normal Speed CS, adjustment of exposure, white balance, and Auto Focus is performed for each CS image when the camera is configured with settings shown below. Auto, A (Aperture Priority) mode, S (Shutter Speed Priority) Exposure Mode mode White Balance Auto WB...
Page 51: Using High Speed Cs And Prerecord Cs
Using High Speed CS and Prerecord CS With High Speed CS, you can configure the camera to shoot at a speed of 1, 3, 5, 7, 10, 15, 30, or 40 images per second, as long as you keep the shutter button and there is memory available to store the images.
Page 52 Set the mode dial to t (Auto). In the REC mode, press [MENU]. Use [4] and [6] to select the “REC” tab. Use [8] and [2] to select “CS” and then press [6]. Use [8] and [2] to select “High Speed CS”, and then press [SET]. Press Õ...
Page 53 Use [4] and [6] to specify how many of the 30 images and for how long images should be pre-recorded in the buffer. • Prerecord CS shooting is not performed when the number of buffer images and the recording time are both zero. Number of pre-record images and pre-record time (Not displayed when...
Page 54 NOTE • Note the following when selecting a High Speed CS speed (fps) setting. – Use a higher High Speed CS speed (fps) setting when shooting a fast-moving subject. – Use a slower High Speed CS speed (fps) setting when shooting a slower-moving subject.
Page 55: High Speed Cs Shooting Using The Mechanical Shutter Only
High Speed CS Shooting Using the Mechanical Shutter Only (F CS) Due to the characteristics of the CMOS imaging element, shooting fast-moving subjects with High Speed CS may cause the subject to become distorted. If this happens, try shooting with F CS (Full pixels Continuous Shutter), which uses the mechanical shutter only and eliminates the problems caused by the CMOS imaging element characteristics.
Page 56: Specifying The Method For Saving Continuous Shutter Images
Use [4] and [6] to select the maximum number of shots for each continuous shutter operation and then press [SET]. Press the shutter button the rest of the way down. Images continue to be shot as long as you keep the shutter button depressed. Image recording will stop when you release the shutter button or after the maximum number of shots is reached.
Page 57 Select & Save After continuous shutter shooting is finished, the shot images are played back at slow speed so you can select the images you want to save. • When shooting with Prerecord CS, the first image saved when you press the shutter all the way is indicated by an “S”...
Page 58: Continuous Shutter Precautions
Continuous Shutter Precautions • You can use the Manual Mode while a continuous shutter mode (High Speed CS, Normal Speed CS, F CS) is selected. To do so, set the mode dial to “A”, “S”, or “M”. • If there is not enough available capacity on the memory card, you may not be able to record the number of CS images indicated on the monitor screen.
Page 59: Recording Movies
Recording Movies To record a movie The following procedure explains how to record a standard (STD) movie. See the pages indicated below for more information about movies. High-definition movie (HD movie): page 62 High speed movie (HS movie): page 62 Set the mode dial to t (Auto).
Page 60: Audio
In order to avoid problems such as these, use of an Ultra High Speed Type SD memory card is recommended. Note, however that CASIO makes no guarantees about the operation of any Ultra High Speed Type SD memory card used with this camera.
Page 61 NOTE • Only digital zoom is enabled during HD or STD movie recording. Zoom is disabled during high speed movie recording. To use optical zoom for HD movie, STD movie, or high speed movie recording, perform the zoom operation before you press [0] to start recording.
Page 62: Recording A High-Definition Movie
Recording a High-definition Movie This camera supports recording of high-definition (HD) movies. The aspect ratio of an HD movie is 16:9, the image size is 1280 Image quality and image size settings cannot be changed. Set the mode dial to t (Auto). In the REC mode, set the movie mode switch to ³...
Page 63 Use [8] and [2] to select “HS » Speed” and then press [6]. Use [8] and [2] to select the frame rate (recording speed) you want and then press [SET]. A fast frame rate (such as 1000 fps) will result in a smaller image size. Frame Rate 120 fps 240 fps...
Page 64: Using Prerecord Movie
Using Prerecord Movie (Prerecord (Movie)) With this feature, the camera pre-records up to five seconds of whatever is happening in front of the lens in a buffer that is continually updated. Pressing [0] saves the pre-recorded action (buffer contents) followed by real-time recording. Real-time recording continues until you stop it.
Page 65 . To shoot a Prerecord Movie After using the above procedure to set up the camera for Prerecord Movie, point the camera at the subject. When you are ready to record, press [0]. This will save the approximately five seconds of action that was prerecorded in the buffer before you pressed [0] (two seconds if you are using high speed movie) and start real-time recording.
Page 66: Recording A Movie For Youtube
Record the movie. The movie file will be stored in a camera folder named “100YOUTB”. • Installing YouTube Uploader for CASIO from the CD-ROM that comes with your camera simplifies uploading of movie files you recorded with the “For YouTube” scene to YouTube (page 148).
Page 67: Shooting A Snapshot While Shooting A Movie
Shooting a Snapshot while Shooting a Movie While a movie is being recorded, press the shutter button. Movie recording continues after the snapshot is recorded. NOTE • You can shoot up to 10 snapshots per movie. The number of snapshots is also limited by the amount of free space available on the memory card.
Page 68: Using Best Shot
Using BEST SHOT What is BEST SHOT? BEST SHOT provides you with a collection of sample “scenes” that show a variety of different types of shooting conditions. When you need to change the setup of the camera, simply find the scene that matches what you are trying to achieve, and the camera sets up for it automatically.
Page 69 Press [SET] to configure the camera with the settings for the currently selected scene. This returns to the REC mode. • The settings of the scene you selected remain in effect until you select a different scene. • To select a different BEST SHOT scene, repeat the above procedure from step 2.
Page 70 . BEST SHOT Precautions • BEST SHOT scene images were not shot using this camera. • Images shot using a BEST SHOT scene may not produce the results you expected due to shooting conditions and other factors. • You can modify the camera settings that are configured after you select a BEST SHOT scene.
Page 71: Creating Your Own Best Shot Setups
Creating Your Own BEST SHOT Setups You can save up to 999 camera setups as user BEST SHOT scenes for instant recall whenever you need them. On the BEST SHOT scene menu, select the scene named BEST SHOT (Register User Scene). Use [4] and [6] to select the snapshot whose setup you want to save.
Page 72: Shooting With High Speed Night Scene
Shooting with High Speed Night Scene (High Speed Night Scene/High Speed Night Scene and Portrait) With High Speed Night Scene and High Speed Night Scene and Portrait, the camera detects automatically whether it is being hand-held or on a tripod. If the camera detects it is being hand-held, pressing the shutter button will record a series of images and combine them in a way that minimizes image blur due to low light conditions.
Page 73 NOTE • When holding the camera by hand while shooting with these BEST SHOT scenes, make sure that the subjects remain as still as possible as the camera shoots the series of images. • Even when holding the camera by hand while shooting with “High Speed Night Scene and Portrait”, under certain conditions the camera may shoot only a single image instead of a series of images.
Page 74: Shooting With High Speed Anti Shake
Shooting with High Speed Anti Shake (High Speed Anti Shake) When you press the shutter button while High Speed Anti Shake is enabled, the camera records multiple images and automatically combines them in a way that produces a final image with minimal blur. You can shoot with this feature to minimize the effects of camera movement when shooting with optical anti shake does not produce the desired results.
Page 75: Digitally Correcting For Overexposure And Underexposure
Digitally Correcting for Overexposure and Underexposure (High Speed Lighting) This BEST SHOT scene shoots a series of CS images using different exposure settings and combines them into a final image to correct for overexposure or underexposure of subjects of differing brightness. In the REC mode, set the mode dial to b.
Page 76: Monitor Screen
Configuring the Camera to Help You Better Time Your Shots (Lag Correction) There always is some unavoidable time lag between the point you press the shutter button and the point that the image is actually recorded. The “Lag Correction” feature lets you configure the camera to lessen or even eliminate this lag to help you better time your shots and get exactly the moment you want.
Page 77 Use [4] and [6] to scroll through the pre-recorded images on the monitor screen. Use [4] and [6] to scroll through the pre-recorded images. Each image appears, along with an indication of the timing when it was pre-recorded. –0.4 sec. –0.3 sec.
Page 78: Isolating Moving Subjects
Isolating Moving Subjects (Multi-motion image) Multi-motion image can be used to isolate a moving subject within a series of multiple images and place them against a stationary background. Use a tripod or some other means to make sure that the camera is not moving or shaking when shooting with Multi-motion image.
Page 79 NOTE • With this BEST SHOT scene, the flash setting automatically becomes ? (Flash Off). • Shooting with this BEST SHOT scene makes the shooting range narrower than normal. • The Self-timer cannot be used with this BEST SHOT scene. •...
Page 80: Shooting With Priority On Subject Faces
Shooting with Priority on Subject Faces (High Speed Best Selection) With High Speed Best Selection, the camera automatically shoots a series of images, and selects the best one based on facial image blur, and facial expression (whether the subject is smiling or blinking). In the REC mode, set the mode dial to b.
Page 81: Shooting An Image In Accordance With Subject Movement
Shooting an Image in Accordance with Subject Movement (Move Out CS/Move In CS) You can use these features to shoot an image automatically whenever the subject moves into or moves out of a frame on the monitor screen. You also can configure the camera to record images of what happened immediately before and after the subject moves.
Page 82 Use [4] and [6] to select the continuous shutter (CS) speed you want and then press [SET]. The camera measures light levels and configures the fastest AUTO possible CS speed setting automatically. Enables specification of the number of CS images recorded per 1 to 40 fps second.
Page 83 Use [4] and [6] to select the subject movement sensitivity, and then press [SET]. • You can select any one of three sensitivity levels: “High”, “Normal”, or “Low”. • Move Out CS Setting Guide High : For a subject that moves out of the boundary quickly Low : For a subject that moves out of the boundary slowly •...
Page 84 Image recording will continue until the end of the recording time is reached. • While the camera is in Move Out CS recording standby, you can cancel standby by pressing the shutter button all the way down. You then will be able to shoot images normally.
Page 85 Save the CS images (page 56). NOTE • With this BEST SHOT scene, the flash setting automatically becomes ? (Flash Off). • Shooting with this BEST SHOT scene makes the shooting range narrower than normal. • The Self-timer cannot be used with this BEST SHOT scene. •...
Page 86: Using The Situation-Specific Cs Scenes
Using the Situation-specific CS Scenes The High Speed CS capabilities provide you with a variety of BEST SHOT options to suite exactly the type of image you are trying to record. Images continue to be shot as long as you keep the shutter button depressed, with the shooting speed optimized according to the BEST SHOT scene you are using.
Page 87 Half-press and hold the shutter button to start pre-recording of images. A preset number of images are pre-recorded. The pre-recorded images are continually updated until you full-press the shutter button. • If you release the half-pressed shutter button before pressing it the rest of the way down, all of the pre-recorded images currently in the buffer will be deleted.
Page 88: Using The Situation-Specific High Speed Movie Scenes
Using the Situation-specific High Speed Movie Scenes The High Speed Movie capabilities of the camera provide you with a variety of BEST SHOT options to suite exactly the type of image you are trying to record. In the REC mode, set the mode dial to b. Press [SET].
Page 89: Advanced Settings
Advanced Settings The following are menu operations you can use to configure various camera settings. Using On-screen Menus . Example Menu Screen Operation In the REC mode, press [MENU]. This will display the menu screen. • Menu contents are different in the REC mode and PLAY mode.
Page 90 . Menu Operations in This Manual Menu operations are represented in this manual as shown below. The following operation is the same as the one described under “Example Menu Screen Operation” on page 89. Procedure [r] (REC) * [MENU] * REC Tab * Self-timer Press [r] (REC).
Page 91: Rec Mode Settings
REC Mode Settings (REC) Selecting a Focus Mode (Focus) Procedure [r] (REC) * [MENU] * REC Tab * Focus Settings Type of Shot Q Auto General Focus recording ´ Close ups Macro Scenery and other distant Infinity subjects When you want Manual to focus Focus...
Page 92 To focus with manual focus On the monitor screen, compose the image so the subject you want to focus on is within the yellow boundary. Watching the image on the monitor screen use [4] and [6] to adjust focus. • At this time the image that is within the boundary will enlarge and fill the monitor screen, which aids in focusing.
Page 93 Using Focus Lock “Focus lock” is a technique you can use when you want to compose an image in which the subject you want to focus on is not within the focus frame in the center of the screen. • To use focus lock, select “U Spot” or “O Tracking” for the Auto Focus area (page 96).
Page 94: Using The Self-Timer
Using the Self-timer (Self-timer) Procedure [r] (REC) *[MENU] * REC Tab * Self-timer With the Self-timer, pressing the shutter button starts a timer. The shutter is released and the image is shot after a fixed amount of time. 10 sec 10-second Self-timer „...
Page 95: Reducing The Effects Of Camera And Subject Movement
Reducing the Effects of Camera and Subject Movement (Anti Shake) Procedure [r] (REC) * [MENU] * REC Tab * Anti Shake You can turn on the camera’s Anti Shake feature to reduce image blur due to subject movement or camera movement when shooting a moving subject using telephoto, when shooting a fast-moving subject, or when shooting under dim lighting conditions.
Page 96: Specifying The Auto Focus Area
Specifying the Auto Focus Area (AF Area) Procedure [r] (REC) * [MENU] * REC Tab * AF Area You can use the following procedure to change the Auto Focus metering area for shooting snapshots. • When recording movies, the AF metering area is always “ U Spot”. This mode takes readings of a small area in the center of the image.
Page 97 “ U Spot” or “ O Tracking” Focus frame “— Free” Focus point • “ O Tracking” cannot be used in combination with the following features. Prerecord CS, Normal Speed CS, some BEST SHOT scenes (Move Out CS, Move In CS, Multi-motion Image, Lag Correction, Expression CS, Baby CS, Child CS, Pet CS, Sports CS) •...
Page 98: Using The Auto Focus Assist Light
Using the Auto Focus Assist Light (AF Assist Light) Procedure [r] (REC) * [MENU] * REC Tab * AF Assist Light Half-pressing the shutter button while this setting is selected causes the front lamp to light, which provides illumination for focusing in areas where lighting is dim.
Page 99: Shooting With Continuous Auto Focus
Tips for Best Face Detection Results • The camera performs center focus if it cannot detect a face. • Always make sure that Auto Focus (AF) is selected as the focus mode when shooting with face detection. • Detection of the following types of faces is not supported. –...
Page 100: Changing The Continuous Shutter Mode
Changing the Continuous Shutter Mode (CS) Procedure [r] (REC) * [MENU] * REC Tab * CS Perform the following steps to change the continuous shutter mode. High Speed CS Š Enables shooting of up to 30 continuous shutter images at faster speeds than Normal Speed CS.
Page 101: Turning Digital Zoom On Or Off
Turning Digital Zoom On or Off (Digital Zoom) Procedure [r] (REC) * [MENU] * REC Tab * Digital Zoom Select “On” when you want to use digital zoom (page 47). • Digital zoom is disabled while shooting with the following feature. –...
Page 102: Shooting With Quick Shutter
Shooting with Quick Shutter (Quick Shutter) Procedure [r] (REC) * [MENU] * REC Tab * Quick Shutter When Quick Shutter is turned on, you can press the shutter button all the way without waiting for Auto Focus. This will record the image using a high speed focus operation that is much faster than Auto Focus.
Page 103: Turning On Image Review
Turning on Image Review (Review) Procedure [r] (REC) * [MENU] * REC Tab * Review While Review is turned on, the camera will display a image for about one second immediately after you press the shutter button to record it. •...
Page 104: Configuring Power On Default Settings
Configuring Power On Default Settings (Memory) Procedure [r] (REC) * [MENU] * REC Tab * Memory This setting lets you specify which camera settings should be remembered by the camera when it is turned off, and restored the next time the camera is turned on. To have the camera remember a setting, you should enable the setting’s memory.
Page 105: Image Quality Settings
Image Quality Settings (Quality) Specifying Snapshot Image Quality (T Quality (Snapshot)) Procedure [r] (REC) * [MENU] * Quality Tab * T Quality (Snapshot) Fine Gives image quality priority Normal Normal Economy Gives the number of images priority • The “Fine” setting helps to bring out details when shooting dense tree branches or leaves, a complex pattern, etc.
Page 106: Setting The High Speed Movie Frame Rate
Setting the High Speed Movie Frame Rate (HS » Speed) Procedure [r] (REC) * [MENU] * Quality Tab * HS » Speed See page 62 for details. Specifying the Metering Mode (Metering) Procedure [r] (REC) * [MENU] * Quality Tab * Metering The metering mode determines what part of the subject is metered for exposure.
Page 107: Specifying Flash Intensity
Specifying Flash Intensity (Flash Intensity) Procedure [r] (REC) * [MENU] * Quality Tab * Flash Intensity You can specify flash intensity to one of five levels from +2 (brightest flash) to –2 (least bright flash). • Flash intensity may not change when the subject is too far away or too close. Using Built-in Color Filters (Color Filter) Procedure [r] (REC) * [MENU] * Quality Tab * Color Filter...
Page 108: Viewing Snapshots And Movies
Viewing Snapshots and Movies Viewing Snapshots See page 28 for the procedure for viewing snapshots. Viewing a Movie Press [p] (PLAY) and then use [4] and [6] to display the movie you want to view. Press [SET] to start playback. Movie Playback Controls [4] [6] (Playback in progress.) Fast forward/fast...
Page 109: Viewing Continuous Shutter Images
Viewing Continuous Shutter Images Each time you perform a continuous shutter (CS) operation, the camera creates a CS group that includes all of the images for that particular CS session. You can use the following procedure to play back the images in a particular CS group. Press [p] (PLAY) and then use [4] and [6] to display the CS group whose images you want to view.
Page 110: Deleting Continuous Shutter Images
The following are operations that are supported after you press [SET] to start image playback. During playback, changes the playback direction and playback speed. While playback is paused, scrolls forward or back. [4] [6] • Playback speed cannot be adjusted while the displayed image is zoomed.
Page 111 Use [4] and [6] to display the image you want to delete. Use [8] and [2] to select “Delete” and then press [SET]. • To delete other files, repeat steps 3 and 4. • To exit the delete operation, press [MENU]. .
Page 112: Dividing Up A Cs Group
. Deleting All Files in a CS Group While CS image playback is in progress or paused (toggle by pressing [SET]), press [2]. This will display the “CS Frame Edit” menu. Use [8] and [2] to select “Delete” and then press [SET]. Use [8] and [2] to select “Del Group Images”...
Page 113: Copying A Cs Group Image
. Dividing Up All CS Groups IMPORTANT! • Once a CS group is divided, it cannot be regrouped. While a CS group is displayed or while the images of a CS group are scrolling on the monitor screen, press [MENU]. Use [4] and [6] to select the “PLAY”...
Page 114: Zooming An On-Screen Image
Zooming an On-screen Image In the PLAY mode, use [4] and [6] to scroll through the images until the one you want is displayed. Slide the zoom controller towards z ([) to zoom. You can use [8], [2], [4], and [6] to scroll the zoomed image on the monitor screen.
Page 115: Viewing Snapshots And Movies On A Tv Screen
Viewing Snapshots and Movies on a TV Screen Use the AV cable that comes with the camera to connect it to the TV. White Yellow Video AUDIO IN jack (red) AUDIO IN jack (white) VIDEO IN jack (yellow) • Make sure that you insert the cable connector into the USB/AV port until you feel it click securely into place.
Page 116 Press [p] (PLAY) to turn on the camera. This will cause an image to appear on the TV screen, without anything appearing on the camera’s monitor screen. • Pressing [ON/OFF] or [r] (REC) will not turn on the camera while the AV cable is connected.
Page 117: Viewing High-Quality Movies On A Hi-Vision Television
Viewing High-quality Movies on a Hi-Vision Television Use a commercially available HDMI cable to connect the camera to the TV. For information about playback, see page 115. • Use a commercially available HDMI cable that is marked with the logo shown to the right.
Page 118 NOTE • Use a HDMI cable that with a plug that is compatible with the camera’s HDMI mini connector on one end, and a plug that is compatible with your TV’s HDMI connector on the other end. • Proper image and/or audio output and other operations may not be possible with some devices.
Page 119: Selecting The Hdmi Terminal Output Method (Hdmi Output)
. Selecting the HDMI Terminal Output Method (HDMI Output) Procedure [MENU] * Set Up Tab * HDMI Output Use this setting to select the digital signal format when connecting to a TV with an HDMI cable. This setting will cause the format to change automatically in accordance Auto with the connected TV.
Page 120: Other Playback Functions (Play)
Other Playback Functions (PLAY) This section explains menu items that you can use to configure settings and perform other playback operations. For information about menu operations, see page 89. Playing a Slideshow on the Camera (Slideshow) Procedure [p] (PLAY) * [MENU] * PLAY Tab * Slideshow Start Starts the slideshow Images...
Page 121 Effect Select the effect you want. Pattern 1 to 5: Plays background music and applies an image change effect. • Patterns 2 through 4 have different background music, but they all use the same image change effect. • Pattern 5 can be used for playback of snapshots only (except for those that are part of a CS group), and the “Interval”...
Page 122: Transferring Music From Your Computer To Camera Memory
Transferring Music from Your Computer to Camera Memory You can replace the built-in slideshow background music with other music from your computer. Supported File Types: • PCM format (16-bit, monaural / stereo) WAV files • Sampling Frequencies: 11.025 kHz/22.05 kHz/44.1 kHz Number of Files: 9 File names: SSBGM001.WAV to SSBGM009.WAV •...
Page 123: Creating A Snapshot Of Movie Frames
Double-click the “SSBGM” folder you created and copy the background music file to it. • See the user documentation that comes with your computer for information about moving, copying, and deleting files. • If there are background music files both in built-in memory and on the memory card loaded in the camera, the files on the memory card take priority.
Page 124: Editing A Movie On The Camera
Editing a Movie on the Camera (Movie Editing) Procedure [p] (PLAY) * Movie Screen of Movie to be Edited * [MENU] * PLAY Tab * Movie Editing The Movie Editing feature lets you use one of the following procedures to edit out a specific part of a movie.
Page 125 Press [2] to display the editing menu and specify one or two cut points. (To-Point Cut) (Point-To-Point Cut) ¡ (From-Point Cut) Use [8] and [2] to select “Yes” and then press [SET]. The selected cut operation will take considerable time to complete. Don’t try to perform any camera operation until the “Busy...
Page 126: Adjusting White Balance
Adjusting White Balance (White Balance) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * White Balance You can use the white balance setting to select a light source type for a recorded image, which will affect the colors of the image. Daylight Outdoors, fair weather ¤...
Page 127: Adjusting The Brightness Of An Existing Snapshot
Adjusting the Brightness of an Existing Snapshot (Brightness) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * Brightness You can select one of five brightness levels, from +2 (brightest) to –2 (least bright). NOTE • The original snapshot is retained in memory and not deleted. •...
Page 128: Protecting A File Against Deletion
Protecting a File Against Deletion (Protect) Procedure [p] (PLAY) * [MENU] * PLAY Tab * Protect Protects specific files. Use [4] and [6] to scroll through the files until the one you want to protect is displayed. Use [8] and [2] to select “On” and then press [SET].
Page 129 Use [4] and [6] to scroll through images until one you want to protect is displayed. Use [8] and [2] to select “On” and then press [SET]. This will protect the image and display the › icon. • To unprotect an image, select “Off” in step 4 and then press [SET]. After you are finished, select “Cancel”...
Page 130: Rotating An Image
Rotating an Image (Rotation) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * Rotation Use [8] and [2] to select “Rotation” and then press [SET]. Each press of [SET] will rotate the displayed image 90 degrees left. When the displayed image is at the orientation you want, press [MENU].
Page 131: Cropping A Snapshot
Cropping a Snapshot (Trimming) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * Trimming You can crop a snapshot to trim parts you do not need, and save the result in a separate file. The original snapshot is also retained.
Page 132: Dividing Up A Continuous Shutter Group
Dividing Up a Continuous Shutter Group (Divide Group) Procedure [p] (PLAY) * [MENU] * PLAY Tab * Divide Group See page 112 for details. Combining CS Images into a Single Still Image (CS Multi Print) Procedure [p] (PLAY) * Display CS group. * [MENU] * PLAY Tab * CS Multi Print Use [8] and [2] to select “Create”.
Page 133: Printing
Printing Printing Snapshots Professional Print Service You can take a memory card that contains the images you want to print to a professional print service and have them printed. Printing on a Home Printer Printing Images on a Printer with Memory Card Slot You can use a printer equipped with a memory card slot to print images directly from a memory card.
Page 134: Connecting The Camera To A Printer
. Connecting the Camera to a Printer Use the USB cable that comes bundled with the camera to connect the camera to your printer’s USB port. Large connector USB port Terminal cover • The camera does not draw power over the USB cable. Check the battery level before connecting and make sure it is not too low.
Page 135 . To print Turn on the printer and load paper. Turn on the camera. This will display the print menu screen. Use [8] and [2] to select “Paper Size”, and then press [6]. Use [8] and [2] to select a paper size and then press [SET]. •...
Page 136: Using Dpof To Specify Images To Be Printed And The Number Of Copies
Using DPOF to Specify Images to be Printed and the Number of Copies . Digital Print Order Format (DPOF) DPOF is a standard that allows you to include image type, number of copy, and time stamp on/off information on the memory card with the images. After configuring settings, you can use the memory card to print on a home printer that supports DPOF or take the memory card to a professional print service.
Page 137 . Configuring the Same DPOF Settings for All the Images Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * DPOF Printing * All images Use [8] and [2] to specify the number of copies. You can specify a value up to 99. Specify 00 if you do not want to print the image. •...
Page 138 Use [8] and [2] to specify the number of copies. You can specify a value up to 99. Specify 00 if you do not want to print the image. • If you want to date stamp the image, slide the zoom controller. This will cause “On”...
Page 139: Date Stamping
DPOF settings are not cleared automatically after printing is complete. The next DPOF print operation you execute will be performed using the last DPOF settings you configured for the images. To clear DPOF settings, specify “00” for the number of copies of all images. Tell your print service about your DPOF settings! If you take a memory card to a professional print service, be sure to tell them that it includes DPOF settings for the images to be printed and the number of copies.
Page 140 . Standards Supported by the Camera • PictBridge This is a standard of the Camera and Imaging Products Association (CIPA). You can connect the camera directly to a printer that supports PictBridge, and perform image selection and printing using the camera monitor screen and controls.
Page 141: Using The Camera With A Computer
Using the Camera with a Computer Things you can do using a computer... You can perform the operations described below while the camera is connected to a computer. Save images to a computer and view them there Transfer images stored on your computer to camera memory Play back and edit...
Page 142: Using The Camera With A Windows Computer
View the User’s Windows XP Guide (SP2/SP3) / Windows 2000 (SP4) YouTube Uploader for CASIO and Photo Transport will not run under 64-bit versions of Windows OS. Install this software: Installation not required. Installation not required. • Windows Media Player,...
Page 143: Computer System Requirements For Bundled Software
. Computer System Requirements for Bundled Software Computer system requirements are different for each of the applications. See the “Read me” file that comes with each application for details. Information about computer system requirements also can be found under “Computer System Requirements for Bundled Software”...
Page 144 Turn off the camera and then use the USB cable that comes with the camera to connect it to your computer. USB port Large connector Terminal cover • The camera does not draw power over the USB cable. Check the battery level before connecting and make sure it is not too low.
Page 145 Double-click “Removable Disk”. • Your computer recognizes the memory card loaded in the camera (or built-in memory if there is no card) as a removable disk. Right-click the “DCIM” folder. On the shortcut menu that appears, click “Copy”. Windows 7 / Windows Vista users: Click “Start” and then “Documents”.
Page 146 . To view images you copied to your computer Double-click the copied “DCIM” folder to open it. Double-click the folder that contains the images you want to view. Double-click the image file you want to view. • For information about file names, see “Memory Folder Structure” on page 159. •...
Page 147: Playing Movies
Playing Movies Windows Media Player, which is already installed on most computers, can be used for movie playback. To play back a movie, first copy the movie to your computer and then double-click the movie file. . Minimum Computer System Requirements for Movie Playback The minimum system requirements described below are necessary to play back movies recorded with this camera on a computer.
Page 148: Uploading Movie Files To Youtube
Uploader for CASIO. . To upload a movie file to YouTube • Before you can use YouTube Uploader for CASIO, you need to go to the YouTube website (http://www.youtube.com/) and register as a user there. • Do not upload any video that is copyrighted (including neighboring copyrights) unless you yourself own the copyright or you have obtained the permission of the applicable copyright holder(s).
Page 149: Viewing User Documentation
On the menu screen, click the “Language” down arrow button and then select the language you want. Click “Manual” to select it and then click “Digital Camera”. IMPORTANT! • You must have Adobe Reader or Adobe Acrobat Reader installed on your computer in order to view the contents of a PDF file.
Page 150: Transferring Images From Your Computer To Camera Memory
. To transfer images to the camera Connect the camera to your computer (page 143). On your computer, click the following: Start * All Programs * CASIO * Photo Transport. This starts up Photo Transport. Drag the file(s) you want to transfer to the [Transfer] button.
Page 151: User Registration
. To transfer computer screen captures to the camera Connect the camera to your computer (page 143). On your computer, click the following: Start * All Programs * CASIO * Photo Transport. This starts up Photo Transport. Display the screen whose screen capture you want to transfer.
Page 152: Using The Camera With A Macintosh
Using the Camera with a Macintosh Install the required software in accordance with what version of the Macintosh OS you are running and what you want to do. When you want to Operating do this: System Version Save images to your OS 9 Macintosh and view OS X...
Page 153 Turn off the camera and then use the USB cable that comes with the camera to connect it to your Macintosh. USB port Large connector Terminal cover • The camera does not draw power over the USB cable. Check the battery level before connecting and make sure it is not too low.
Page 154: To View Copied Images
Double-click the camera’s drive icon. Drag the “DCIM” folder to the folder to which you want to copy it. After the copy operation is complete, drag the drive icon to Trash. On the camera, press [ON/OFF] to turn off the camera. After making sure that the green back lamp is unlit, disconnect the camera from the computer.
Page 155: Transferring Images Automatically And Managing Them On Your Macintosh
Transferring Images Automatically and Managing Them on Your Macintosh If you are running Mac OS X, you can manage snapshots using iPhoto, which comes bundled with some Macintosh products. If you are running Mac OS 9, you will need to use commercially available software.
Page 156: Viewing User Documentation
Open the file named “camera_xx.pdf”. • “xx” is the language code (Example: camera_e.pdf is for English.) User Registration Internet registration only is supported. Visit the following CASIO website to register: http://world.casio.com/qv/register/ Using an Eye-Fi Wireless SD Memory Card to Transfer Images...
Page 157 IMPORTANT! • Recorded images are transferred over wireless LAN. Do not use the Eye-Fi card or turn off Eye-Fi card communication (page 161) when on an aircraft or in any other location where use of wireless communication is limited or prohibited. •...
Page 158: Files And Folders
Files and Folders The camera creates a file each time you shoot a snapshot, record a movie, or perform any other operation that stores data. Files are grouped by storing them in folders. Each file and folder has its own unique name. •...
Page 159: Memory Card Data
Memory Card Data The camera stores images you shoot in accordance with the Design Rule for Camera File System (DCF). . About DCF DCF is a standard that makes it possible to view and print images recorded on one manufacturer’s camera on DCF-compliant devices produced by other manufacturers. You can transfer DCF-compliant images recorded with another camera to this camera and view them on this camera’s monitor screen.
Page 160: Supported Image Files
. Supported Image Files • Image files shot with this camera • DCF-compliant image files This camera may not be able to display an image, even if it is DCF-compliant. When displaying an image recorded on another camera, it may take a long time for the image to appear on this camera’s monitor screen.
Page 161: Other Settings (Set Up)
Other Settings (Set Up) This section explains menu items that you can use to configure settings and perform other operations in both the REC mode and PLAY mode. For information about menu operations, see page 89. Adjusting Monitor Screen Brightness (Screen) Procedure [MENU] * Set Up Tab * Screen With this setting, the camera detects available light levels and...
Page 162: Auto Image Orientation Detection And Rotation
Auto Image Orientation Detection and Rotation (Auto Rotate) Procedure [MENU] * Set Up Tab * Auto Rotate Automatically rotates snapshots shot with the camera held vertically 90 degrees. Images not rotated automatically. The camera automatically detects whether a snapshot image was shot in portrait or landscape orientation and displays it accordingly.
Page 163: Specifying The File Name Serial Number Generation Rule
Specifying the File Name Serial Number Generation Rule (File No.) Procedure [MENU] * Set Up Tab * File No. Use the following procedure to specify the rule that governs generation of the serial number used in file names (page 158). Tells the camera to remember the last used file number.
Page 164: Time Stamping Snapshots (Timestamp)
Use [8], [2], [4], and [6] to select the geographic area you want and then press [SET]. Use [8] and [2] to select the city you want and then press [SET]. Press [SET]. IMPORTANT! • Before configuring World Time settings, make sure that the Home City setting is the place where you live or normally use the camera.
Page 165: Setting The Camera's Clock (Adjust)
Setting the Camera’s Clock (Adjust) Procedure [MENU] * Set Up Tab * Adjust [8] [2] Change the setting at the cursor location [4] [6] Move the cursor between settings Zoom Toggles between 12-hour and 24-hour format controller When the date and time settings are what you want, select “Apply” and then press [SET] to apply them.
Page 166: Specifying The Display Language
Specifying the Display Language (Language) Procedure [MENU] * Set Up Tab * Language . Specify the display language you want. Select the tab on the right. Select “Language”. Select the language you want. • Camera models sold in certain geographic areas may not support display language selection.
Page 167: Configuring Auto Power Off Settings
Configuring Auto Power Off Settings (Auto Power Off) Procedure [MENU] * Set Up Tab * Auto Power Off Auto Power Off turns off the camera whenever no camera operation is performed for a preset amount of time. Trigger Time Settings: 2 min, 5 min, 10 min (The trigger time is always 5 minutes in the PLAY mode.) •...
Page 168: Configuring Usb Protocol Settings
Configuring USB Protocol Settings (USB) Procedure [MENU] * Set Up Tab * USB You can use the procedure below to select the USB communication protocol, which is used when exchanging data with a computer, printer, or other external device. Select this setting when connecting to a computer (pages 143, 152).
Page 169: Selecting The Hdmi Terminal Output Method
Selecting the HDMI Terminal Output Method (HDMI Output) Procedure [MENU] * Set Up Tab * HDMI Output • See page 119 for details. Configuring a Startup Image (Startup) Procedure [MENU] * Set Up Tab * Startup Display the image you want to use as your startup image and then select “On”. •...
Page 170: Formatting Built-In Memory Or A Memory Card
Formatting Built-in Memory or a Memory Card (Format) Procedure [MENU] * Set Up Tab * Format If a memory card is loaded in the camera, this operation will format the memory card. It will format built-in memory if no memory card is loaded. •...
Page 171: Configuring Monitor Screen Settings
Configuring Monitor Screen Settings Turning Display Information On and Off (Info) Each press of [8] (DISP) will cycle through display settings that display or hide on- screen information and the control panel. You can configure separate settings for the REC mode and PLAY mode. Displays setting information and the control panel.
Page 172: How To Use The Histogram
How to Use the Histogram A histogram is a graph that represents the lightness of an image in terms of the number of pixels. The vertical axis indicates the number of pixels, while the horizontal axis indicates lightness. If the histogram appears too lopsided for some reason, you can use EV shift to move it left or right in order to achieve better balance.
Page 173: Appendix
Appendix Precautions during Use . Avoid Use While In Motion • Never use the camera to record or play back images while operating an automobile or other vehicle, or while walking. Looking at the monitor while in motion creates the risk of serious accident. .
Page 174 • Never try to take the camera apart or modify it in any way. Doing so creates the risk of electric shock, burn injury, and other personal injury. Be sure to leave all internal inspection, maintenance, and repair up to your dealer or nearest CASIO authorized service center.
Page 175: Memory Protection
• The battery is intended for use with a CASIO Digital Camera only. Use with any other device creates the risk of the battery damage, or deterioration of battery performance and service life.
Page 176: Battery Life
• If battery charging does not end normally within the specified charging time, stop charging anyway and contact your local CASIO authorized service center. Continued charging creates the risk of battery overheating, fire, and explosion.
Page 177: Data Error Precautions
. Data Error Precautions Your digital camera is manufactured using precision digital components. Any of the following creates the risk of corruption of data in camera memory. – Removing the battery or memory card while the camera is performing some operation –...
Page 178: Caring For Your Camera
Doing so creates the risk of fire, malfunction, and electric shock. 0 Should the power cord ever become damaged (to the point that internal wires are exposed or cut), immediately contact your original retailer or a CASIO authorized service center to request repair. Continued use of a damaged power cord creates the risk of fire, malfunction, and electric shock.
Page 179: Other Precautions
Note that CASIO COMPUTER CO., LTD. shall not be held liable for use of this product in any way that infringes on the copyrights of others or that violates copyright laws.
Page 180: Power Supply
• Check if the charger and battery contacts are dirty. If contacts are dirty, wipe them clean with a dry cloth. If problems continue to occur after you perform the above steps, it could mean that the battery is faulty. Contact your nearest CASIO authorized service center. Appendix...
Page 181: To Replace The Battery
To replace the battery Open the battery cover and remove the current battery. With the monitor screen side of the camera facing upwards, slide the stopper in the direction indicated by the arrow in the illustration. After the battery pops out, pull it the rest of the way out of the camera.
Page 182: Using The Camera In Another Country
Using the Camera in another Country . Precautions during Use • The bundled charger is designed for operation with any power supply in the range of 100V to 240V AC, 50/60Hz. Note, however, that the shape of the power cord plug depends on each country or geographic area.
Page 183: Using A Memory Card
. Using a Memory Card • SD memory cards and SDHC memory cards have a write protect switch. Use the switch when you need to guard against accidentally deleting data. Note, however, if you write protect an SD memory card you must then turn write protection off whenever you want to record to it, format it, or delete any of its images.
Page 184: Computer System Requirements For Bundled Software
Hard Disk Drive Space : At least 180MB Other : Internet Explorer 6.0 or higher installed For details about the minimum system requirements for each software application, see the “Read me” files on the CASIO Digital Camera Software CD-ROM that comes bundled with the camera. Appendix...
Page 185: Reset Initial Default Settings
Reset Initial Default Settings The tables in this section show the initial default settings that are configured for menu items (displayed when you press [MENU]) after you reset the camera (page 170). Menu items depend on whether the camera is in the REC mode or PLAY mode. •...
Page 186: Play Mode
“Set Up” Tab Screen Auto 2 Eye-Fi Auto Rotate Startup: Sound 1 / Half Shutter: Sound 1 / Shutter: Sound 1 / Sounds Operation: Sound 1 / = Operation: ...//// / = Play: ...//// File No. Continue World Time Home Timestamp .
Page 187: When Things Don't Go Right
2)The battery may be dead. Charge the battery (page 16). If the battery goes dead soon after being charged, it means the battery has reached the end of its life and needs to be replaced. Purchase a separately available CASIO NP-90 rechargeable lithium ion battery. The camera 1)Auto Power Off may have activated (page 167).
Page 188 (page 44) or select a different BEST SHOT scene (page 68). The ? (Flash Off) The flash unit may be malfunctioning. Contact a CASIO icon flashes red on authorized service center or your original retailer. Note that...
Page 189 Problem Possible Cause and Recommended Action A recorded image 1)Camera power may have been turned off before the save was not saved. operation was complete, which will result in the image not being saved. If the battery indicator shows battery as soon as possible (page 18). 2)You may have removed the memory card from the camera before the save operation was complete, which will result in the image not being saved.
Page 190 Possible Cause and Recommended Action Images are not This camera cannot display non-DCF images recorded onto a displayed. memory card using another digital camera. Images cannot be Note that you cannot edit the following types of snapshots. edited (with White •...
Page 191: Display Messages
If the same message appears after you turn power back on, contact your retailer or a CASIO authorized service center. when you remove the battery after it has been loaded for more than 24 hours, it could mean that the camera’s setting memory is defective.
Page 192 The Anti Shake unit of the camera may be malfunctioning. LENS ERROR 2 If the same message appears after you turn power back on, contact your retailer or a CASIO authorized service center. Load paper! The printer ran out of paper while printing.
Page 193 Shoot the image again. Your camera system is corrupted. Contact your retailer or a SYSTEM ERROR CASIO authorized service center. The LOCK switch of the SD or SDHC memory card loaded in the camera is in the The card is locked.
Page 194: Number Of Snapshots/Movie Recording Time
Number of Snapshots/Movie Recording Time Snapshot Image Size Image Quality (Pixels) RAW+ Fine (10M: Normal 3648 2736) Economy Fine (3648 2736) Normal Economy Fine (3648 2432) Normal Economy 16:9 Fine (3648 2048) Normal Economy Fine (3456 2592) Normal Economy Fine (3072 2304) Normal...
Page 195 Movies Movie Image Quality Mode (Pixels) / (Audio) HD (1280 720) 30 Megabits/second (Stereo) HD/STD STD (640 480) 10 Megabits/second (Stereo) 120 fps (640 480) 50 Megabits/second (No audio) (120 frames/second) 240 fps (448 336) 50 Megabits/second (No audio) (240 frames/second) 420 fps (224 168) 50 Megabits/second...
Page 196 Movie Image Quality Mode (Pixels) / (Audio) YouTube (HS120) (640 480) (No audio) YouTube (HS240) (448 336) (No audio) YouTube (HS420) (224 168) (No audio) YouTube (HS1000) (224 (No audio) YouTube YouTube (HS30-120) Capture (640 480) Mode (Audio recording at 30 fps only) YouTube (HS30-240) (448...
Page 197 Built-in memory capacity after formatting The above values are based on use of a PRO HIGH SPEED SD memory card (Panasonic Corporation). The number of images you can save depends on the type of memory card you are using. RAW+ is the total file size of the RAW file and 10M (3648 quality setting applies to the JPEG file only.
Page 198: Specifications
Specifications File Format Snapshots: * DNG file format is one type of RAW image file, and it is Movies: Recording Media Built-in Memory (Image Storage Area: 85.9MB) SD/SDHC Recorded Image Sizes Snapshot: Movies: Image Deletion 1 file; selected files; all files 1 CS group;...
Page 199 Exposure Control Program AE, Aperture Priority AE, Shutter Speed Priority AE, Manual Exposure Exposure –2.0 EV to +2.0 EV (in 1/3EV steps) Compensation Shutter CMOS electronic shutter, mechanical shutter Shutter Speed Snapshot (Auto): 1 to 1/2000 second Snapshot (Aperture Priority AE): 1 to 1/2000 second Snapshot (Shutter Speed Priority AE): 30 to 1/2000 second Snapshot (Manual Exposure): 30 to 1/2000 second * May differ due to the camera setup or shooting conditions.
Page 200 Timekeeping Built-in quartz digital clock Functions Date and Time: Recorded with image data Auto Calendar: To 2049 World Time 162 cities in 32 time zones City name, date, time, summer time Input/Output USB/AV port, Hi-Speed USB compatible Terminals HDMI output (Mini) Microphones Stereo Speaker...
Page 201 Approximate Battery Life All of the values provided below represent the approximate amount of time under normal temperature (23°C (73°F)) before the camera turns off. These values are not guaranteed. Low temperatures shorten battery life. Number of Shots (CIPA) (Operating Time)* Continuous Playback (Snapshots)* Approximate continuous movie recording time (High speed movie)*...
Page 202 . Rechargeable lithium ion battery (NP-90) Rated Voltage Rated Capacitance Operating Temperature Requirements Dimensions Weight . Charger unit (BC-90L) Input Power Output Power Operating Temperature Requirements Supported Battery Type Charging Time Dimensions Weight • Power cord precautions for use in Singapore The power cord set is not supplied.
Page 203 CASIO COMPUTER CO.,LTD. 6-2, Hon-machi 1-chome Shibuya-ku, Tokyo 151-8543, Japan MA1003-B...

This manual is also suitable for:

Ex-fh100bk

Casio Exilim EX-FH100 User Manual

Quick Start Basics

Snapshot Tutorial

Recording Movies

Using BEST SHOT

Advanced Settings

Viewing Snapshots and Movies

Other Playback Functions (PLAY)

Printing

Using the Camera with a Computer

Other Settings (Set Up)

Configuring Monitor Screen Settings

Appendix

Quick Links

Digital Camera

Need help?

Questions and answers

Related Manuals for Casio Exilim EX-FH100

Summary of Contents for Casio Exilim EX-FH100
