ASSEMBLY INSTRUCTIONS

FRAME ASSEMBLY

1.
Align six holes of the seat cushion (B).
Insert Ø6.3 x 45L bolt (BB), Ø6.3 x 50L
(CC) bolt through spring washer (DD),
flat washer (EE), with the chair back (A).
Repeat this procedure for adjacent hole.
Hardware Used
BB Ø6.3 x 45L Bolt
Ø6.3 x 50L Bolt
CC
Ø6.3 Spring washer
DD
Ø6.3 Flat washer
EE
2.
Align holes of the seat frame (C) and
foot rest (E).Insert Ø6.3 x 45L bolt (BB)
through spring washer (DD), flat washer
(EE), with the chair leg (D). Repeat this
procedure for 2nd leg.
Hardware Used
Ø6.3 x 45L Bolt
BB
Ø6.3 Spring washer
DD
Ø6.3 Flat washer
EE
1
x 2
A
x 4
x 6
x 6
2
D
x 8
x 8
FF
x 8
3
FF
CC
DD
EE DD
EE
B
EE
C
E
EE
EE
DD
DD
BB
FF
FF
BB
DD
EE
BB
DD
EE
E
D
D
BB
FF
CC FF
DD
FF
BB
C
