- Page 1 INc4b075_US 835-422 Ver 032021.08 ASSEMBLY INSTRUCTIONS...
- Page 2 SAFETY INFORMATION assemble or install the product. 2.Assemble the item on a soft, non-abrasive surface such as carpeting to avoid damage. Estimated Assembly Time: 60 minutes Recommended maximum sitting weight for the stool is 350 lbs/ 160kgs. Before beginning assembly of product, make sure all parts are present. Compare parts with parts list.If any part is missing or damaged, do not attempt to assemble the product and contact us immediately...
- Page 3 PACKAGE CONTENTS PART DESCRIPTION QUANTITY Chair back Seat cushion Seat frame Chair legs Foot rest Ø6.3 x 25L Ø6.3 x 50L Ø6.3 x 45L Bolt Bolt Bolt Qty. 4 Qty. 10 Qty. 4 Extra. 1 Extra. 1 Ø6.3 Ø6.3 Spring Allen Flat Washer...
- Page 4 ASSEMBLY INSTRUCTIONS FRAME ASSEMBLY Align six holes of the seat cushion (B). Insert Ø6.3 x 45L bolt (BB), Ø6.3 x 50L (CC) bolt through spring washer (DD), flat washer (EE), with the chair back (A). Repeat this procedure for adjacent hole. Hardware Used Ø6.3 x 45L Bolt Ø6.3 x 50L Bolt...
- Page 5 ASSEMBLY INSTRUCTIONS FRAME ASSEMBLY Repeat the same procedure as step 2 for the 3rd and 4th leg Hardware Used Ø6.3 x 45L Bolt Ø6.3 Spring washer Ø6.3 Flat washer Hardware Used Align holes of the swivel plate (C). Insert Ø6.3 x 25L bolt (AA) through Ø6.3 x 25L Bolt spring washer (EE), flat washer (FF), with the seat cushion (B).
- Page 6 ITEM NO. CTN NO. INCLUDING 8 35 -4 42 B K / 1 Chair back + 1 Seat cushion + 1 Seat Frame + 4 Chair legs + 1 Foot Rest + Hardware Part Product clusters inside carton Reference Picture Chair back Seat cusshion Seat frame...
