Installing Your SMART Hub PE260 with Four SMART Board™
680i2 Interactive Whiteboard Systems (SB680i2-PE260-04)
Applies to: SMART Board™ 680i2 interactive whiteboard systems (including SMART Board 680 interactive
whiteboards with Unifi™ 45 projectors) and the SMART Hub PE260
Overview
Follow these instructions to install your SMART Hub PE260 with four SMART Board 680i2 interactive
whiteboard systems.
WARNING
• This document is intended for installers who are responsible for installing and configuring
the SMART Hub with four SMART Board interactive whiteboard systems. You require advanced
knowledge of system installation and cabling to complete the procedures in this document.
• You need the help of another person to complete the following procedures because your
SMART Board interactive whiteboard systems and frame(s) may be too heavy for you to safely
maneuver by yourself.
This document covers:
•
Things to consider before installing your SMART Hub PE260 with four SMART Board 680i2 interactive
whiteboard systems (this page).
•
Instructions for installing your SMART Hub PE260 on the frame for your primary SMART Board 680i2 interactive
whiteboard system (page 3).
•
Instructions for installing a frame or a wall mount bracket for each of your additional SMART Board 680i2
interactive whiteboard systems (page 3).
•
Instructions for connecting your SMART Board 680i2 interactive whiteboard systems to your SMART Hub
PE260 (page 5).
•
Extra parts that you might have left over after you install your SMART Hub PE260 with four SMART Board 680i2
interactive whiteboard systems (page 9).
Details
Before You Begin
Before you install your SMART Hub PE260 with four SMART Board 680i2 interactive whiteboard systems,
consider whether:
•
Your installation wall is at least 8' 6" (2.6 m) high, which is high enough to accommodate safe head space
clearance, while maintaining enough space for airflow and installation access above the unit.
IMPORTANT
• Consult your local building codes and national regulations before you install your SMART Board
interactive whiteboard systems.
• Section 4.4.2 of the Americans with Disabilities Act
and Facilities
If you install your systems in a circulation space, you might need an installation wall that
is higher than 8' 6" (2.6 m) to meet this requirement.
Installing Your SMART Hub PE260 with Four SMART Board 680i2 Interactive Whiteboard Systems
requires circulation spaces to have a minimum vertical clearance of 80" (2.03 m).
Accessibility Guidelines for Buildings
1 of 10
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SMART PE260
Summary of Contents for SMART PE260
- Page 1 Instructions for connecting your SMART Board 680i2 interactive whiteboard systems to your SMART Hub PE260 (page 5). • Extra parts that you might have left over after you install your SMART Hub PE260 with four SMART Board 680i2 interactive whiteboard systems (page 9). Details...
- Page 2 However, if you install another interactive whiteboard system beside the SMART Hub’s side plate on your primary interactive whiteboard system’s frame, you must leave a 10" (25.4 cm) gap between the systems, which enables you to easily access the laptop connection panel and the reset button on the side plate.
-
Page 3: Smart Hub
3. Follow the instructions on page 23 to the end of page 26 to install your Unifi 45 projector and its boom. 4. Follow step 9 on page 29, and then, with the help of another person, hang your SMART Board interactive whiteboard on its wall mount bracket. - Page 4 Procedure 2 To install each of your remaining SMART Board 680i2 interactive whiteboard systems on a wall mount bracket, 1. Download and print the SMART Board 600i2 Interactive Whiteboard System Wall Bracket Installation Template (document 118926). Using this template ensures that you: –...
- Page 5 Connecting Your SMART Board 680i2 Interactive Whiteboard Systems to Your SMART Hub PE260 To connect your SMART Board interactive whiteboard systems to the bottom of your hub The following procedure refers to these cables: HD DB15 – VGA Cable (Unifi 45 Projector)
- Page 6 USB extension device, which isn’t included. 8. Connect one end of the power supply cable that you received with your SMART Hub to the DC In 12V 30V receptacle on your hub, and then connect the other end of this cable to a wall outlet.
- Page 7 USB Cable Power Connection (AC) Mouse DVI to VGA 3.5 mm IN for a Microphone Keyboard Connections from the Bottom of Your SMART Hub PE260 Installing Your SMART Hub PE260 with Four SMART Board 680i2 Interactive Whiteboard Systems 7 of 10...
- Page 8 99641. To connect optional peripherals to your SMART Hub 1. If you want to connect to a network, connect a Cat 5 cable (not provided) from the bottom of your SMART Hub to your network’s LAN input. 2. If you want to use a microphone, connect a 3.5 mm audio cable (not provided) to the audio IN receptacle on the bottom of your SMART Hub.
- Page 9 12 on page 30. Extra Parts that You Might Have Left Over If you installed an additional SMART Board 680i2 interactive whiteboard system on a frame to the wall, you might have the following extra parts (excluding documentation): Frame for SB680i2+SMART Hub boxes •...
- Page 10 Support +1.403.228.5940 or Toll Free 1.866.518.6791 (U.S./Canada) © 2008 SMART Technologies ULC. All rights reserved. SMART Board, Unifi, the SMART logo and smarttech are trademarks or registered trademarks of SMART Technologies ULC in the U.S. and/or other countries. All other third-party product and company names may be trademarks of their respective owners.
