8.2 Menu
MENU
mode display
DMX
auto
manual
audio
ob-3
8.3 Stand-Alone Mode
In stand-alone mode, the device runs one of the built-in programs: automatic or sound-activated.
Stand-Alone Mode with Built-in Programme
To set the device to stand-alone mode:
1. Unplug any connection from the DMX input [4] of the device.
2. Press MENU to open the menu.
3. Select <AP-->.
4. Select one of the built-in programmes.
Sound Activation
With sound activation, the built-in programme responds to sound. To use sound activation with the
selected built-in programme:
1. Press MENU to open the menu.
2. Select <Soun>.
3. Select one of the sensitivity levels.
8.4 Master/Slave Mode
The master/slave mode allows for connecting several devices to a single master device in a daisy chain.
All slave devices will then work synchronously with the master device. The first device in the daisy chain
functions as the master device.
To set the devices to master/slave mode:
1. Unplug any connection from the DMX input [4] of the master device (the first device in the chain).
2. Connect the DMX input of the first slave device to the DMX output [5] of the master device.
3. Connect the DMX input of the subsequent slave devices to the DMX output of the previous slave
device.
4. On the master device, press MENU to open the menu.
5. Select the desired mode.
6. On the slave devices, press MENU until <A---> appears on the display.
7. Select <A001> and confirm with ENTER.
V. 01 – 25/11/2014
VDPLDJBAR8
ENTER
A.001-A.512
DMX address selection
AP01-AP12
built-in programmes
F.00-F.08
8 speed options (00 = static)
r.00-r.08
intensity red (00 = off)
g.00-r.08
intensity green (00 = off)
b.00-r.08
intensity blue (00 = off)
F.00-F.08
strobe speed (00 = static)
SP00-SP03
audio sensitivity from low to high
RGB no function
7
UP/DOWN ENTER
save
+
run
