- Page 1 USER MANUAL UPM 1400 Field meter type DVB-T/S/C Article Reference UPM 1400 Portable Field meter DVB-S/T/C 304579 Document Version V 3.23 Date 05/2022...
- Page 2 Toute intervention sur l’installation ou travaux de maintenance sont à proscrire en cas d’orage. Introduction These operating instructions will help you get the most out of your UPM 1400 field meter device. We assume that the user of this meter device is a trained personal and he/she is in possession of a general knowledge of handling antenna technology components.
- Page 3 UPM 1400...
-
Page 4: Table Of Contents
UPM 1400 Introduction ................................... 6 Description of the UPM 1400 unit ................................. 6 Content of the product package delivered ..............................6 Main Features ..................................6 Frontal face ........................................7 Right side ........................................7 Left side .......................................... 8 Commissioning (put into operation)............................8 Turn on the meter, charge the battery ................................ - Page 5 Basic safety instructions • In the event of a malfunction, disconnect the UPM 1400 unit from the power supply or connected signal source. • To prevent fire or electric shock hazard, do not expose the meter unit to rain or other moisture.
-
Page 6: Introduction
Description of the UPM 1400 unit The TRIAX UPM 1400 unit is a COMPACT and ECONOMIC measuring device, combining the measurements of satellite, cable and terrestrial signals. Its compact design and extensive functions make it a reliable aiding tool when installing and pointing terrestrial and satellite antennas. -
Page 7: Frontal Face
UPM 1400 Frontal face Screen: 5" TFT display for the menu and TV program LEDs status : The two color POWER LED displays the charge and operation of the product: Red : device in operation Green : device charging LOCK : indicates received signal... -
Page 8: Left Side
Turn on the meter, charge the battery Before using your UPM 1400 device for the first time, batteries should be charged for at least 2 hours. To do this, connect the measuring device to the power supply. Please only use the appropriate power supply included with the product in order to avoid potential damage to the device. -
Page 9: Main Menu
UPM 1400 Main menu Description of the menu items Satellite: • TP search: search for signals on a satellite, by transponders, etc… • SAT identification: auto recognition of the received satellite • Packet control: simultaneous measurements of multiple transponders in real time •... -
Page 10: Main Menu
UPM 1400 Main menu The image below depicts the main menu. Menu items are selected by using the cursor keys. Confirmation is done by pressing the OK button, gives access to this menu For quick adjustment to lighting conditions, various screen adjustments can be made using the function keys. -
Page 11: Satellite, Tp Search: Functions And Settings
UPM 1400 Satellite, TP search: functions and settings Important parameters such as LNB command and control signals are also permanently set in the TP search menu. Incorrect settings lead to malfunctions ! After selecting the desired satellite from the list of satellites offered, by pressing the OK button, you are now in the TP search menu for DVB-S/S2 signals where the reception parameters are specified, the transponders are classified and TV programs can be searched. -
Page 12: Satellite, Tp Search: Add/Edit A Transponder
UPM 1400 Function Key Options F1 - starts a channel search on the selected transponder F2 - displays signal level and quality in an enlarged display mode In the Zoom Signal menu, the signal level is displayed on the left and the signal quality is displayed on the right, both values in very large scale. -
Page 13: Satellite, Sat Identification
The example below shows the automatic identification of satellites during the search. The UPM 1400 searches for all satellites until it receives a signal for LNB 1 with the correct satellite ID. In the example below, the Astra 19.2E satellite has been detected at the DiSEqC LNB1 port. -
Page 14: Satellite, Packet Control: Satellite List
UPM 1400 Satellite, packet control: satellite list With the packet check function received on the TPs, all stored transponders of a respective satellite are measured and evaluated one after the other. By evaluating over a longer period of time, for example, errors can be determined that only occur sporadically. -
Page 15: Satellite, Diseqc Search
If you need to check an existing multi-satellite setup, you can use the DiSEqC search to quickly and easily check the current setup. The UPM 1400 checks all connected satellites, identifies them and displays the corresponding DiSEqC port. The analysis begins as soon as the function has been selected. You can cancel the search at any time by pressing the Exit button. -
Page 16: Satellite, Spectrum
UPM 1400 Satellite, spectrum The signal spectrum shows a graphical representation of the signal carriers on a certain satellite polarization in a certain frequency band. The selected frequency is displayed via a cursor in the form of a green line. -
Page 17: Satellite, Spectrum: Constellation Diagram
The screen shot below shows the rating and constellation diagram of a QPSK DVB-S modulated transponder by pressing the F2 key The UPM 1400 evaluates the signal parameters of a channel and displays them graphically using a constellation diagram. Ideally, the device receives a noise-free and interference-free signal. This is shown in 4 quadrants over many small dots which are grouped together and form circles. -
Page 18: Satellite Configuration, Alignment Settings
Satellite configuration, alignment settings Now that the antenna is pointing south and the elevation angle has been set to suit your location, the UPM 1400 can be connected to the LNB. The easiest way to line up is through the TP search menu. The detailed explanation of the different functions of this menu item can be found in chapter 5.1. -
Page 19: Satellite Configuration, Pointing Using The Measuring Device
UPM 1400 Satellite configuration, pointing using the measuring device Pointing: Now turn the antenna carefully, very slowly and never jerkily to the east (to the left when standing behind the antenna). After only a few centimeters of rotation, the bar graphs showing the MER and BER values of the measuring device deviate. -
Page 20: Terrestrial, Constellation Diagram
The screenshot below shows the rating and constellation diagram of a 64QAM DVB-T2 modulated transponder. The UPM 1400 evaluates the signal parameters of a channel and displays them graphically using a constellation diagram. Ideally, the device receives a noise-free and interference-free signal. This is shown in 4 quadrants over many small dots which are grouped together and form circles. -
Page 21: Terrestrial, Packet Control
Only channels / transponders already stored in the UPM 1400 are displayed. Before packet checking can be performed, the DVB-T/T2 channels must be registered via a search... -
Page 22: Cable Menu (Wired Network)
The antenna supply voltage can be adjusted with the F4 function key. Attention, supplying an antenna with a voltage while no preamplifier is inserted between the UPM 1400 meter and the antenna can irreparably damage the antenna and the meter! -
Page 23: Cable, Constellation Diagram
The screenshot shows the rating and constellation diagram of a 64 QAM DVB-C modulated transponder. The UPM 1400 evaluates the signal parameters of a channel and displays them graphically using a constellation diagram. Ideally, the device receives a noise-free and interference-free signal. In the diagram, this is shown by many clearly defined points that form a circle. -
Page 24: Cable, Spectrum
UPM 1400 Function Key Options F1 - restarts the control and the device starts scanning again F2 - saves the analyzed values over an individual time period to a USB storage medium F3 - scans transponders for 1 hour and saves results to USB storage... -
Page 25: Tv Mode, Channel Lists Option
UPM 1400 In the following example you can see a live television picture transmission of a DVB-T program. Function Key Options F1 - Selection of program lists for DVB-S, DVB-T or DVB-C channels F2 - opens the main program list which contains all saved channels of all reception types... -
Page 26: Tv Mode, Advanced Options
UPM 1400 TV mode, advanced options The Menu key gives access to further options in TV mode, which are explained below The image shows the advanced options Silence – allows you to mute the sound output of the meter Info - displays detailed program and signal information PVR –... -
Page 27: Tv Mode, Signal Search And Evaluation
Press the SCAN button from TP mode to quickly start a DVB-S, DVB-T or DVB-C search. The mode supports a quick search function as well as a detailed blind search. Parameters and advanced menus of the meter Parameters The basic UPM 1400 meter settings are set in the Settings sub-menu of the menu. -
Page 28: Reset
UPM 1400 System settings - Sets basic parameters such as language, sound signal, unit of measurement, etc. An extremely interesting parameter in this menu is the “city”. We have filled in the channels (R1 to R6) of some French DTT transmitters serving the main French cities. By selecting the city closest to where you are doing your terrestrial measurements, the 6 channels will be pre-selected and displayed during the terrestrial measurement –... -
Page 29: Advanced
UPM 1400 page on our website Internet www.triax.fr Update procedure: ➢ Turn on the UPM 1400 and wait for it to boot up completely ➢ Connect the USB storage medium, after a short while a message appears at the "USB Connected" screen ➢... -
Page 30: Additional Information
To do this, connect the supplied AV/DC cable to the AV IN/DC OUT socket of the UPM 1400 and to the signal source. By pressing the AV/TV button, the device enters AV playback mode... -
Page 31: Technical Datasheet
UPM 1400 Technical datasheet Display Type 5“ TFT Resolution 480*800 Satellite 13V,18V, LNB Test12V-20V in 0,2V increments 22KHz Auto, On, Off Control signals voltages DiSEqC DiSEqC1.0/1.1/1.2 Terrestre 5V, 12-24V Satellite 950 MHz - 2150MHz Frequency bands Terrestre & Cable 50 MHz - 860 MHz MPEG1, MPEG-2 MP@ML, H.264, VC1, DV, MPEG-4, H.265... - Page 32 UPM 1400 Notes...
