Specification
Model
TR-D4D5
Image sensor
1/3" CMOS 4МP
Resolution
4MP(2560x1440)
Frame rate
4MP@25fps
Electronic shutter speed
1/2 ~ 1/1 000 s
Day/Night Mode
Mechanical ICR
Sensitivity
0.005Lux (F1.8)
IR range
up to 15 m
Lens (mm)
Field of view(horiz./vert.)
2.8mm: 94˚ / 50˚
3.6mm: 77˚ / 42˚
WDR
D-WDR (105 dB)
Digital Noise Reduction
Video compression
Н.265+ / Н.265 / H.264
Bitrate
up to 8Mbps
IVS
Corridor mode
Power supply
PoE (802.3af) / 12V DC
PoE Class
Power consumption
DC: 2.6W
PoE: 2.9W
Case material
Dimensions (mm)
Ø95 x 63
Weight Net/Gross (g)
295 / 385
Protection
IP66, IK10, TVS 4000V
Working temperature
-40°C ... +60°C
Technical support
www: helpdesk.trassir.com
mail: helpdesk@trassir.com
2.8 / 3.6
3D DNR
Yes
Yes
0
Metal
Data ___________________________ Stamp ___________________________
Here is the confirmation form for warranty assurance
TR-D4D5
Outdoor IR Network Camera
4МP
IR
Cut
IK10
Note: read user manual before using
Website: www.trassir.com
For any inquiry: info@trassir.com
Advertisement
Related Manuals for TRASSIR TR-D4D5
Summary of Contents for TRASSIR TR-D4D5
- Page 1 Weight Net/Gross (g) 295 / 385 Protection IP66, IK10, TVS 4000V Working temperature -40°C … +60°C 4МP Data ___________________________ Stamp ___________________________ IK10 Here is the confirmation form for warranty assurance Note: read user manual before using Website: www.trassir.com For any inquiry: info@trassir.com...
- Page 2 2. Set up camera IP address using fast configuration utility that can ∅95 be downloaded from www.trassir.com. 66,7 3. Change IP camera settings using TRASSIR professional software. Camera package You can find detailed camera settings instructions in User Manual that can be downloaded from trassir.com.
