TRASSIR TR-D2221WDIR4 Quick Start Manual

Specification
Model TR-D2221WDIR4
Image sensor 1/2.8" STARVIS CMOS 2MP
Resolution FullHD(1920x1080)
Frame rate FullHD@25fps
Electronic shutter speed 1/2 ~ 1/1 000 s
Day/Night mode
Mechanical ICR
Sensitivity 0.003Lux (F1.8)
IR range
up to 40 m
Lens (mm) 1.9 / 2.8 / 3.6
Field of view (horiz./vert.) 1.9mm: 118˚ / 62˚
2.8mm: 108˚ / 58˚
3.6mm: 88˚ / 47˚
WDR Real WDR (120dB)
Digital noise reduction
Video compression Н.265 / H.264
Bitrate up to 8Mbps
Local storage MicroSD up to 128GB
Audio Built-in microphone
AudioOut
Alarm In/Out
Corridor mode
Power supply PoE (802.3af) / 12V DC
PoE Class
Power consumption
Case material
Dimensions (mm) 183.3 x 67.3 x 63.9
Weight Net/Gross (g) 460 / 565
Ingress protection
Lightning protection TVS 4000V
Working temperature -40°C ... +60°C
Technical support
www: helpdesk.trassir.com
mail: helpdesk@trassir.com
3D DNR
1 / 1
Yes
3
DC: 7W
PoE: 8W
Metal
IP67
Data ___________________________ Stamp ___________________________
Here is the confirmation form for warranty assurance
TR-D2221WDIR4
2MP Lens Bullet IR Camera
2MP
Note: read user manual before using
Website: www.trassir.com
For any inquiry: info@trassir.com
