TRASSIR TR-D2181IR3 Quick Start Manual

Technical Specifications
Model TR-D2181IR3
Image sensor 1/2.7" CMOS 8Mp
Resolution 8МР(3840х2160)
Broadcast speed 8MP@15fps
Electronic shutter speed 1/3-1/1 000 s
"Day/Night" mode Mechanical ICR
Sensitivity 0.005 lux (F1.8)
IR range Up to 35 m
Lens (mm)
Field of view (horiz./vert.) 2.8mm: 110°±3°/59°±3°
3.6mm: 91°±3° / 46°±3°
WDR Real WDR (120dB)
Digital Noise Reduction
Video compression Н.265+ / Н.265 / Н.264+ / Н.264
Bitrate up to 10Mbps
Local storage MicroSD up to 128Gb
Audio Built-in microphone
Corridor mode
IVS Human detection
Line crossing
Intrusion detection
face detector
detector of left possessions
line crossing statistics
Power РоЕ (802.3af) / 12V DC
РоЕ Class
Maximum DC: 8.5W
consumption РоЕ: 13W
Case material
Dimensions (mm) 165.3x64.8x64.8
NET/GROSS weight (g)
IP rating
Ingress protection
TVS 2000V
Working temperature -40°С ... +60°С
Service center addresses
Moscow,
17b3 Perevedenovskiy lane
+7(495)783-72-87
Nizhny Novgorod,
31a Premudrova st.
+7(831)228-64-51
St. Petersburg
5 Bobruiskaya st.
+7(812)339-89-29
Novosibirsk,
2.8/3.6
3/1 3 rd Krasheninnikov Lane
+7(383)355-99-39
Vladivostok,
7g Semyonovskaya st.,
+7(423)249-28-29
3D DNR
Yaroslavl,
16bld.81 Polushkina Roscha st.
+7(4852)69-53-75
Samara,
150/1 Aurora st.
+7(846)207-43-68
Yes
Kiev,
44E Glybochytskaia st.
+380(44)591-56-83
0
You can find addresses of other service centers at:
Metal
364/435
IP67
Date:
Do not attempt to disassemble the camera, if the camera does
not work, contact your place of purchase or a service center.
Krasnodar,
25 Molodezhnaya st.
+7(861)203-38-68
Kazan,
36 Yamashev ave.
+7(843)205-36-57
Ekaterinburg,
35a Furmanov st.
+7(343)257-26-43
Rostov-on-Don,
3 Budennovskiy ave.
+7(863)303-36-84
Volgograd,
19 7-Gvardeyskaya st.
+7(8442)78-01-35
Voronezh,
53 Moskovsky ave.
+7(473)204-51-12
Ufa,
6 Luganskaya st.
+7(347)214-90-31
Almaty,
270/4 Kablukova st.
+7(727)350-52-46
www.trassir.com/service/
LS
TR-D2181IR3
Outdoor IP camera with IR illumination
H.265
8Mp
HEVC
-40°
Note:
Please read this user manual before connecting
the camera!
