TRASSIR TR-D5124 User Manual

Specification
Model TR-D5124
Image sensor 1/2.8" STARVIS CMOS 2MP
Resolution FullHD(1920x1080)
HD720P(1280x720)
Frame rate FullHD@25fps
HD720P@25fps
Electronic shutter speed 1/1 ~ 1/30 000 sec
"Day/Night" mode Mechanical ICR
Sensitivity 0.005Lux (F1.6)
Lens (mm) 5.3-64 mm, F1.6-F4.4
Field of view (horiz.) 58.2˚ - 4.8˚
Optical zoom
Digital zoom
Pan/Tilt Range Pan: 0° ~ 360°(infinite)
Tilt: -2° ~ 90° (autoflip to 180°)
Manual Control Speed Pan: 0.1°/s ~ 300°/s
Tilt: 0.1°/s ~ 120°/s
Preset Speed Pan: 300°/s
Tilt: 200°/s
Auto focus
WDR Real WDR (120dB)
Digital noise reduction Ultra DNR (2D/3D)
Video compression Н.265 / H.264
Bitrate up to 8Mbps
Local storage MicroSD up to 128GB
Audio 1 in / 1 out
IVS
Alarm IN/OUT
Power supply PoE+ (802.3at) / 24V AC
Power consumption
Dimensions (mm) Ø170 x 155
Weight Net/Gross (g)
Ingress protection IP66, IK10
Working temperature -30°C ... +60°C
Technical support
www: helpdesk.trassir.com
mail: helpdesk@trassir.com
x12
x16
Yes
Yes
2 / 1
12W
1800
Data ___________________________ Stamp ___________________________
Here is the confirmation form for warranty assurance
TR-D5124
Compact 2MP PTZ IP camera
