SAFETY WARNINGS

1-Follow the information on the warning label appearing on the upper bunk bed
and structure on the carton ... Do not remove warning label from bed
2-Alway use the recommended size mattress or mattress support, or both,
to help prevent the likelihood of entrapment or falls.
3-Surface of mattress must be at least 5 inches below the upper edge of guard rails.
4-Do not allow children under 6 years to use the upper bunk bed.
5-Prohibit more than one person on upper bunk.
6-Periodically check and ensure that the guardrail, ladder, and other components are
in their proper position, free from damage, and that all connectors are tight.
7-Do not allow horseplay on or under the bed and prohibit jumping on the bed.
8-Always use the ladder for entering and leaving upper bunk.
9-Do not use substitute part. Contact the manufacturer or dealer for replacement part.
10-Use of night light may provide added safety precaution for a child using the upper
bunk.
11-If the bunk bed will be placed next to a wall, the guardrail that runs the full length of the bed.
12-Always use guardrail on both long sides of the upper bunk.
13-The use of water or sleep flotation mattresses is prohibited.
14-Keep these instruction for future reference.
15-Strangulation Hazard - Never attach or hang items to any part of the bunk bed that are not
designed for use with the bed, for example, but not limited to hooks, belts and jump rores.
PLEASE DO NOT RETURN PRODUCT TO THE STORE.
If you have any problem or concerns, please feel free to contact our customer
service department. We will reply you as soon as possible.
ASSEMBLY INSTRUCTIONS
ITEM # :
WF195692 &WF195693
E-Mail: csr@merax.com
Tel: 626-912-8886 Ext.100
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WF195692 and is the answer not in the manual?

Questions and answers

Summary of Contents for Merax WF195692

  • Page 1 ASSEMBLY INSTRUCTIONS ITEM # : WF195692 &WF195693 SAFETY WARNINGS 1-Follow the information on the warning label appearing on the upper bunk bed and structure on the carton ... Do not remove warning label from bed 2-Alway use the recommended size mattress or mattress support, or both, to help prevent the likelihood of entrapment or falls.
  • Page 2 ASSEMBLY INSTRUCTIONS ITEM # : WF195692 PART LISTS PHOTO PART NAME Q'TY 2pcs Cap for horizontal bar 2pcs Center horizontal bar 2pcs Bottom horizontal bar 2 pc Side rail ( Center Guardrail Support 1pcs 2pcs Upper legs ( 2pcs Upper legs (...
  • Page 3 ASSEMBLY INSTRUCTIONS ITEM # :WF195693 PART LISTS HARDWARE LISTS PHOTO HARDWARE NAME Q'TY PHOTO PART NAME Q'TY 20pcs 2pcs Cap for horizontal bar 4pcs 2pcs Center horizontal bar 2pcs Bottom horizontal bar Horizontal-Hole bolts 24pcs Side rail ( Hex-Head bolts 16pcs Side rail ( Hex-Head bolts...
  • Page 4 STEP 1: Headboard Assembly (I) WF195692 4 PLACES STEP 2: Headboard Assembly (I) Page 4...
  • Page 5 Completed Twin Slat Assembly (I) STEP 3: STEP 4: 6 PLACES Page 5...
  • Page 6 STEP 5: Headboard Assembly (II) STEP 6: Headboard Assembly (II) 2 PLACES Page 6...
  • Page 7 STEP 7: Headboard Assembly (II) 2 PLACES STEP 8: Completed Twin Slat Assembly (II) Page 7...
  • Page 8 STEP 9: Ladder (II) Assembly STEP 15: Ladder (I)&(II) Assembly Headboard (II) WF195692 Headboard (I) WF195692 Page 8...
