- Page 1 BED WITH TRUNDLE PLEASE DO NOT RETUNR PRODUCT TO THE STORE. If you have any problems or concerns, please feel free to contact our customer service department. We will reply to you at the first time. E-Mail: csr@merax.com Tel: 626-912-8886 Ext.100 WF194473...
-
Page 2: Detail View
Detail View... -
Page 3: Part List
Part List Cap for HB & FB - 2pcs HB/FB Frame - 1pc HB horizontal bar - 1pc Leg headboard(Left) - 1pc Leg headboard(Right) - 1pc Leg footboard(Right) - 1pc Leg footboard(Left) - 1pc Side rail - 2pcs Slat - (10pcs) Front panel of trundle - 1pc Back panel side rail of trundle - 1pc Trundle Slat - (8pcs) -
Page 4: Hardware List
Hardware List 1/4"*15 (9.5mm) Hex-Head bolts (10pcs) Hex-Head bolts (8pcs) Horizontal-Hole bolts(18pcs) Hex-Head bolts (6pcs) Wood screws (32pcs) Metal bracket (2pcs) (1/4")4.5*58mm Allen key (1pc) Metal bracket (2pcs) Wood screws (16pcs) 100*63*20mm Wheels (4pcs) ASSEMBLY TOOLS REQUIRED ( NOT INCLUDED ) - Page 5 STEP 1: 10PCS 10PCS STEP 2: 6PCS...
- Page 6 STEP 3: 8PCS 8PCS STEP 4: 8PCS Note: Do not lock the screws of the bed slats to the outermost edge of the bed slats, you need to leave a certain space at the edges,...
- Page 7 STEP 5: 4PCS 8PCS STEP 6: 16PCS Note: Do not lock the screws of the bed slats to the outermost edge of the bed slats, you need to leave a certain space at the edges,...
- Page 8 STEP 7: 2PCS 8PCS STEP 8: 8PCS 2PCS...
- Page 9 STEP 9: Push Trundle under the bottom of Twin bed.
