Field wiring and signal termination

You can use the following screw terminal boards to terminate field signals and route them into the PCI-
DUAL-AC5 using the C100FF-x cable.
CIO-MINI50 – 50-pin universal screw terminal board. Two boards are required. Details on this
product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=258.
CIO-SPADE50 — 16" x 4" termination panel which mates with both 37-pin and 50-pin connectors.
Two boards are required. Details on this product are available on our web site at
www.mccdaq.com/pdfs/screw.pdf.
CIO-TERM100 – 100-pin screw terminal board (daisy-chained 50-pin IDC connectors). Two boards
are required. Details on this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=102&pf_id=281.
SCB-50 – 50 conductor, shielded signal connection/screw terminal box provides two independent
50-pin connections. Details on this product are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=196&pf_id=1168.
You can use the following relay mounting rack with the C100FE-x cable to provide digital signal
conditioning.
SSR-PB24 – 24 channel solid-state relay mounting and interface rack. Details on this product are
available on our web site at www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=122&pf_id=619.
The PCI-DUAL-AC5 supports up to two SSR-PB24 boards (one cable required per SSR-PB24).
