PCI-DUAL-AC5 User's Guide

Installing the software

Install the software included with your board before you install the hardware. Installing the software first
ensures that the information required for proper board detection is installed and available at boot up.
Refer to the Quick Start Guide for instructions on installing the software on the Measurement Computing
Data Acquisition Software CD. This booklet is shipped with the hardware, and is also available in PDF at
www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf.

Installing the hardware

The PCI-DUAL-AC5 board is completely plug-and-play. There are no switches or jumpers to set on the
board. Configuration is controlled by your system's BIOS. To install your board, follow the steps below.
Install the MCC DAQ software before you install your board
The driver needed to run your board is installed with the MCC DAQ software. Therefore, you need to
install this software before you install your board. Follow the directions for installing this software in the
Quick Start Guide that shipped with your board.
1.
Turn your computer off, open it up, and insert your board into an available PCI slot.
2.
Close your computer and turn it on.
If you are using an operating system with support for plug-and-play (such as Windows 2000 or
Windows XP), a dialog box pops up as the system loads indicating that new hardware has been
detected. If the information file for this board is not already loaded onto your PC, you will be
prompted for the disk containing this file. The MCC DAQ software contains this file. If required,
insert the Measurement Computing Data Acquisition Software CD and click
3.
To test your installation and configure your board, run the InstaCal utility installed in the previous
section. Refer to the Quick Start Guide that came with your board for information on how to initially
set up and load InstaCal.

Connecting the board for I/O operations

Connectors, cables – main I/O connector
Table 2-1
lists the board connectors, applicable cables, and compatible accessory products for the PCI-
DUAL-AC5.
Table 2-1. Board connector, cables, and accessory equipment
Connector type
Compatible cables
Compatible accessory product with
the C100FE-x cable
Compatible accessory products with
the C100FF-x cable
The PCI-DUAL-AC5 connector is accessible through the PCI slot expansion bracket. The connector is a
standard 100-pin header connector. If you are connecting to the SSR-PB24 or equivalent, we recommend
using the C100FE-x series cable. This cable splits the 100-pins into two edge-connectors which can
connect to two SSR-PB24 racks.
100-pin high-density Robinson-Nugent
C100FE-x
C100FF-x
SSR-PB24 (two required)
CIO-MINI50 (two required)
CIO-SPADE50 (two required)
CIO-TERM100
SCB-50
2-3
Installing the PCI-DUAL-AC5
.
