31
NO.
PROGRAMMING THE MOTOR CONTROLLER ON A 48V HYPOWER
TM
SERVICE CALL:
MODEL(S):
TOOLS NEEDED:
PROGRAMMING TEH MOTOR
ALL TEREX UTILITIES UNITS
CURTIS PROGRAMMING DEVICE
CONTROLLER ON A 48V
EQUIPPED WITH THE 48V
PHILLIPS SCREWDRIVER
HYPOWER
HYPOWER
SYSTEM
TM
TM
TEREX UTILITIES TECHNICAL SUPPORT TEAM
PHONE:
1-844-TEREX4U (1-844-837-3948)
| EMAIL:
UTILITIES.SERVICE@TEREX.COM
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Terex TECH TIP 31
Summary of Contents for Terex TECH TIP 31
- Page 1 PROGRAMMING THE MOTOR CONTROLLER ON A 48V HYPOWER SERVICE CALL: MODEL(S): TOOLS NEEDED: PROGRAMMING TEH MOTOR ALL TEREX UTILITIES UNITS CURTIS PROGRAMMING DEVICE CONTROLLER ON A 48V EQUIPPED WITH THE 48V PHILLIPS SCREWDRIVER HYPOWER HYPOWER SYSTEM TEREX UTILITIES TECHNICAL SUPPORT TEAM PHONE: 1-844-TEREX4U (1-844-837-3948) | EMAIL: UTILITIES.SERVICE@TEREX.COM...
- Page 2 The information contained in this Tech Tip is a supplement to the Service Manual. Consult the appropriate Service Manual of your machine for TECH TIP 31 | RELEASED 03.14.2022 | VERSION 1.0 safety rules and hazards. ©TEREX UTILITIES. ALL RIGHTS RESERVED TECH TIP 31 | RELEASED 03.14.2022...
- Page 3 | Set Turn On Time Threshold | Select Motor Item in Parameters STEP 5 - STEP 6 | Adjust speed settings | Verify programming STEP 7 - STEP 9 TECH TIP 31 | RELEASED 03.14.2022 | VERSION 1.0 PAGE 3 OF 10...
- Page 4 Locate the panel displaying PTO hours and hybrid battery status. This panel is typically installed in one of the rear compartments. Once the panel has been located, remove the four Phillips screws holding it in place. TECH TIP 31 | RELEASED 03.14.2022 | VERSION 1.0 PAGE 4 OF 10...
- Page 5 Device. After approximately 10 seconds, the Curtis Programming Device should power up. STEP 4 Once the system boots up, use the arrow keys to select the Parameters menu. TECH TIP 31 | RELEASED 03.14.2022 | VERSION 1.0 PAGE 5 OF 10...
- Page 6 The variable, Turn on Voltage should be set to 44.50V. This value represents the voltage that triggers the engine to start and recharge the unit. If this value is incorrect, use the arrow keys to select it and change the set value. TECH TIP 31 | RELEASED 03.14.2022 | VERSION 1.0 PAGE 6 OF 10...
- Page 7 44.50V before the system starts to recharge. This value should be set to 5 seconds, select it to modify the set value. STEP 6 Select the Motor menu item in the parameters menu. TECH TIP 31 | RELEASED 03.14.2022 | VERSION 1.0 PAGE 7 OF 10...
- Page 8 STEP 6 (CONTINUED) Next, choose Temperature Control. The Sensor Enable variable in this screen should be set to OFF. If it is ON, select the variable to modify it. TECH TIP 31 | RELEASED 03.14.2022 | VERSION 1.0 PAGE 8 OF 10...
- Page 9 44.5 Volts. Once the voltage remains at or below 44.5 V for at least 5 seconds the chassis engine should start to charge the hybrid system. TECH TIP 31 | RELEASED 03.14.2022 | VERSION 1.0 PAGE 9 OF 10...
- Page 10 FOR FURTHER ASSISTANCE, CONTACT THE TEREX UTILITIES TECHNICAL SUPPORT TEAM PHONE: 1-844-TEREX4U (1-844-837-3948) | EMAIL: UTILITIES.SERVICE@TEREX.COM...
