INSTALLATION GUIDE
IP-DECT Base Station and IP-DECT Gateway
The IPBL current consumption is 0,3 A and is included in max current consumption.
For more information of power consumption of the RFPs, see
page 32.
4.2

Pin the IPBL Cable

All data cables used for the IPBL is standard CAT5 unshielded cable. It is assumed that installation
personnel know how to crimp these connectors to a cable.
4.2.1

Synchronization Cable

The maximum cable length between two IPBLs must not exceed 2000 meters.
1. Cut the cable to the correct length.
2. Connect the cable to a RJ45 modular jack. For information on pinning, see
pinning of the Sync IN cable, page 26
26.
3. Label the cable.
Sync IN
Figure 17. Connector pinning of the Sync IN cable
RJ45
modula r jack
1 2 3 4
Sync OUT
Figure 18. Connector pinning of the Sync OUT cable
RJ45
modula r jack
1 2 3 4
TD 92989EN / 25 January 2021 / Ver. E
and
5 6 7 8
Tx = Transmitter data pair
Rx = Reciever data pair
Sign = Signalling
5 6 7 8
Tx = Transmitter data pair
Rx = Reciever data pair
Sign = Signalling
Appendix A RFP Power Consumption,
Figure 18. Connector pinning of the Sync OUT cable, page
Installation of the IPBL
Figure 17. Connector
26
