INSTALLATION GUIDE
IP-DECT Base Station and IP-DECT Gateway
2.3.1

Overview

Figure 4. Overview of the IPBL
lan
1 2
1 2 3
Pos. Name
1 Reset
2 Status LED
3 Lan
4 Synchronization
5 Reference
6 Base station 01-16
2.3.2

Power Supply

The power supply are located at the rear of the IPBL. The IPBL can be powered using the following
alternatives:
• 110/230 VAC (only IPBL IP-DECT Gateway VAC/VDC)
• 48 VDC
For more information, see
Software
The software in the IPBL can be updated by downloading new software without disconnecting the
equipment. The new software is stored in flash memory. For information on how to update the software in
the IPBL, see the applicable Installation and Operation Manual for the IPBL.
2.3.3

LED indication

Status LED
Not lit
Flashing slow green
TD 92989EN / 25 January 2021 / Ver. E
base s tation
synchr oni zation refer ence
ring in ring out in out
4 5
Function
Resets the IPBL. For information on how to use the reset button, see
the applicable Installation and Operation Manual for the IPBL.
Indicates the status on the IPBL.
10BASE-T/100BASE-T Ethernet interface.
LAN1 port must be used in the IP-DECT system (LAN2 port is for
administration only).
Note: This is not applicable when RSTP is used. For information about
RSTP, see the applicable Installation and Operation Manual for the
device.
Sync ring in and sync ring out interfaces.
Reference sync in and reference sync out interfaces.
ISDN U DECT base station interfaces.
PN
4.3 Power the IPBL, page
01 02 03 04 05 06 07
09 10 11 12 13 14 15
6
27.
Description
Not powered, status is not defined.
When pressing the reset button.
Description
08
16
8
