Trotec SL400 Operating Manual page 5

Display
15
16
UNDER
MAX MIN FAST SLOW
34
33
32
DATE
31
REC dBA
30
FULL dBC
29
28 27
No. Designation
15 UNDER indication (i.e. fallen below measuring range)
16 MIN indication
17 FAST indication
18 OVER indication (i.e. measuring range exceeded)
19 SLOW indication
20 Indication of the scale's maximum value
21 Display of the measuring scale
22 TIME indication
23 Measurement value display
24 AUTO indication
25 HOLD indication
26 dBA / dBC indication
27 FULL indication (memory full)
28 REC indication
29 Battery status indication
30 Automatic switch-off indication
31 DATE indication
32 Time / date display
33 Indication of the scale's minimum value
34 MAX indication
EN
18
17
OVER
TIME
AUTO
HOLD
26
25
digital sound level meter SL400
Connections
19
20
21
22
23
24
No. Designation
35 Connection for the power adapter (DC 9 V)
36 Mini USB port
37 3.5 mm jack *
38 Setscrew for calibration
* e.g. to connect a frequency analyser or recorder
35
36
37
38
