- Page 1 OPERATION MANUAL HIGH FREQUENCY POKER VIBRATOR TYPES LHF & HS LIEVERS HOLLAND Groot Mijdrechtstraat 68 – 3641 RW Postbus 103 - 3640 AC Mijdrecht (NL) Tel.: 0031 – (0)297-231900 / Fax: 0031 – (0)297-231909 E-mail: info@lieversholland.nl / Internet: www.lieversholland.nl...
-
Page 2: Table Of Contents
Bouwmachinefabriek Lievers B.V. Bouwmachinefabriek Lievers B.V. may not be held responsible for any guarantees or liabilities for the contents of this publication and points to, in this case, all implied securities for suitability of merchantability or any other purposes. -
Page 3: Preface
All damage to parts of the poker vibrator, occurring within 12 months after date of purchase as a consequence of material , production or construction defects, will be replaced by Lievers as soon as possible. Lievers declines all responsibility for unsafe situations, accidents and damage caused by: ... -
Page 4: Safety
2. Safety Explanation of the used safety symbols Read the instruction manual Safety glasses, safety helmet and ear protection compulsory. Vibration reducing glove with GELFÔM compulsory. Safety shoes with extra protection compulsory. Before opening remove the plug. Dangerous electric voltage Be careful. -
Page 5: Restrisk
Check the feeder cable’s outercasing and if in use extension lead’s outercasing before you connect the machine to the electrical mains. The outercasing may not be damaged. Replace the cable if you cannot read the marks on the outercasing anymore. ... -
Page 6: Technical Specifications
3. Technical specifications LHF/HS 36mm 36mm 50mm 50mm 57mm 57mm 65mm Short long Short long Short long Voltage 42V/200Hz 42V/200Hz 42V/200Hz 42V/200Hz 42V/200Hz 42V/200Hz 42V/200Hz Current consumption 4,5A 4,5A 6,7A 9,5A 11,5A 13,5A Vibr/Min 12.000 12.000 12.000 12.000 12.000 12.000 12.000 Compaction diam. -
Page 7: Use
4. Use 4.1 Intended use Poker-vibrators LHF and HS are machines with a vibrating, steel bottle, for compacting concrete. 4.2 Operation AREFUL READ THE GENERAL AND SPECIFIC SAFETY INSTRUCTIONS BEFORE YOU SWITCH ON THE POKER VIBRATOR AREFUL FIRST SWITCH ON THE FREQUENCY CONVERTER BEFORE YOU SWITCH ON THE POKER VIBRATOR Switching on the poker-vibrator, compacting the concrete and switching off the poker vibrator. -
Page 8: Application
Fig. 4: Operation procedure during concrete compaction When work is done Put the switch in the OFF position and pull the supply-cable’s plug out of the socket. Switch off the converter and pull the plug out of the wall socket. After use, place the converter and poker vibrator on a dry and stable surface. - Page 9 Fig.5: Overview of the most important components LHF 1. Plug CEE 42V 200 Hz 2. Supply cable 10M 3. Switch 4. Operating hose 5. Inner cable 6. Pokerhead 42V 200Hz 7. Steel tip 8. Rubber tip Figure 6: Overview of the most important components HS 1.
-
Page 10: Maintenance
5. Maintenance 5.1. Maintenance Although the poker vibrators type LHF & HS have a few moving parts, regular maintenance promotes a long and trouble-free life. ARNING O NOT CLEAN THE POKER VIBRATOR WITH A HIGH PRESSURE CLEANER ISCONNECT THE ELECTRICAL SUPPLY TO THE POKER VIBRATOR BEFORE YOU CARRY OUT ANY MAINTENANCE ACTIVITIES TO THE POKER VIBRATOR 5.2. -
Page 11: Troubleshooting And Repairs
Take the poker-vibrator / converter for inspection to the nearest Lievers service- station. The activated poker-vibrator Defect converter or Check the voltage provided by the converter (read trips out regularly. -
Page 12: Dismantling, Disposal
Contact details Lievers Holland: PO Box 103 3640 AC Mijdrecht Tel: +31 (0)297-231900 Fax: +31 (0)297-231909 E-mail: info@lieversholland.nl Internet: www.lieversholland.com 7.Dismantling, disposal National and local regulations concerning dismantling and disposal of materials need to be obeyed. 12/20 Operation manual LHF / HS, revision 6: 22-12-2015... - Page 13 13/20 Operation manual LHF / HS, revision 6: 22-12-2015...
-
Page 14: Partlists
8. Part lists Fig. 7: Exploded view LHF 14/20 Operation manual LHF / HS, revision 6: 22-12-2015... - Page 15 Ø 36 Ø 50 Ø 57 Ø 65 Pos. Number Number Number Number Quantity Description 1300360011 1300500011 1300570011 1300650011 Steel tip 1300360020N 1300500020K n.a. n.a. Spring soucer n.a. n.a. 1300570020N 1300650020N Spring soucer 1300360030 1300500030 1300570030 1300650030 Bearing 1300360030 1300500030 1300570070 1300650070 Bearing...
- Page 16 Fig. 8: Exploded view HS 16/20 Operation manual LHF / HS, revision 6: 22-12-2015...
- Page 17 Tabel 4: Parts list HS Ø 36 Ø 50 Ø 57 Ø 65 Pos. Part number Part number Part number Part number Qty. Description 1300360011 1300500011 1300570011 1300650011 Steel tip 1300360012 1300500012 1300570012 13000650012 Rubber tip 1300360020N 1300500020K n.a. n.a. Spring soucer n.a.
- Page 18 Fig 9: exploded view pokerhead LHF/ HS Short execution 18/20 Operation manual LHF / HS, revision 6: 22-12-2015...
- Page 19 Table 5: parts list pokerhead LHF/HS bottle SHORT execution LHF / Ø 36 short Ø 50 short Ø 57 short Pos. Number Number Number Quantity Description 1300360011 1300500011 1300570011 Steel tip Rubber tip 1300360012 1300500012 1300570012 1300360020N 1300500020K n.a. Spring soucer n.a.
-
Page 20: Declaration Of Conformity
9. Declaration of conformity EC-DECLARATION OF AGREEMENT FOR MACHINERY (Directive 2006/42/EC, Annex II, under A) Supplier: Bouwmachinefabriek Lievers B.V. Address: Groot Mijdrechtstraat 68, 3641 RW Mijdrecht Hereby declares that The poker vibrators LHF en HS: 1) comply with the regulations for the Machine directive (Directive 2006/42/EC) , EMC-Directive (Directive...
