L.B. White Foreman CI230 Owner's Manual And Instructions

L.B. White Foreman CI230 Owner's Manual And Instructions

Ductable indirect fired oil heater

Advertisement

Quick Links

View this manual online at www.lbwhite.com
Attention
This heater has been tested
and evaluated by OMNI Test
Laboratories in accordance
with the requirements of CSA
B140.8-1967(R2015) and
UL 733-2019 and is listed and
approved as a ductable indirect
oil-fired forced-air construc-
tion heater with application
for the temporary heating of
buildings under construction,
alteration, or repair. CHECK
WITH YOUR LOCAL FIRE
SAFETY AUTHORITY, YOUR
FUEL GAS SUPPLIER, OR
THE L.B. WHITE COMPANY
IF YOU HAVE QUESTIONS
REGARDING APPLICATIONS
OR INSTALLATION.
www.lbwhite.com
SEE ASSEMBLY
INSTRUCTIONS
INSIDE
Please refer to important
elevation information on
inside cover.
WORLD PROVIDER - INNOVATIVE HEATING SOLUTIONS
411 Mason Street, Onalaska, WI 54650 • 800-345-7200 • 608-783-5691 • 608-783-6115 (fax) • www.lbwhite.com
Owner's Manual and Instructions
Foreman
Ductable Indirect-
Fired Oil Heater
Congratulations!
You have purchased the finest Indirect-fired construction heater
available. Your new L.B. White heater incorporates the benefits
from the most experienced manufacturer of heating products
using state-of-the-art technology.
We, at L.B. White, thank you for your confidence in our products
and welcome any suggestions or comments you may have...
contact us at 1-800-345-7200, or email us at
customerservice@lbwhite.com.
230,000 Btuh / 67.4 kW
CI230
500,000 Btuh / 146.54 kW
CI500
750,000 Btuh / 219.8 kW
CI750
#1 / #2 Fuel Oil
Report No: 0545HH002S
SCAN THIS
with your smartphone or
visit http://goo.gl/nvneR
to view maintenance
videos for L.B.White heaters.*
* Requires an app like QR Droid
for Android or for iPhone
