Always make certain that any required approvals are obtained in writing. DO NOT ACCEPT VERBAL APPROVALS, THEY ARE NOT VALID. NexWatch never recommends using the PW-5000 or related products as a primary warning or monitoring system. Primary warning or monitoring systems should always meet local fire and safety code requirements.
Page 5
United States protect all information in this document or in the software product itself. NOTICE Any use of this product is subject to the terms and acceptance of the NexWatch Software Agreement. Please request a copy from NexWatch, and review the agreement carefully.
Customer shall immediately notify NexWatch in writing of all such claims. NexWatch shall defend or settle such claims and shall indemnify and hold Customer harmless for any costs or damages including reasonable attorneys’...
All Products sold or licensed by NexWatch include a warranty registration card which must be completed and returned to NexWatch by or on behalf of the end user in order for NexWatch to provide warranty service, repair, credit or exchange. All warranty work shall...
Confidentiality All software, drawings, diagrams, specifications, catalogs, literature, manuals and other materials furnished by NexWatch relating to the design, use and service of Products shall remain confidential and shall constitute proprietary rights of NexWatch, and Customer agrees to treat such information as confidential. Customer shall acquire no rights in the design of Products or the related materials except to use such information solely for the purpose of and only during the time it sells Products.
PW5K2ENC1 / PW5K2ENC2 Description The PW-5000 system is designed for maximum efficient use of wall space through the use of a secure metal cabinet (PW5K2ENC1/PW5K2ENC2) that can hold up to nine modules, a 4 amp power supply (PW5K2E1PS) and a self-contained replaceable backup battery.
1. Measure and install four mounting screws with heads smaller than .4" [0.01016 m] using proper techniques for the material on which the PW-5000 is being mounted. Use a rectangular screw pattern 12.1" [0.30734 m] H x 16" [0.40640 m] W. Leave the screws exposed approximately 1/2"...
PW-5000 Enclosure PW5K2ENC1 & PW5K2ENC2 Installation Guide 6. CHECK ALL CONNECTIONS PRIOR TO POWERING UP THE ENCLOSURE AND PANELS. 7. The remainder of the panels can be manually wired for power and RS-485 communications using 18 AWG wire. The wires will be daisy-chained from one panel to the next so the power and the communications are wired in parallel.
PW-5000 Enclosure PW5K2ENC1 & PW5K2ENC2 Installation Guide 4. Watchman tour 5. Fire alarm supervision (N/A) PROWATCH is not certified for fire alarm supervision 6. Burglar alarm supervision 7. Industrial supervision 8. Other supervisory services NOTE: 2 and 3 may have equal priority: 5 and 6 may have equal priority &...
Installation Guide PW-5000 Enclosure PW5K2ENC1 & PW5K2ENC2 8. Launch the User Interface.The database should now be programmed to accommodate the PW5K1IC panel and accompanying I/O boards. Refer to the PROWATCH Installa- tion Manual for additional detail. The programming should continue until the system is fully functional and communications have been established.
PW-5000 Enclosure PW5K2ENC1 & PW5K2ENC2 Installation Guide 6. Click Next. Change the Server to match the name of the LOCAL PC. The database should be selected as PWNT from that Server. (The destination database). 7. Click Next. Select Transfer objects and data between SQL Server database.
Installation Guide PW-5000 Enclosure PW5K2ENC1 & PW5K2ENC2 Redundant Test Examples NOTE: Stop watch needed for all three test examples. Example #1 1. Use the MAIN PC’s OFF button to shut it down. Turn on the REDUNDANT PC and start the stop watch.
PW-5000 Enclosure PW5K2ENC1 & PW5K2ENC2 Installation Guide Conduit Knockouts 3/4” Top: Bottom: Right Side: Left Side: Power Supply Enclosure Switch Position: CAUTION: De-energize unit prior to servicing. 24VDC = SW1 OPEN For continued protection against fire hazard replace 12VDC = SW1 CLOSED fuse with the same type and rating 3.5A, 250V...
Installation Guide PW-5000 Enclosure PW5K2ENC1 & PW5K2ENC2 Installation Installation Instructions 1. Install the PW5K1E5PS (Altronix AL400ULX) power supply and battery enclosure per the supplied instructions. 2. Measure and install four mounting screws with heads smaller than .4" (1cm) using proper techniques for the material on which the PW5K2ENC1 or PW5K2ENC2 is being mounted.
500' (152 m) Alarm input points NC 2221-BR 2000' (610 m) Relay outputs NC 1821-OR twisted pair, shielded 2000' (610 m) NOTE: For Plenum rated cable just add a “P” to NexWatch part number prefix; for example NC1861-BL becomes PNC1861-BL TD1151 rev1101...
