- Page 1 PW-5000 Remote Enclosure Installation Manual Part Number: PW5K1ENC3 TD1125 rev1101...
-
Page 3: Table Of Contents
Product Liability; Mutual Indemnification..............6 Unpacking Procedure ................... 6 Shipping Instructions .................... 6 Limited Warranty ....................7 Confidentiality ..................... 7 PW-5000 Remote Enclosure .................. 8 Description ......................8 Dimensions ......................8 Conduit Knockouts ....................8 Power Supply ....................... 9 LED Diagnostics....................9 Backup Power Supply ................... -
Page 4: Warnings And Cautions
Always make certain that any required approvals are obtained in writing. DO NOT ACCEPT VERBAL APPROVALS, THEY ARE NOT VALID. NexWatch never recommends using the PW-5000 Series or related products for use as a primary warning or monitoring system. Primary warning or monitoring systems should always meet local fire and safety code requirements. - Page 5 States protect all information in this document or in the software product itself. NOTICE Any use of this product is subject to the terms and acceptance of the NexWatch Software Agreement. Please request a copy from NexWatch, and review the agreement carefully.
-
Page 6: Disclaimer
Customer shall immediately notify NexWatch in writing of all such claims. NexWatch shall defend or settle such claims and shall indemnify and hold Customer harmless for any costs or damages including reasonable attorneys’... -
Page 7: Limited Warranty
All Products sold or licensed by NexWatch include a warranty registration card which must be completed and returned to NexWatch by or on behalf of the end user in order for NexWatch to provide warranty service, repair, credit or exchange. All warranty work shall... -
Page 8: Pw-5000 Remote Enclosure
PW-5000 Remote Enclosure Description The PW-5000 Remote Enclosure allows for a variety of system configurations. It can be used in combination with the PW5K2ENC1, for example to place modules closer to the doors they control. Or it can be used alone to house modules for a smaller system. -
Page 9: Power Supply
Installation Guide PW-5000 Remote Enclosure—PW5K1ENC3 Power Supply DO NOT USE POWER SUPPLY TO POWER LOCKS - 12 VDC 2 amp continuous power limited output with backup battery charging and battery supervision. - A 16.5 VAC 20 VA wall transformer is provided. -
Page 10: Pw-5000 Remote Enclosure
Installation Guide PW-5000 Remote Enclosure—PW5K1ENC3 PW-5000 Remote Enclosure 14.725 7.850 .975 11.875 9.020 13.385 6.840 4.660 9.300 .4975 LEFT SIDE .930 .760 14.940 BACK 16.015 16.015 1.700 1.700 13.675 13.675 11.875 11.875 13.985 13.985 9.020 9.020 6.840 4.660 4.660 .990... -
Page 11: Installation Instructions
This enclosure can mount two full size PW-5000 panels OR one full size panel, one PW5K1R1 single reader panel and one PW5K1MX8 multiplexer panel. -
Page 12: Installation Diagram 2
Installation Guide PW-5000 Remote Enclosure—PW5K1ENC3 Installation Diagram 2 AC AC TD1125 rev1101... -
Page 13: Cable Specifications
500' (152 m) Alarm input points NC 2221-BR 2000' (610 m) Relay outputs NC 1821-OR twisted pair, shielded 2000' (610 m) NOTE: FOR PLENUM RATED CABLE JUST ADD A “P” TO NEXWATCH’ PART NUMBER PREFIX; FOR EXAMPLE NC1861-BL BECOMES PNC1861-BL TD1125 rev1101... -
Page 14: Nci Cable Part Numbers
Installation Guide PW-5000 Remote Enclosure—PW5K1ENC3 NCI Cable Part Numbers Part Number Description Application Length NC1841-GY 18 AWG/4 conductor reader cable 1,000' NC1861-BL-500 18 AWG/6 conductor reader cable 500' NC1861-BL 18 AWG/6 conductor reader cable 1,000' NC18121-YL-500 18 AWG/12 conductor keypad cable... - Page 16 Your Access to the Future 47102 Mission Falls Court • Fremont, CA 94539 USA Tel (510) 360-7800 • Fax (510) 360-7820 www.nexwatch.com...
