- Page 1 Last updated: 2020-10-29 C2000-RSDD-CK-CK31 User Manual 3 * RS485 ⇋ 1 * RS485 Serial-to-Ethernet Device — Serial-to-Serial Converter SinoCon Co., Ltd.
-
Page 2: Table Of Contents
C2000-RSDD-CK-CK31 User Manual Catalog Catalog 1. Hardware Description 1.1. Specifications 1.2. Apprearance 1.3. Indicators 1.4. Port Description 1.5. Product Dimensions 1.6. Installation Method 2. Package Contents 3. Warranty Policy SinoCon Co., Ltd. www.sinoconsys.com 2 / 12... - Page 3 Copyright Notice ©2000 - 2020 SinoCon Co., Ltd. All Rights Reserved. Trademarks The KonNaD logo is a registered trademark of SinoCon Co., Ltd. All other trademarks or registered marks in this manual belong to their respective manufacturers. Disclaimer This document only provides information about KonNaD products. No license to any intellectual property rights is granted by this document, including any intellectual property licenses, expressed or implied, or by any means.
- Page 4 C2000-RSDD-CK-CK31 User Manual SinoCon Co., Ltd. www.sinoconsys.com 4 / 12...
-
Page 5: Hardware Description
C2000-RSDD-CK-CK31 User Manual 1. Hardware Description 1.1. Specifications Classification Parameter Specification Ethernet No. of Ports Bandwidth 10/100M Communication Distance 100m Industrial Protocols TCP/IP Downstream Serial Serial Standard RS485 Port No. of Ports Connector Terminal block Cascade Connection/Transparent Bidirectional transparent Transmission... - Page 6 C2000-RSDD-CK-CK31 User Manual Classification Parameter Specification Installation Wall Environmental Operating Temperature -40℃ ~ 85℃ Limits Storage Temperature -60℃ ~ 125℃ Ambient Relative Humidity 5% ~ 95% RH, non-condensing SinoCon Co., Ltd. www.sinoconsys.com 6 / 12...
-
Page 7: Apprearance
C2000-RSDD-CK-CK31 User Manual 1.2. Apprearance SinoCon Co., Ltd. www.sinoconsys.com 7 / 12... -
Page 8: Indicators
C2000-RSDD-CK-CK31 User Manual 1.3. Indicators Classification Indicator Description Meaning Ethernet LINK Network Steady on：Network connection enabled status Flashing：Transmit or receive data indicator Off：The network port is not plugged into the network cable 10/100Mbps Steady on：100M network connected indicator Off：Not connected to the 100M network... -
Page 9: Port Description
C2000-RSDD-CK-CK31 User Manual 1.4. Port Description Recommended Classification Port Description wiring Ethernet Ethernet RJ45 Ethernet port CAT-5e DEBUG PORT +、-、 RS485 debug port positive, RS485 debug port RVSP 2*0.5 negative, GND Reserved GND、 Reserved port PP2、 GND、 Power Input Used for reliable grounding of the device, surge RVV 2*0.5... -
Page 10: Product Dimensions
C2000-RSDD-CK-CK31 User Manual 1.5. Product Dimensions unit: mm（inch） 1.6. Installation Method SinoCon Co., Ltd. www.sinoconsys.com 10 / 12... - Page 11 C2000-RSDD-CK-CK31 User Manual 2. Package Contents Contents Device * 1 Terminal block * 1 set Installation guide card * 1 SinoCon Co., Ltd. www.sinoconsys.com 11 / 12...
-
Page 12: Warranty Policy
C2000-RSDD-CK-CK31 User Manual 3. Warranty Policy In the normal use of the products you purchased, free warranty service will be provided from the date of purchase whenever the quality problems caused by raw materials or production process are concerned. However, due to the user's failure to install, disassemble or improperly use the product according to the requirements of this product manual, the company provides maintenance services, but charges appropriate maintenance fees.
