- Page 1 Last updated: 2019-12-13 C2000-A2-SDX6000-CX1 User Manual RS485 ← 6AC AC 90-275V Remote I/O Module — AC Digital Input Module SinoCon Co., Ltd.
-
Page 2: Table Of Contents
C2000-A2-SDX6000-CX1 User Manual Catalog Catalog 1. Hardware Description 1.1. Specifications 1.2. Apprearance 1.3. Indicators 1.4. Port Description 1.5. Product Dimensions 1.6. Installation Method 2. Package Contents 3. Warranty Policy SinoCon Co., Ltd. www.sinoconsys.com 2 / 11... - Page 3 Copyright Notice ©2000 - 2019 SinoCon Co., Ltd. All Rights Reserved. Trademarks The KonNaD logo is a registered trademark of SinoCon Co., Ltd. All other trademarks or registered marks in this manual belong to their respective manufacturers. Disclaimer This document only provides information about KonNaD products. No license to any intellectual property rights is granted by this document, including any intellectual property licenses, expressed or implied, or by any means.
- Page 4 C2000-A2-SDX6000-CX1 User Manual SinoCon Co., Ltd. www.sinoconsys.com 4 / 11...
-
Page 5: Hardware Description
C2000-A2-SDX6000-CX1 User Manual 1. Hardware Description 1.1. Specifications Classification Parameter Specification AC Input AC Channels Connector Terminal block AC Type Wet contact Channel-to-Channel Isolation 1500Vrms Acquisition Frequency 1kHz Logic Logic 0: ≤ 75VAC, Logic 1: 90~275VAC Upstream Serial Port Serial Standrad RS485 No. -
Page 6: Apprearance
C2000-A2-SDX6000-CX1 User Manual 1.2. Apprearance SinoCon Co., Ltd. www.sinoconsys.com 6 / 11... -
Page 7: Indicators
C2000-A2-SDX6000-CX1 User Manual 1.3. Indicators Classification Indicator Description Meaning AC Input AC input Steady on：Input voltage more than the threshold voltage indicators (90VAC) Off：Input voltage less than the threshold voltage (90VAC) Downstream RS485 data Steady on：RS485 line fault, please check if the positive... -
Page 8: Port Description
C2000-A2-SDX6000-CX1 User Manual 1.4. Port Description Recommended Classification Port Description wiring AC Input L、N AC live wire, AC neutral wire Upstream Serial +、- RS485+, RS485- (upstream) RVSP 2*0.5 Port Power Input V+、 Power supply input positive, power supply input RVV 2*1.0... -
Page 9: Product Dimensions
C2000-A2-SDX6000-CX1 User Manual 1.5. Product Dimensions unit: mm（inch） 1.6. Installation Method SinoCon Co., Ltd. www.sinoconsys.com 9 / 11... - Page 10 C2000-A2-SDX6000-CX1 User Manual 2. Package Contents Contents Device (contain mounting kit) * 1 Terminal block * 1 set Installation guide card * 1 SinoCon Co., Ltd. www.sinoconsys.com 10 / 11...
-
Page 11: Warranty Policy
C2000-A2-SDX6000-CX1 User Manual 3. Warranty Policy In the normal use of the products you purchased, free warranty service will be provided from the date of purchase whenever the quality problems caused by raw materials or production process are concerned. However, due to the user's failure to install, disassemble or improperly use the product according to the requirements of this product manual, the company provides maintenance services, but charges appropriate maintenance fees.
