- Page 1 Last updated: 2020-11-26 C2000-C2-SHK0401-BB1 User Manual 1 * RS485 + 1 * RS232 ⇋ 4 * RS485 Serial-to-Ethernet Device — Serial-to-Serial Converter SinoCon Co., Ltd.
-
Page 2: Table Of Contents
C2000-C2-SHK0401-BB1 User Manual Catalog Catalog 1. Hardware Description 1.1. Specifications 1.2. Apprearance 1.3. Indicators 1.4. Port Description 1.5. Product Dimensions 1.6. Installation Method 2. Package Contents 3. Warranty Policy SinoCon Co., Ltd. www.sinoconsys.com 2 / 12... - Page 3 Copyright Notice ©2000 - 2020 SinoCon Co., Ltd. All Rights Reserved. Trademarks The KonNaD logo is a registered trademark of SinoCon Co., Ltd. All other trademarks or registered marks in this manual belong to their respective manufacturers. Disclaimer This document only provides information about KonNaD products. No license to any intellectual property rights is granted by this document, including any intellectual property licenses, expressed or implied, or by any means.
- Page 4 C2000-C2-SHK0401-BB1 User Manual SinoCon Co., Ltd. www.sinoconsys.com 4 / 12...
-
Page 5: Hardware Description
C2000-C2-SHK0401-BB1 User Manual 1. Hardware Description 1.1. Specifications Classification Parameter Specification Serial Interface Optical isolation True Downstream Serial Serial Standard RS485 Port No. of Ports Connector Terminal block Cascade Connection/Transparent Bidirectional transparent Transmission transmission Baud Rate 1200~115200bps Upstream Serial Port Serial Standrad RS485/RS232 No. - Page 6 C2000-C2-SHK0401-BB1 User Manual Classification Parameter Specification Environmental Operating Temperature -40℃ ~ 85℃ Limits Storage Temperature -60℃ ~ 125℃ Ambient Relative Humidity 5% ~ 95% RH, non-condensing SinoCon Co., Ltd. www.sinoconsys.com 6 / 12...
-
Page 7: Apprearance
C2000-C2-SHK0401-BB1 User Manual 1.2. Apprearance SinoCon Co., Ltd. www.sinoconsys.com 7 / 12... -
Page 8: Indicators
C2000-C2-SHK0401-BB1 User Manual 1.3. Indicators Classification Indicator Description Meaning Downstream COMx RS485 data Steady on：RS485 line fault, please check if the Serial Port receive/transmit positive and negative poles of 485 line are indicators reversed Flashing：RS485 receiving/transmitting data Off：RS485 no receiving/transmitting data Downstream RS232 Steady on：RS232 line fault，please check if the data receive... -
Page 9: Port Description
C2000-C2-SHK0401-BB1 User Manual 1.4. Port Description Recommended Classification Port Description wiring Power Input ㊉ → ㊀ Power supply input positive, power supply RVV 2*1.0 input negative V+、V- Power supply input positive, power supply RVV 2*1.0 input negative Upstream Serial +、- RS485+, RS485- (upstream) RVSP 2*0.5 Port... -
Page 10: Product Dimensions
C2000-C2-SHK0401-BB1 User Manual 1.5. Product Dimensions unit: mm（inch） 1.6. Installation Method SinoCon Co., Ltd. www.sinoconsys.com 10 / 12... - Page 11 C2000-C2-SHK0401-BB1 User Manual 2. Package Contents Contents Device (contain mounting kit) * 1 Terminal block * 1 set Installation guide card * 1 SinoCon Co., Ltd. www.sinoconsys.com 11 / 12...
-
Page 12: Warranty Policy
C2000-C2-SHK0401-BB1 User Manual 3. Warranty Policy In the normal use of the products you purchased, free warranty service will be provided from the date of purchase whenever the quality problems caused by raw materials or production process are concerned. However, due to the user's failure to install, disassemble or improperly use the product according to the requirements of this product manual, the company provides maintenance services, but charges appropriate maintenance fees.
