- Page 1 S e r v i c e M a n u a l NOTE This manual is related to the following Equipment: Suction Pump F-18 / F-36 F-20 / F-40 Doc : Service Manual - F-18-36-20-40 Rev. 1 del 20 SEP 2005 Page 1 di 12...
- Page 2 (e.g. operators or maintenance staff). Doc : Service Manual - F-18-36-20-40 Rev. 1 del 20 SEP 2005 Page 2 di 12...
- Page 3 36 LT/MIN 18 LT/MIN 36 LT/MIN ASPIRATION VENT FUSE 1 X 1,6A 250V 1 X 1,6A 250V 1 X 1,6A 250V 1 X 1,6A 250V Doc : Service Manual - F-18-36-20-40 Rev. 1 del 20 SEP 2005 Page 3 di 12...
- Page 4 ANTIBACTERIAL/HYDROPHOBIC FILTER (DISPOSABLE) SHOULD ACCESSORIES BE USED OTHER THAN THOSE SUPPLIED BY FAZZINI S.R.L., YOU MUST MAKE SURE THAT THEY HAVE THE SAME CHARACTERISTICS AS THE ORIGINAL ONES. NOTE: THE SUPPLIED JARS ARE NOT MEANT TO BE USED AS MEASURERS, AND PROVIDE ONLY AN INDICATION OF THE CONTAINED QUANTITY.
- Page 5 BEFORE CARRYING OUT ANY CHECK DUE TO MALFUNCTIONING OR ANOMALIES, CALL THE FAZZINI S.R.L. TECHNICAL SERVICE OR PERSONNEL QUALIFIED BY FAZZINI S.R.L. FAZZINI S.R.L. DOES NOT OFFER ANY WARRANTY ON APPLIANCE THAT UPON INSPECTION BY THE TECHNICAL SERVICE SHOWS SIGNS OF TAMPERING.
- Page 6 Jar drive to the filter Silicone tube to the patient Jar drive to the patient Suction catheter CH 14 Main switch Vacuum regulator Vacuum gauge Doc : Service Manual - F-18-36-20-40 Rev. 1 del 20 SEP 2005 Page 6 di 12...
- Page 7 S e r v i c e M a n u a l General assembly – F-18 / F-36 SP.32.05 – Single head 230V motor (for F-18) SP.32.01 – Double head 230V motor (for F-36) Doc : Service Manual - F-18-36-20-40 Rev. 1 del 20 SEP 2005 Page 7 di 12...
- Page 8 Jar drive to the filter Silicone tube to the patient Jar drive to the patient Suction catheter CH 14 Main switch Vacuum regulator Vacuum gauge Doc : Service Manual - F-18-36-20-40 Rev. 1 del 20 SEP 2005 Page 8 di 12...
- Page 9 S e r v i c e M a n u a l General assembly – F-20 / F-40 SP.32.05 – Single head 230V motor (for F-20) SP.32.01 – Double head 230V motor (for F-40) Doc : Service Manual - F-18-36-20-40 Rev. 1 del 20 SEP 2005 Page 9 di 12...
- Page 10 Functional layout Feeding wire (Blue) Feeding wire (Brown) Feeding wire (Blue) Feeding wire (Brown) IEC double pole switch IEC Power inlets Feeding 50/60 Hz Doc : Service Manual - F-18-36-20-40 Rev. 1 del 20 SEP 2005 Page 10 di 12...
-
Page 11: Pneumatic Circuit
S e r v i c e M a n u a l Pneumatic circuit Catheter to the patient Suction regulator Non rebeathing valve Filter Pump / Motor Vent Doc : Service Manual - F-18-36-20-40 Rev. 1 del 20 SEP 2005 Page 11 di 12... -
Page 12: Correcting Malfunctions
Internal tubing are choked Open the equipment and verify internal tubing bends Open the equipment ,disconnect the tubing and check Pump fault the pump Doc : Service Manual - F-18-36-20-40 Rev. 1 del 20 SEP 2005 Page 12 di 12...
