Meyer Lot Pro 41760 Assembly Instructions Manual

Central hydraulics

Advertisement

Quick Links

Form No. 1-1240
April 2022
Assembly Instructions
Central Hydraulics
Includes: 41760
18513 Euclid Ave. • Cleveland, Ohio 44112-1084
© 2022 Printed in the U.S.A.
www.meyerproducts.com
Phone 216-486-1313

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lot Pro 41760 and is the answer not in the manual?

Questions and answers

Summary of Contents for Meyer Lot Pro 41760

  • Page 1 Form No. 1-1240 April 2022 Assembly Instructions Central Hydraulics Includes: 41760 18513 Euclid Ave. • Cleveland, Ohio 44112-1084 © 2022 Printed in the U.S.A. www.meyerproducts.com Phone 216-486-1313...
  • Page 2: Table Of Contents

    NOTICE: Meyer Products LLC reserves thje right, under its continuing product imporvement program, to change construction, design, details, specifications, and prices without notice or without incurring any obligation. Meyer Products LLC assumes no responsibility for installations not made in accordance with these instructions.
  • Page 3: Black Iron Parts Lists

    Black Iron Parts List...
  • Page 4 Black Iron Parts List Item Part Description Item Part Description 41710 Pkg: DE SOS E73 7.5-9.0 41292X • Accessory Box 05818 Lift Ram 1.75 x 8” 07178 •• Trip Spring 05887 •• Ram (1-1/2” x 10”) 23067 •• Nite Saber LED Kit 11859 •...
  • Page 5: Moldboard Parts List

    Moldboard Parts List Item Part No. Part No. Part No. Part No. Description 7’ 6” 8’ 8’ 6” 9’ 09400 09401 09402 09403 Moldboard Assembly 09797 09133 09134 07259 • Cutting Edge 08486 --------- --------- --------- • Bolt C 1/2-13 x 1-3/4 & Locknut (Kit of 9 each) --------- 08692 08692...
  • Page 6: Plow Assembly & Adjustments

    Plow Assembly & Adjustments Adjustable Clevis Adjustable Clevis Trip Spring Adjustment Trip Spring Adjustment The 14700 adjustable clevis The 14700 adjustable clevis is now standard with all Standard Operating Sys- Attach Eye Bolts to Moldboard and Trip Springs to Pivot Bar, making certain tem black iron packages.
  • Page 7: Mounting Plow

    Mounting Plow NOTE: NOTE: Pictures may vary based on model A. Pull vehicle into plow E. E. Remove crankstand assembly and push plow from a-frame. assembly forward an inch or two. B. B. Twist handles on both sides to engage spring loaded pins.
  • Page 8: Dismounting Plow

    Dismounting Plow A. Push lift arm down until there is slack in the chain. E. E. While slightly pushing the lift frame towards vehicle pull handles on either side to disengage pins then twist until the leg locks the pin in the open position. B.
  • Page 9: Pre-Delivery Inspection

    PRE-DELIVERY INSPECTION Vehicle Make: Vehicle Model: Vehicle Year: Vehicle VIN#: Vehicle FGAWR: Installing Company: Hydraulic Serial Number: Moldboard Serial Number: All bolts torqued to specification Plow Operation Up Clevis height Suspension interference Plow Operation Left Clevis height in inches Plow Operation Right Trip springs adjusted Plow Operation Down Lift Chain Adjusted...
