Meyer EZ-Mount Classic Operation And Maintenance Manual

Snow plows
Hide thumbs
Table of Contents

Advertisement

Quick Links

SNOW PLOWS
Operation and Maintenance Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZ-Mount Classic and is the answer not in the manual?

Questions and answers

Related Manuals for Meyer EZ-Mount Classic

Summary of Contents for Meyer EZ-Mount Classic

  • Page 1 SNOW PLOWS Operation and Maintenance Manual...
  • Page 2 • Minimum 70 Amp Battery or larger (550 C.C.A.) the storm hits, your Meyer Snow Plow will be ready and you will • Mud and Snow Tires know how to plow like a pro. DO NOT EQUIP ANY VEHICLE WITH •...

  • Page 3: Table Of Contents

    Meyer Registration Card Back Cover SAFETY FIRST Meyer Products recommends that this manual be read cover to cover so that you are completely aware of all important safety recommendations. Record your E-58H Serial Number and Moldboard Serial Number. These serial numbers are printed on the E-58H unit decal and on the back of the Moldboard on the part number decal www.meyerproducts.com...

  • Page 4: Get To Know Your Ez-Mount Plus Snow Plow

    ARM SHOULD BE REMOVED FROM VEHICLE WHEN SNOW PLOW IS REMOVED. 4. Trip Springs Allow moldboard to trip forward and ride over obstructions, this 13. Meyer Nite Saber Snow Plow Lights ® protects the snow plow, vehicle, and operator. Complies with the Federal Motor Vehicle Safety Standards.
  • Page 5 Blue E-58H (14)
  • Page 6 CRANKSTAND STORAGE Storage of the Crankstand is the responsibility of the To store Crankstand on the Lift Frame slide the tube that is operator. The stand can be stored on the lift frame in the attached to the side of the Crankstand over the receiver tube on retracted position to the driver’s side transport tube or inside the driver’s side of the Lift Frame.
  • Page 7 DETACHING THE COMPLETE ASSEMBLY the top of the Lift Frame towards the truck locking the pins to Leave control switch in lower float position and push down on the clevis frame. Remove the Crankstand from the A-frame by the Lift Arm. Disconnect the electrical plug and slip on weather removing the chained locking pin.
  • Page 8 Removal (back) (front) Pull, then rotate blue pins on both sides of Lower Plow to float position and manually Remove crankstand from storage truck into locked out position. The vehicle push lift arm down. Disconnect the electrical position on the side of mount and is now free from mount and may safely connection.
  • Page 9 Attachment Drive into assembly until contact is made Return crankstand to storage position and Rotate blue pins until engaged and push reattach the electrical connection. The and push assembly a few inches forward. top of lift frame towards truck until pins mount is now securely attached to the click in place.
  • Page 10 High quality steel—positions moldboard straight across, or angle COLLISION, LIFT ARM SHOULD BE REMOVED FROM right or left. VEHICLE WHEN SNOW PLOW IS REMOVED. 6. Pivot Pin 13. Meyer Nite Saber Lights ® Pin that attaches moldboard to sector. Complies with the Federal Motor Vehicle Safety Standards.
  • Page 11 RECEIVER TUBE LIFT FRAME ADJUSTING BOLT A-Frame Sector King Bolt SECTOR TO A-FRAME ASSEMBLY Weather Cap Runner...
  • Page 12 Removing Moldboard and Lift Frame Assembly 1. Be sure moldboard is on ground! The chain can have a small amount of tension to help support the back of the A-Frame. At this time use a wood block to slide under the back of the A-Frame to support and maintain level position for reattaching.
  • Page 13 ADJUSTING CHAIN FOR PROPER SLACK WHEN PLOWING SNOW 1. Be sure moldboard is on ground and A-frame is reattached at center hole in clevis frame. 2. Be sure lift piston is fully retracted. 3. Hold chain taut and choose the third link above lift arm, place that link in lift arm locking groove.

  • Page 14: Models Of Meyer Snow Plow Moldboards

    TRIMLINE SERIES Models TM-6, TM-6.5 Models TMP-6.5, TMP-7 6’, 6 1/2’, 7’, 7 1/2’ Diamond Blade For 4x4 Down Sized Pickups For Down Sized Pickups For Skid-Steer and Sport Utility Vehicles and Sport Utility Vehicles Vehicles STEEL MOLDBOARD SPECIFICATIONS MAX POLYETHYLENE SPECIFICATIONS STEEL MOLDBOARD SPECIFICATIONS SNOW PLOW MODEL TM-6...
  • Page 15 STANDARD SERIES Models STP-7, STP-7.5 Models ST-7, ST-7.5, STL-7.5 For 4x4 Standard Duty Pickups For 4x4 Standard Duty Pickups and Sport Utility Vehicles and Sport Utility Vehicles NOTE: STP-7 standard with 2 trip springs. NOTE: ST-7 standard with 2 trip springs. MAX POLYETHYLENE SPECIFICATIONS STEEL MOLDBOARD SPECIFICATIONS SNOW PLOW MODEL...
  • Page 16 CONTRACTOR SERIES Models C-7.5, C-8, C-8.5, C-9 Models CP-7.5, CP-8, CP-8.5, CP-9.0 For 4x4 Heavy Duty 3/4 ton, 1 ton Pickups, For 4x4 Heavy Duty 3/4 ton, 1 ton Pickups, and 1 ton Cab Chassis and 1 ton Cab Chassis STEEL MOLDBOARD SPECIFICATIONS MAX POLYETHYLENE SPECIFICATIONS SNOW PLOW MODEL...
  • Page 17 HEAVY MUNICIPAL SERIES Models HM-9, HM-10 Models HMP-10 For trucks with a G.V.W. of 16,000 to 27,000 For trucks with a G.V.W. of 16,000 to 27,000 STEEL MOLDBOARD SPECIFICATIONS MAX POLYETHYLENE SPECIFICATIONS SNOW PLOW MODEL HM-9 HM-10 SNOW PLOW MODEL HMP-10 MOLDBOARD LENGTH 9’...
  • Page 18 HEAVY MUNICIPAL SERIES Model HML-10 Aggressor Models AGP-10, AGC-10 For Chevy/GMC trucks model HD3500 and 4500/5500 For vehicles up to 33,000 GVW and Ford F-450, F-550 SPECIFICATIONS SPECIFICATIONS SNOW PLOW MODEL AGP-10 AGC-10 SNOW PLOW MODEL HML-10 MOLDBOARD LENGTH 120” 120”...
  • Page 19 2 minutes. If the overload light is still illuminated after attempts to down arrow in short intervals. Holding down the down arrow will activate reset the switch have failed, contact your nearest authorized Meyer a float light located in the upper right corner of the control switch. This...
  • Page 20 Reset is accomplished by turning off the ignition switch or by turn- ing the power switch off momentarily and then back on. If the moni- tor light is still illuminated after attempts to reset the switch have failed, contact your nearest authorized Meyer Distributor for repairs.
  • Page 21 1. Keep windshield wipers, heaters and lights working. 2. Use emergency flasher lights for increased visibility and safety. Meyer offers as standard equipment quartz halogen snow plow lights for even brighter illumination. 3. Equip vehicles with chains where necessary.
  • Page 22 B. Always replace runners as soon as they start to and hoses of all hydraulic fluid. The complete hydraulic system wear through. should then be flushed out with Meyer Hydra-Flush before adding new Meyer Hydraulic Fluid. C. Adjust the runners to maintain cutting edge height 2.
  • Page 23 It is effective corrosion. for a maximum of one year. Always carry an extra quart of Meyer 6. Remove EZ Mount® lift frame module from vehicle. Liberally coat Hydraulic Fluid M-1 or equal fluids. Use of any inferior fluids will insides of clevis frame receiver tubes and ends of lift frame with void the Meyer warranty.

  • Page 24: Hydraulic Power Unit Diagnosis Charts

    ELECTRIC HYDRAULIC POWER UNITS These charts are intended to be used as an aid in diagnosing problems on Meyer Hydraulic Power Units. They are not a substitute for factory train- ing and experience. Be certain to read the General Information and Testing Tips sections before attempting any troubleshooting. Additional detailed information as well as all electrical schematics may be found in Service Manuals 1-822.
  • Page 25 Electric Hydraulic Power Unit Diagnosis Chart MODEL CONDITION POSSIBLE CAUSE CORRECTION Plow does not lift or lifts 1. Low hydraulic fluid level. 1. Add fluid to proper level Power slowly - motor operates. 2. Discharged battery. 2. Recharge battery. Angling 3.
  • Page 26 Electric Hydraulic Power Unit Diagnosis Chart MODEL CONDITION POSSIBLE CAUSE CORRECTION Motor does not operate. 1. Discharged or defective battery. 1. Recharge or replace battery. Power 2. Loose or corroded electrical connections. 2. Clean and tighten electrical connections. Angling 3. Inoperative starter solenoid. 3.

  • Page 27: Efficient Snow Clearance Starts With Planning

    Efficient Snow Clearance Starts with Planning PREPARING AREAS, USE OF GUIDE MARKERS KEEP SNOW UNDER CONTROL Every area to be plowed should be inspected before Deep or heavy, wet snow, because of its increased weight, calls snowfall for potential hazards. Holes should be repaired, for more skillful and powerful plowing than light powder snow.

  • Page 28: Plow With The Storm

    Plow with the Storm It is of utmost importance to remember one basic rule -- plow path, in the angled position, should exceed the tire track Always plow with the storm. Start plowing when snow is 1 by at least six inches on either side. Be sure to have enough to 4 inches deep, depending upon traffic or other limitations.

  • Page 29: Two Established Snow Clearance Plans

    Two Established Snow Clearance Plans These two snow plowing techniques have been time- and 3. Have vehicles and equipment inspected, fueled and ready. operation-tested. Use them as guidelines for most snow 4. Clear area by pushing snow first to sides of drives, around plowing strategies.

  • Page 30: Snow Plowing Tips From The Pros

    Snow Plowing Tips from the Pros SNOW PLOWING OPEN AREAS On a dirt or slag surface, drop moldboard to ground in straight position, then raise one inch or adjust runners for desired Open areas such as parking lots require a more serious clearance.
  • Page 31 STRAIGHT LINE SNOW PLOWING WIDE DRIVEWAY This method is most efficient for drives, streets, roads and 1. Make one pass down center walkways. Moldboard type blade snow plows mounted on with blade in straight position. utility vehicles or service trucks are best for such an operation. 2.
  • Page 32 Areas where there is little or no space for stacking cleared to the Snow Plow components or the vehicle that will not be covered under the Meyer Products Warranty Program. snow are considered “trapped.” An example is an area requiring full access from surrounding buildings. Snow...

  • Page 33: Minerals & Chemicals For Snow & Ice Control

    first, especially where snow may compact and adhere to the road surface, causing icy road conditions. When slush begins to stiffen and refreeze, it will be necessary to plow again and reapply ice melting materials. THE MEYER INSERT HOPPER SPREADER...

  • Page 34: Meyer Spreaders

    Also available in stainless steel and Mini Jr. (36006) direct drive. The Meyer Mini Jr (5.75cu.ft.) is an ideal solution for small and medium sized jobs: walkways, intersections, access ramps and parking lots. Mate XL (38000) The no rust thermoplastic hopper and internal vertical spiral auger The Meyer Mate XL spreader holds provide continuos and even flow of material.
  • Page 35 2.0 cu. yd. Stainles Steel will perform dozens of jobs while saving on labor, time and materials. The Meyer 1.8 & 2.0 cubic yard capacityV-box spreader Every municipality ,contractor, utility and construction company can for pickup trucks mountsand stores as a single unit.

  • Page 36: Meyer Accessories

    Meyer M-1 system operating at peak performance. It Hydraulic Fluid has additives that insure peak features special additives to ensure effi- efficient operation of all Meyer electric hydrau- cient operation. lic power units (15134). Hydra-Flush ®...
  • Page 37 The reversible cutting edge improves perfor- Lock Pin mance and durability. It also gives your plow Protect your Meyer Snow Plow components with this sturdy, an extra edge when cutting hard, packed snow durable stainless steel and brass lock pin. Available in two and ice.
  • Page 38 (see page 4 for further information). Nite Saber I lights are select styles and can easily be added standard equipment on new Meyer mounts. They have a to new or existing vehicles to increase slim profile and a strong light output.

  • Page 39: Genuine Meyer Parts

    MEYER GENUINE PARTS E-58H CUTTING EDGES - (STEEL) NUTS & BOLTS (STEEL) 09796 ST-7.5 / STP-7.5 / C-7.5 / CP-7.5 09104 TM-6.0 08486 SET OF 6 TM-SERIES 09133 C-8.0 / CP-8.0 09100 TM-6.5 / TMP-6.5 08184 SET OF 9 ST / C-SERIES 09134 C-8.5 / CP-8.5...
  • Page 40 RUBBER EDGES W/HARDWARE (CONT.) SNOWPLOW HARDWARE (CONT.) A-FRAMES FOR ST-6.5 / STP-7.5 08187 ST-6.5 08575 HINGE PIN W/COTTER (2) 13299 BRONCO/CJ/HAT 31” X 17 1/2” 08188 ST-7.0 / STP-7.0 10958 HINGE PIN (ONLY) HM-SERIES 13302 J-SERIES 72/78 37” X 17 1/2” 08189 ST-7.5 / STP-7.5 / C-7.5 / CP-7.5 08543...
  • Page 41 PIVOT BARS / SECTORS SNOW DEFLECTOR KITS POWER UNITS 12984 TM PIVOT BAR (POLYETHYLENE) 15995 E-58H UNIT ONLY 12326 SECTOR ST-6.5 / STP-7.5 FOR STEEL MOLDBOARDS MISC. POWER UNIT 12793 SECTOR C-7.5 / HM-10.0 12036 6.0 FT. LG. 15727 MOTOR (ISKRA) TWO TERMINAL E-58H 12037 6.5 FT.
  • Page 42 SWITCHES PAINT - TOUCH UP Meyer Products LLC 22154 TOUCH PAD 07026 BLACK AEROSOL (1) U.S. Patent Numbers 08583 FLOOR MOUNT BRACKET 08676 BLACK AEROSOL (12) 22690 PISTOL GRIP CONTROLLER 07027 SNO-FLO AEROSOL (1) YE 7,114,270 6,138,388 5,036,608 6,015,219 08677...
