HIGH-DEFINITION TELEVISION
BASIC OWNER'S GUIDE
MODELS
C9 Series
737 Series
837 Series
This manual provides basic connection, setup, and operating instructions.
Please visit our website at www. mitsubishi-tv.com to view or download a
detailed owner's guide that fully describes the features of this TV.
•
For questions:
»
Visit our website at www.mitsubishi-tv.com.
»
E-mail us at MDEAservice@mdea.com.
»
Call Consumer Relations at
•
For information on
•
To order replacement or additional remote controls or lamp cartridges, visit our website at
www.mitsuparts.com or call 800-553-7278.
837 Series. IR emitter cables are available for purchase from Mitsubishi. Request either
part number 242D483020 (two-ended cable) or part number 299P254020 (four-ended cable).
800-332-2119.
System Reset, please see the back cover.

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi WD-73837

Summary of Contents for Mitsubishi WD-73837

  • Page 1 HIGH-DEFINITION TELEVISION BASIC OWNER’S GUIDE MODELS C9 Series 737 Series 837 Series This manual provides basic connection, setup, and operating instructions. Please visit our website at www. mitsubishi-tv.com to view or download a detailed owner’s guide that fully describes the features of this TV. •...

  • Page 2: Fcc Declaration Of Conformity

    This TV meets ENERGY STAR® efficiency standards in all operating modes. Projection Television Receiver WD-60C9, WD-65C9, WD-73C9 WD-60737, WD-65737, WD-73737, WD-82737 WD-65837, WD-73837, WD-82837 Mitsubishi Digital Electronics America, Inc. 9351 Jeronimo Road Irvine, CA 92618-1904 (800) 332-2119 Reorient or relocate the receiving antenna.

  • Page 3: Table Of Contents

    Important Safety Instructions Remote Control ......TV Connector Panel Diagrams Connector Performance .

  • Page 4: Important Safety Instructions

    Important Safety Instructions Please read the following safeguards for your TV and retain for future reference. Always follow all warnings and instructions marked on the television. Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water.

  • Page 5: Remote Control

    Remote Control ACTIVITY Select a TV input to watch. GUIDE Displays ChannelView listings. MENU Displays the TV main menu. INFO Displays TV status and help. BACK Steps back one menu. VOLUME UP MUTE VOLUME DOWN Record/Playback controls for external devices (PAUSE) Freezes a broadcast TV picture.

  • Page 6: Tv Connector Panel Diagrams

    TV Connector Panel Diagrams Note: The number of inputs/outputs shown TV Panel diagram may vary from those on purchased model. Side connector panel Connector Performance BEST HDMI HDMI-to-DVI DVI/PC R–AUDIO–L AUDIO HDMI OUTPUT DIGITAL R–AUDIO–L AUDIO OUTPUT INPUT 3 Y/ VIDEO L–AUDIO–R HDMI 4 VIDEO QUALITY...

  • Page 7: Connecting Devices

    Connecting Devices Connecting with HDMI or DVI Required: 1. HDMI-to-HDMI cable OR 2. a. DVI-to-HDMI cable AND b. Left/Right Analog Audio cable DVI/PC INPUT R - AUDIO - L TV Panel TV Panel AUDIO OUTPUT HDMI HDMI DIGITAL Y/ VIDEO R - AUDIO - L DVI OUT Connecting with Composite Video...

  • Page 8: Connecting Antenna Or Cable Without A Box

    Connecting Antenna or Cable without a Box Antenna Cable TV service Direct cable (no cable box) DVI/PC INPUT TV Panel TV Panel R - AUDIO - L AUDIO Y/ VIDEO Y/ VIDEO Mitsubishi recommends using coaxial antenna cable instead of flat twin lead antenna wires for better performance.

  • Page 9: Customizing Device Setup

    Customizing Device Setup Auto Device Discovery Feature TV’s Easy Connect Automatic Device Discovery detects most connections automatically. Connect your device to the TV. TV displays the ‘New Device Found’ menu when the connection is detected automatically. To ensure best detection, power on HDMI devices before connection.

  • Page 10: Tv Channel Setup

    TV Channel Setup Memorizing Channels Use the Scan option in the Channel Management menu to locate and memorize all of the local channels from an antenna or from direct cable service (no cable box). MENU key to display menu. Press to open the Channel menu.

  • Page 11: Tv Menus

    TV Menus Menu Navigation Displays or clears the main menu. • Moves up one menu level. • Clears the current menu. • Navigation into a submenu • Selects an item. Move the highlight within menus. Make adjustments in some menus. Look for the key guide at the bottom of each menu.
  • Page 12 Adjust continued Displayed only if an A/V receiver or headphone connection has been detected: Turns on the internal TV speakers. Speak- Audio available from an A/V Receiver: Receiver. Head- Audio available from headphones. phones: No special audio effects from the Stereo: TV speakers.
  • Page 13 Adjust continued • To display 3D images, Mitsubishi Home Theater DLP TVs require that source devices support checkerboard display formats for 3D gaming or 3D cinema content. • A 3D standard format does not currently exist for Blu-Ray or DVD prepackaged media. •...

  • Page 14: Closed-Caption Settings

    Captions Closed-Caption Settings Initial Setup of TV Features • Provides choices and separate on/off controls for digital and analog captions. • Selects background color for analog captions. Selects settings for the appearance of digital closed captions. Choose either English or Spanish for TV menus. •...
  • Page 15 Initial continued Adding/Deleting Channels • Check mark indicates memorized channels. • Select and press ENTER to add / delete the channel from the memory. Use this menu to set a day and time for the TV to power on automatically. Select the input and channel to be used at Power-On.

  • Page 16: Input Management

    Inputs Input Management • Assign or change names of inputs appearing in the Activity menu. • Turn the Ant input On/Off (to display/hide in the Activity menu). • Delete unused HDMI inputs from the menu. For complete setup instructions, see the owner’s guide on the web.

  • Page 17: Controlling Tv Usage

    Lock Controlling TV Usage This feature restricts the access according to the U.S. based program ratings, the time of day or by the channels. Restricting the access using the non-U.S. based ratings (Alternate Rating System) can be setup from the ‘Other’ submenu.

  • Page 18: Usb Media Player Menu

    USB Media Player Menu • 837 Series only. • The TV can display photo or music files from a USB device. • Photos must be in JPEG format and music files in wma format. Connect your USB card reader or USB drive to the TV’s USB port located at the side panel.

  • Page 19: 3D Video

    3D Video This section provides Instructions for viewing 3D video using the TV’s 3D feature. The 3D options are found in the Adjust > 3D Mode menu. Initial Setup Check if your HDMI 3D video source device RS-232C outputs a 1080p 60 Hz signal. This information will be needed when you assign an input name in the New Device Found screen.

  • Page 20: Troubleshooting

    Troubleshooting General TV Operation Symptom A fan is running even while the TV is powered off. The fan gets louder after the TV is shut off. The TV remote control does not work. When I try to use the remote control, the POWER key blinks five times.
  • Page 21 TV Channels Symptom The TV takes several seconds to respond to channel changes. You cannot access a channel. When ChannelView list is displayed, informa- tion appears incomplete TV Power On/Off Symptom TV takes an excessively long time to power You cannot program the TV to turn on auto- matically (Timer function).
  • Page 22 Picture Symptom Picture does not look like a high-definition picture. TV has sound but no picture. Picture has become dimmer. There is a large black or gray rectangle on the screen. You cannot view a picture when playing a VHS tape. VCR or DVD player’s on-screen menus jitter up and down.
  • Page 23 Sound Symptom There is no sound even when the volume is turned up. The sound does not match the screen picture. The sound from my A/V receiver does not match the screen picture (I should hear the correct audio from my A/V receiver).

  • Page 24: Lamp-Cartridge Replacement And Cleaning

    Lamp-Cartridge Replacement and Cleaning CAUTION: If the television is on, press POWER to turn it off. Unplug the television and allow it to cool for at least one hour before attempting to replace the lamp cartridge. Lamp The light source for this television is a lamp, which is part of a lamp cartridge assembly.
  • Page 25 Lamp-Cartridge Replacement Removing the Old Lamp Cartridge Turn off TV power and allow the lamp to cool for at least one hour before proceeding. After the lamp has cooled, remove the cover of the lamp compartment, located on the back of the TV. Refer to figures 1 and 2.

  • Page 26: Warranty, Trademarks, And Licenses

    Mitsubishi DLP Projection Television Limited Warranty MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC. (“MDEA”) warrants as follows to the original purchaser of this television from an authorized MITSUBISHI Audio/Video Dealer, should it prove defective by reason of against defects arising from improper workmanship and/or material: a.

  • Page 27: Trademark And License Information

    or other factors beyond the reasonable control of MDEA, such as power surge damage caused by electrical system or lightning. This limited warranty also excludes service calls where no defect in the product covered under this warranty is found, service calls related to unsatisfactory audio or visual reception or signal unless caused by a defect in the product that is covered under this limited warranty, all costs, expenses or any other damages arising from product installation, or set-ups, any adjustments of user controls (including contrast, brightness, color, tint, fine tuning, sharpness), other adjustment necessary to prepare the unit for display or use, connection with any external audio receiver, antenna, cable...

  • Page 28: Mitsubishi Tv Software

    Mitsubishi TV Software END-USER LICENSE AGREEMENT FOR EMBEDDED SOFTWARE IMPORTANT – READ CAREFULLY: This License Agreement is a legal agreement between you (either an individual or an entity) and Mitsubishi Digital Electronics America, Inc. (MDEA) for all software pre installed and/or provided along with this television (“Software”). By utilizing this television and Software, you agree to be bound by the terms of this License Agreement.
  • Page 30 For questions, call Consumer Relations at remote controls, lamp cartridges or IR emitter cables, Visit our website www.mitsuparts.com © 2009 Mitsubishi Digital Electronics America, Inc. 853B710A10 Website: www.mitsubishi-tv.com E-mail: MDEAservice@mdea.com 800-332-2119 To order replacement or additional or call 800-553-7278 SYSTEM RESET If the TV does not respond to the remote control, control-panel buttons, or will not power on/off, hold power button for about 10 seconds.
