- Page 1 CH1900 Series CAN Bus Control Installation Manual . . . includes CP1200 Operator Panel MANINPBYM01 Revision 2.0...
- Page 2 The information contained in this manual is believed to be accurate at the time of going to print but no responsibility, direct or consequential, can be accepted for damage resulting from the use of this information. The manufacturers reserve the right to make changes, without notice, to any of its products. Page CH1900 Series Electronic Control Installation Manual...
-
Page 3: Table Of Contents
Contents Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Parts Supplied . -
Page 4: Overview
Overview The CH1900 Series Control and CP100 Operator Panel are designed to be used with the Yanmar electronic control system. This manual provides installation details of the control heads and operator interface panel. For installation of other electronic components, calibration, operation, and other technical information, refer to the Electronic Control System Installation and/or Operation Manual that is provided with each system. -
Page 5: Mounting Instructions
Mounting Instructions Mounting the Control Head Determine a Proper Mounting Location The CH1900 control heads are designed to be mounted on flat vertical surfaces on port and starboard sides of the operator helm. The controls are designed to mount on surfaces from ¾ inch (19 mm) to 1-1/4 inch (32 mm) thick. - Page 6 Mounting Instructions Installation Diagram Note: The port and starboard controls are unique. Each control head is clearly labeled at the end of each harness. Figure 2: Control Head Mounting Page 6 CH1900 Series Electronic Control Installation Manual...
- Page 7 Mounting Instructions Installation Instructions 1. Starting with either port or starboard control, locate the desired position of center of handle and cut a 1-/4 inch (45 mm) diameter through hole in the mounting surface. 2. Remove the spanner nut from the front of the control. Insert the controls threaded flange through the 1-3/4 inch hole from the inside.
-
Page 8: Operator Panel
Mount the Control Interface (see page 12 for diagram) While the CH67019D can be mounted horizontally or vertically, the preferred mounting is vertical with the connectors facing down. Page 8 CH1900 Series Electronic Control Installation Manual... -
Page 9: Connecting The Components
Connecting the Components Complete the installation by connecting components as shown in Fig. . Excess harness should be neatly coiled and secured with nylon ties. The components may have to be disconnected for service at some point during the boats lifetime, so leave at least 4 inches (10 cm) of clearance in all directions for releasing and removing their connectors. -
Page 10: Ch1900 Setup & Operation
After all controls and system components have been mounted and interconnected, the system must be set up to agree with the engines, transmissions, and operators preferences. For calibration, feature selection, and system operation, refer to the Electronic Control System Installation Manual. Page 10 CH1900 Series Electronic Control Installation Manual... -
Page 11: Cp1200 Operator Panel Template
CP1200 Operator Panel Template Page 11 © 2006 Teleflex Marine, Inc. -
Page 12: Ch67600 Control Interface Template
U.S. to Metric 4 inches = 101.6 mm 1.535 inches = 39 mm 5.217 inches = 132.5 mm .610 inches = 15.5 mm 4.677 inches = 118.8 mm 1.441 inches = 36 mm Page 1 CH1900 Series Electronic Control Installation Manual...
