JAC HFC7151M1V-U221B Workshop Manual page 8

3) Position sealant with the specified size.
■ Put the sealant into the groove for it (if any).
■ Generally, the sealant is put inside the bolt hole; however, it is occasionally put outside the bolt hole.
■ Install the matching part in a certain period of time after applying sealant.
■ Eliminate any dirt from the sealant.
■ Do not re-tighten the bolts or nuts after installation in order to avoid failures of bolts or nuts.
■ Add engine oil and coolant 30min after the installation has been finished.
Attention:
■ Conduct the operation in accordance with the instructions specified in this manual.
江淮汽车 部门：客户服务部
Fig.1.1.003
Mechanical Part of
Engine
