Q5VOIP SERIES MANUAL
QUANTUM Q5VOIP SERIES
Table of Contents Limitation of Liability
Products Limited Warranty
Limited Warranty Limits and Exclusions
CHAPTER 1 GETTING STARTED
CHAPTER 2 INSTALLATION AND WIRING DIAGRAM
General Wiring Diagram
CHAPTER 3 KEYPAD CORRELATION TABLE
CHAPTER 4 PROGRAMMING
Log-in to Programming Mode
Function Code 00: Change Master Code
Function Code 01: Add New Tenant Directory
file:///C|/PACH-CO.COM-2022-B/online_manual/q5voip_manual.htm[4/27/2022 8:54:09 AM]
PROGRAMMING MANUAL V04122022

TABLE OF CONTENTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q5VOIP Series and is the answer not in the manual?

Questions and answers

Related Manuals for Quantum Q5VOIP Series

Summary of Contents for Quantum Q5VOIP Series

  • Page 1: Table Of Contents

    Q5VOIP SERIES MANUAL QUANTUM Q5VOIP SERIES PROGRAMMING MANUAL V04122022 TABLE OF CONTENTS Table of Contents Limitation of Liability Function Code 23: Lock-out Count Function Code 24: Alarm Products Limited Warranty Function Code 25: Keypad Beep Function Code26: Door Beep Limited Warranty Limits and Exclusions...
  • Page 2 Pach and Company does not assume any liability for any damages, which may arise in installation or use of the Quantum Q5VOIP Series Pach and Company does not assume liability for any incompatibility between the Quantum Q5VOIP Series and users devices.
  • Page 3 Pach & Company thanks and congratulates you on the purchase of your Quantum Q5VOIP Series Telephone Entry Access Control Systems. The manual is designed to guide you through the proper programming and use of the Quantum Q5VOIP Series It is important for you to read and follow the manual completely.
  • Page 4 Q5VOIP SERIES MANUAL The Quantum Q5VOIP Series is residential intercom with 10 tenants capacity. It can be used for small appartment less than 10 tenants. Analog dial tone is supplied by AATA2 Capacity 10 tenants, 100 cards and 100 codes.
  • Page 5 Q5VOIP SERIES MANUAL 1. AC1 and AC2, Input Power 12VAC 40VA (supplied) or 12VDC 3.0A (not supplied). Measurement voltage under load must be 12.50-14.00 VAC (AC Transformer) or 13.50-14.00 VDC (DC power supply) 2. BAT and GND, Battery backup 12VDC 4.5Ahr.
  • Page 6 Q5VOIP SERIES MANUAL shown above on diagram. The LCD will display as below LCD Display OK --- Flash OK --- RTC OK --- DTMF OK --- INIT START --- INIT COMPLTE --- SCROLLING CHAPTER 3 Keypad Correlation Table The QR5 buttons are lighted. Below are the correlation table for each key.
  • Page 7 Q5VOIP SERIES MANUAL Log-in to programming Enter 00 then # 3. Enter new master code then press # Function code 01 - Add New Tenant Directory A tenant directory consists of directory code (2, 3 or 4 digits depending on the setup, see fucntion code 19), tenant's name and phone number.
  • Page 8 Q5VOIP SERIES MANUAL Enter tenant directory number to be edited then # Enter new name up to 16 characters then press # or press # keep the existing name Chapter 3 for keypad layout Enter the a new tenant phone number up to 16-digit then press # or press # to keep the existing phone number.
  • Page 9 Q5VOIP SERIES MANUAL Do the following: - Press 1 (to clear all directories) then press # - Press * to cancel Function Code 05 - Call Forwarding Enable or disable call. Default setting= 1 (enable). If 1 (disable) is selected, the system can't make calls Log-in to programming 2.
  • Page 10 Q5VOIP SERIES MANUAL Enter door 1 or 2, or 3 for both, then press # Enter time zone 1-3 then press # Enter 00 (24 hours) - 20 see function code 17 then press # Enter satellite system ID 0-7 (enter 0 if no satellite system connected to the main system) then press #...
  • Page 11 Q5VOIP SERIES MANUAL Log-in to programming Enter 07 then # Enter 1 to clear all access code then press # * to cancel Function Code 09 - Access Code Digit Log-in to programming Enter 09 then #| 3. Enter 4, 5, 6, 7 or 8 (default setting is 4 digit) then press #...
  • Page 12 Q5VOIP SERIES MANUAL Chapter 3 for keypad layout Enter name up to 16 characters then press # Enter door 1 or 2, or 3 for both then press # Enter time zone 1-3 then press # Enter 00 (24 hours) - 20 see...
  • Page 13 Q5VOIP SERIES MANUAL Repeat this step to delete another code Function Code 12 - Clear All Cards Log-in to programming Enter 12 then # Enter 1 to clear all keyfobs or cards press # or * to cancel Function Code 13 - Set Time...
  • Page 14 Q5VOIP SERIES MANUAL MM= Month DD= Date then press # Enter 0= Sunday, 1= Monday, 2= Tuesday, 3= Wednesday, 4= Thursday, 5= Friday, 6= Saturday then press # 5. Enter 0= NO Daylight Saving Zone (Hawaii, Indiana and Arizona) 1=Daylight Saving Zone...
  • Page 15 Q5VOIP SERIES MANUAL Enter 0= Delete the existing AUS the press # 1= Add AUS then press # Enter open time in military then press # Enter close time in military then press # Enter 0= Sunday, 1= Monday, 2= Tuesday, 3= Wednesday, 4= Thursday, 5= Friday, 6= Saturday then press # 8.
  • Page 16 Q5VOIP SERIES MANUAL Enter 0= Delete the existing time zone then press # 1= add new time zone then press # Enter start time in military then press # Enter end time in military then press # Enter 0= Sunday, 1= Monday, 2= Tuesday, 3= Wednesday, 4= Thursday, 5= Friday, 6= Saturday...
  • Page 17 Q5VOIP SERIES MANUAL 0= Delete the existing holiday zone then press # 1= add new holiday zone then press # 5. Enter month and date (i.e. 0704 for U.S.A Independence Day) then press # Return to step 3 to add more holiday zones.

  • Page 18: Function Code 23 Lock-Out Count

    Q5VOIP SERIES MANUAL AUXIN2 is used for input device such as postal lock, infrared sensor, exit button, etc.. AUXIN2 is associated with relay 2 Log-in to programming Enter 21 then # 3. Enter 0= disable (default setting) 1= Enable control by relay 2 open door interval, see...

  • Page 19: Function Code 24 Alarm

    Q5VOIP SERIES MANUAL Function Code 24 Alarm The system has a warning alarm if invalid code or card has been enter according to the setting on function code 23. Log-in to programming 2. Enter 24 then # 3. Enter 0= disable, 1=disable system for 60 seconds and local beep (default setting), 2= disable system for 60 seconds with...

  • Page 20: Function Code 28 Unlock Relay 1 Time

    Q5VOIP SERIES MANUAL The amount of time the visitor can talk to the tenant. The timer starts as soon as the system is offhook. Log-in to programming 2. Enter 27 then # 3. Enter 10-240 seconds then press # Function Code 28 Unlock Relay 1 Time The amount of time for relay 1 to trigger.

  • Page 21: Function Code 31 Call Forwarding Time

    Q5VOIP SERIES MANUAL Log-in to programming 2. Enter 30 then # 3. Enter 0= disable (default) pr 1= enable then press # Function Code 31 Call Forwarding Time Intercom call can be forwarded to an outside line (land line, cellular phone) between 15-60 seconds. The call forwarding time must be set shorter than your voice mail or answering machine answers time otherwise it will not work.
  • Page 22 Q5VOIP SERIES MANUAL 2. Enter 33 then # 3. Enter 0= delete existing temporary code or 1= add temporary code then press # 4. Enter code number 01-10 then press # Enter 4-8 digit code, see digit setting on function code 09...

  • Page 23: Function Code 34 Special Code

    Q5VOIP SERIES MANUAL Function Code 34 Special Code The code can be use to unlock hold (open hold) and use same code again to lock (close) door or gate. Up to 10 special codes can be programmed. Log-in to programming 2.

  • Page 24: Function Code 35 Temporary Card

    Q5VOIP SERIES MANUAL 10. Enter Sat ID 0-7 then press # (enter 0 if no satellite connected to the QR5) 11. Enter 0= no more additional time zone then press # and return to step 3 to program another temporary code...

  • Page 25: Function Code 36 Special Card

    Q5VOIP SERIES MANUAL 8. Enter time zone 1-3 then press # 9. Enter 00 (24 hours) - 20 see function code 17 then press # 10. Enter Sat ID 0-7 then press # (enter 0 if no satellite connected to the QR5) 11.

  • Page 26: Function Code 38 System Acknowledge

    Q5VOIP SERIES MANUAL 6. Present the card or fob in front of the black window, the system will register the card or fob 8-digit number printed then press # 7. Enter 1= relay 1(door 1), 2= relay 2 (door 2) or 3= both relay then press # 8.

  • Page 27: Function Code 39 Disable And Enable Remote Access

    Q5VOIP SERIES MANUAL Function Code 39 Disable and Enable Remote Access If no remote opening allow, disable it using this function code. Default setting is enabled. Log-in to programming 2. Enter 39 then # 3. Press 0= disable remote access...

  • Page 28: Function Code 42 Relay 2 Mode

    Q5VOIP SERIES MANUAL Function Code 42 Relay 2 Mode Relay 2 can be set to four different mode: 1= door control, 2= trigger simultaneously as relay 1, 3= alarm mode (see function code 24), 4= turn relay 2 on/off remotely (DTMF key7/6) Log-in to programming 2.
  • Page 29 Q5VOIP SERIES MANUAL 7. Enter 0= Sunday, 1= Monday, 2= Tuesday, 3= Wednesday, 4= Thursday, 5= Friday, 6= Saturday then press # Return to step 3 to program another time zone Function Code 44 Disable Time Zone Relay The system's relay can be disabled during certain time but the system is still in full operation. Maximum 10 disable time zones.
  • Page 30 Q5VOIP SERIES MANUAL Function Code 45 Relay 1 and 2 Unlock Timer Relay 1 and 2 can be unlock using count down timer 01-98 hours or 00=lock or 99= unlimited unlock hold. Log-in to programming 2. Enter 45 then # 3.
  • Page 31 Q5VOIP SERIES MANUAL 3. Enter 0= disable or 1= enable then press # 4. Enter the number to access dial tone to dial an outside line, generally 9 is the default number for most PBX system, then press # 5. Select delay time for the PBX system to access dial tone, generally 2-3 second delay is plenty of time, then press #...
  • Page 32 Q5VOIP SERIES MANUAL Function Code 51 Welcome Screen It consists of three segments and 16 characters for each segment Log-in to programming 2. Enter 51 then # 3. 1st segment, enter the characters then press # see Chapter 3 for keypad layout 4.
  • Page 33 5.4 Opening Door Using Card, Temporary Card, and Special Card The Quantum Q5VOIP Series has built-in card reader. The door can be access using UFOB, UCLAM or UISO. Card Standard Operation is used to open the door and door will be closed automatically, see...
  • Page 34 Q5VOIP SERIES MANUAL CHAPTER 6 QWCM Internet IP Module The QWCM Web Based module is included on Q5VOIP Series. Click here for QWCM manual DEFAULT SETTING QWCM IP: 192.168.1.230 SUBNET: 255.255.255.0 GATEWAY: 192.168.1.1 DNS: 192.168.1.1 USERNAME: Administrator PASSWORD: pach or 8888...
