Summary of Contents for AURES OLC 8.4
- Page 1 USER MANUAL VERSION V1.0a NOVEMBER 2009 OLC 8.4 Monitor...
- Page 2 Copyright 2009 All Rights Reserved Manual Version 1.0a Part Number: The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
- Page 3 Safety IMPORTANT SAFETY INSTRUCTIONS Read these instructions carefully. Save these instructions for future reference. Follow all warnings and instructions marked on the product. Do not use this product near water. Do not place this product on an unstable cart,stand,or table.The product may fall, causing serious damage to the product.
- Page 4 CAUTION ON LITHIUM BATTERIES Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. LEGISLATION AND WEEE SYMBOL 2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components.
- Page 5 Revision History Changes to the original user manual are listed below: Revision Description Date • Initial release 2009 November • Correct VGA cable with power connector 1.0a 2009 December • Correct power adpater...
-
Page 6: Table Of Contents
Table of Contents 1. Packing list ....... 1 1-1. Standard Checklist ..........1 2. System Review ......2 2-1. Front ................2 2-2. I/O Ports ..............3 2-3. Dimensions ..............3 3. On Screen Display ....4 4. Specification ......5... -
Page 7: Packing List
Note: If you connect the OLC8.4 Monitor to a Poseo 5200, you can use the power cable integrated in the VGA cable to provide power to the monitor. For use with other PCs, you need to use the provided AC adaptor to power the OLC 8.4. -
Page 8: System Review
System Review 211. Front Items Description Touch screen OSD Keypad (front left to right): • Power button for LCD monitor on / off • Left button for function adjustment purpose • Right button for function adjustment purpose • Select(Enter) button •... -
Page 9: I/O Ports
212. I/O Ports Items Description VGA Port Power Button DC-IN Jack 213. Dimensions 220 mm 41.4 mm... -
Page 10: On Screen Display
On Screen Display The OSD keypad locates in the rear cover of the monitor. Detail OSD funtion menu described as follows. OSD Keypad (front left to right): • Power button for LCD monitor on / off • Left button for function adjustment purpose •... -
Page 11: Specification
Specification Model Name OLC8.4 AD Board Name LCD Panel Panel Size 8.4" Brightness 250nits Resolution 800 * 600 External I/O Ports DC-in Jack Power button 1x Power button for LCD monitor on / off 1x Menu button to get into video setup mode OSD Button 1x Up/Down button for video function adjustment purpose 1x Exit button...
