The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be reproduced,translated to another language or stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission.
Table of Contents Usage Notice Precautions..........................1 Introduction About LCDSLIM 17’’ FP Series ....................2 Touch Screen for LCDSLIM 17’’ FP ................3 Package Overview .......................4 Installation Product Overview ......................5 Front View .......................5 Bottom View ......................5 Attaching the Side Brackets ..................6 Side Mount for Your Monitor ..................7 Sealing foam installation ....................9...
Usage Notice Warning - To prevent the risk of fire or shock hazards, do not expose this product to rain or moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit.
Introduction About LCDSLIM 17’’ FP Series The LCDSLIM 17’’ FP Series is a 17" flat panel screen with an active matrix, thin-film transistor (TFT) liquid crystal display (LCD). This unit is to be used as commercial and light industrial equipment only.
Package Overview LCD Display Power Cord VGA Signal Cable Remote Key USB Cable (A to B) DC Power Supply (sold separately) Touch Driver CD Bracket Screws Side Brackets...
Attaching the Side Brackets Depending on your mounting scheme, alternately, you may use the side brackets to mount your displays onto your wall or device. Find a suitable location for attaching side brackets. A. The left and right sides B. The Top and bottom sides Bracket Bracket Bracket...
Side Mount for Your Monitor This monitor can be mounted to the wooden or concrete wall with 4 screws and a pair brackets on the opposites. 1.0 mm 1.0 mm 186.0 mm 170.0 mm...
Page 11
Customer panel material: 1. Wooden wall: Ø4.5mm thru holes for M4 screws w/nuts, or no thru holes, screws for wood 4mm. 2. Sheet metal: concealed head threaded studs M4 w/nuts. RECOMMENDED CUSTOMER PANEL CUT-OUT RECOMMENDED CUSTOMER PANEL CUT-OUT (Front Mount Recommend gap size 2.0 mm) (Rear Mount Recommend gap size 1.5 mm) 404.0 mm 170.0 mm...
Sealing foam installation Sealing / Rear Mounting Sealing foam narrow side facing the glass surface (top) SEE DETAIL DETAIL A SCALE 4.000 Sealing / Front Mounting Sealing foam wide side facing the glass surface (top) SEE DETAIL DETAIL B SCALE 4.000...
Connecting the Display (Figure 10.1) To setup this display, please refer to the following figure and procedures. 1. Be sure all equipment is turned off. 2. Connect the DC adapter to the power connector on the monitor and the other end into an electrical outlet (10.1).
User Controls Back Panel Controls Icon Key Name MENU Menu MENU SELECT Down Enter SELECT Power Menu off status Menu on status MENU Menu appear Menu disappear / return to main item Brightness Main item select up / Adjust up Contrast Main item select down / Adjust down SELECT...
How to Use the OSD Menus Icon Key Name Menu MENU Down Enter SELECT Power 1. Press the “MENU” button to pop up the “on-screen menu” and press “Up” or “Down” button to select among the five functions in the main menus. 2.
On-Screen Display Menus Main OSD Menu: ITEM CONTENT Contrast The monitor luminance level control. Brightness The monitor backlight level control. Auto Adjust Fine-tune the image to full screen automatically. Left/Right Moving screen image horizontal position to left or right. Up/Down Moving screen image vertical position to up or down.
Appendix Troubleshooting If you are experiencing trouble with the LCD display, refer to the following. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. ► Check that all the I/O and power connectors are correctly and well connected described in the "Installation"...
Warning Signal If you see warning messages on your LCD screen, this means that the LCD display cannot receive a clean signal from the computer graphics card. Below are the three kinds of Warning Signal. Please check the cable connections or contact your local dealer or our service center for more information.
Compatibility Modes Mode Resolution H-Frequency(khz) V-Frequency(hz) IBM VGA 720X400 31.47 IBM VGA 640X480 31.47 Apple MacII 640X480 35.00 VESA VGA 640X480 37.86 VESA VGA 640X480 37.50 VESA SVGA 800X600 35.16 VESA SVGA 800X600 37.88 VESA SVGA 800X600 48.08 VESA SVGA 800X600 46.88 Apple Mac...
Touch Screen Driver Installation The LCDSLIM 17’’ FP is available with USB connections. The touch driver is located on the enclosed CD-ROM for these operating systems: Windows® 7/8, VISTA, XP, 2000, CE, XP Embedded, Linux Kernel 2.6.x (32 bit & 64 bit), Apple® Mac OS. (Windows 7/8 Multi touch...
Optional Calibration Tool Install: Calibrating the touch screen in Windows 7/8: 1. Tap the Start button, Control Panel and then Hardware and Sound. 2. Under Tablet PC Settings, tap Calibrate the screen for pen or touch input. 3. On the Display tab, under Display options, tap Calibrate and then Yes to allow the program to make changes.
Driver Install Instructions: If you are using a PC running Windows® 7/8, VISTA, XP, 2000, follow the instructions below: 1. Power on the PC. 2. Be sure the USB cable is connected from the PC to the LCD display. 3. Open the CD-ROM. 4.
