MAGNUM SPEEDLITE
MAGNUM SPEEDLITE
Aputure BEG Market
2012.06
MG- - 68TL
MG
68TL

Advertisement

loading
Need help?

Need help?

Do you have a question about the MAGNUM SPEEDLITE MG-68TL and is the answer not in the manual?

Questions and answers

Related Manuals for Aputure MAGNUM SPEEDLITE MG-68TL

Summary of Contents for Aputure MAGNUM SPEEDLITE MG-68TL

  • Page 1 MAGNUM SPEEDLITE MAGNUM SPEEDLITE MG- - 68TL 68TL Aputure BEG Market 2012.06...

  • Page 2: Product Introduction

    It has TTL control, 4 sec recycle time, an external power port enabling 2 sec recycle, precise brightness control, 5 flash modes, optical sensor, power saving mode, PC sync port. Whatever your flash lighting needs, take aim with the Aputure Magnum Speedlite and gun'am down.

  • Page 3: Main Features

    Main Features： GN 48 GN 48 Five Flash Mode（ （ TTL/M/ Five Flash Mode TTL/M/ /S1/S2) /S1/S2) Precise Brightness Adjustment Precise Brightness Adjustment Optical Sensor Optical Sensor Fast Recycling Fast Recycling PC Sync Port PC Sync Port PC Sync Port PC Sync Port External Power Port External Power Port...
  • Page 4 1. GN 48 1. GN 48 MAGNUM Speedlite MG-68TL is measured at GN48 when in ISO100, 105mm. GN48 makes MG-68TL GN48 makes MG-68TL speedlite flash much stronger and cover much farther.
  • Page 5 2. Five Flash Mode 2. Five Flash Mode Aputure Magnum Speedlite MG-68TL has five flash modes including TTL/M/ /S1/S2. Press <MODE>, MG-68TL will be switched between the five modes. Stroboflash Stroboflash S1 Mode S1 Mode S2 Mode S2 Mode M Mode...
  • Page 6 TTL Mode TTL Mode TTL stands for through-the-lens, a way of measuring light levels through the lens on the camera. It can effectively determine the correct flash brightness output. When using TTL mode, camera should be set to <M>, <AV>, or <TV> Mode.
  • Page 7 Stroboflash Mode Stroboflash Mode In this mode, MG-68TL fires rapidly to capture multiple exposures of fast moving subjects in a single image. For example, it can be used to capture every detailed motion when a capture every detailed motion when a basketball player shoots the ball.
  • Page 8 M/S1/S2 Mode M/S1/S2 Mode While on the camera MG-68TL can work as MG-68TL can also work as hot shoe, MG-68TL will an off-camera auxiliary an off-camera auxilliary flash flash when you press flash. When the master while shooting your master flash in TTL mode.
  • Page 9 3. 3. Precise Brightness Adjustment MG-68TL has precise brightness adjustment. Press “left” and “right” buttons to adjust the brightness. In TTL mode, press the left or right button to adjust the exposure from -3 to +3 in 1/3 stops. stops. In Stroboflash, the brightness can be adjusted amongst 1/128, 1/64, 1/32, 1/16, 1/8 and 1/4.
  • Page 10 4. Optical Sensor Sensor The optical sensor plays an important role in flash lighting. For example, multi-flash and bounce flash applications. As an optical slave, MG-68TL can be triggered remotely as an auxiliary be triggered remotely as an auxiliary flash. Multi-flash lighting: The flash radio signals can be reflected by the walls of the room.
  • Page 11 5. Fast Recycling 5. Fast Recycling MG-68TL only takes 4 seconds to recharge to full brightness. Get more shots and save more time with fast recharging.
  • Page 12 6. PC Sync Port 6. PC Sync Port MG-68TL includes PC sync port which enables the flash at the camera’s maximun flash sync speed if triggered by the Trigmaster.

  • Page 13: External Power Port

    MG-68TL normally recycles in 4 seconds. But when connecting to an external power source, such as Aputure's external battery adaptor (AP- EBN), and triggered by the camera or the trigmaster ,it can recycle to full the trigmaster ,it can recycle to full...

  • Page 14: Power Saving Mode

    8. Power Saving Mode 8. Power Saving Mode MG-68TL will enter power saving mode automaticly when no operation in 50 seconds. This reduces power consumption, saving more energy for shooting.
  • Page 15 9 9 . Setting Recall . Setting Recall MG-68TL saves the parameters last used when powering off and back on again. There is no need to remenber and set everything all over again. No worry about the trouble when mistake No worry about the trouble when mistake in operation, take greater efficiency.0...
  • Page 16 10. Overheating Protection . Overheating Protection MG-68TL will enter protection mode to protect the flash from damage when it flashes too frequently. When using continuous flash, output brightness should be set below ¼ . brightness should be set below ¼ .
  • Page 17 1 1 1 1 . Detailed LCD Display . Detailed LCD Display MG-68TL features a high definition LCD display that shows all relevant settings. The high quality LCD is clear and easy to see, and has low power consumption.
