Master Operating Instructions
secuENTRY Home
ENTRY 5000 CYL
BURG-WÄCHTER KG
Altenhofer Weg 15
58300 Wetter
Germany
www.burg.biz
Contents index
en
English
en
Further languages at:
www.burg.biz
Foreword
Dear Customer,
Thank you very much for deciding on the secuENTRY 5000 CYL.
The system was developed in Germany according to the most
modern technical capabilities and fulfils the latest high safety
requirements.
The secuENTRY 5000 CYL electronic cylinder can be easily
installed in any door with a profile cylinder lock, up to a door
thickness of 118 mm (59/59 mm, measured in the centre of the
forend screw). No drilling or laying of cables is required and it
is ideally suited for both new installations and retrofitting. The
secuENTRY 5000 CYL can be fitted to house and interior doors.
The secuENTRY 5000 CYL is setup and operated using the free
smartphone app secuENTRY KeyApp
less, the cylinder uses the modern Bluetooth 5.2 standard.
*
Alternatively, the cylinder can also be operated via the PIN keypad ENTRY 7711
Keypad PIN or the radio key ENTRY sE-Key 7713 (both available separately).
The secuENTRY KeyApp, however, is always required for the setup.
!
Important:
Please read the entire operating instructions before you
start the installation.
We hope you enjoy your new locking system!
2
*
. The transmission is wire-

Advertisement

Table of Contents
loading

Related Manuals for Burg Wächter secuENTRY Home ENTRY 5000 CYL

Summary of Contents for Burg Wächter secuENTRY Home ENTRY 5000 CYL

  • Page 1 Contents index English Further languages at: Master Operating Instructions www.burg.biz secuENTRY Home ENTRY 5000 CYL Foreword Dear Customer, Thank you very much for deciding on the secuENTRY 5000 CYL. The system was developed in Germany according to the most modern technical capabilities and fulfils the latest high safety requirements.

  • Page 2: Set Contents

    Set contents secuENTRY 5000 CYL commissioning To setup the secuENTRY 5000 CYL, you ENTRY Home 5000 CYL Cylinder secuENTRY must first download the secuENTRY KeyApp Forend screw KeyApp. This can be found in the App Store and Google Play Store (Fig. 3). Hexagon spanner SW2 Fig.
  • Page 3 A prompt will appear asking you to Change administrator code scan the QR code provided using your smartphone camera. The QR code is on Proceed as follows to delete a cylinder: the sticker enclosed in the packaging (see small fig.). Open the main menu (Fig.

  • Page 4: Delete Cylinder

    Delete cylinder Create user and assign access medium There are various access media available to open your door. Including opening with a user-defined Proceed as follows to delete a cylinder: code , the sE-Key radio key and the KeyApp itself. Open the main menu (Fig.
  • Page 5 Enter the first name and surname of the Create user – Radio key sE-Key user you wish to register (I) (Fig. 30). Note: The radio key "ENTRY sE-Key 7713" This section allows you to set up a user is available separately from specialist code, a radio key sE-Key or another retailers.
  • Page 6 Smartphone A: Create user – KeyApp as an electronic key The QR code displayed on smartphone The KeyApp allows you to open the lock with the help of another smartphone. The installation B can now be scanned via the app on has two different options for this method of opening: smartphone A.
  • Page 7 Smartphone A: Option 2: CSV file Temporarily store the file received Smartphone B: from smartphone B on smartphone A. The file can be deleted again after First, download the secuENTRY KeyApp programming. and register. Tap on "CSV" in the user menu at the Open the main menu (Fig.
  • Page 8 Changing the user access medium Changing the user access medium - User code Proceed as follows if you wish to Delete the entry of the relevant line change an opening medium assigned and, if required, enter a new user- to a user: defined code (I) (Fig.

  • Page 9: Delete User

    Changing the user access medium - KeyApp as electronic radio key Programming/updating the cylinder Tap the relevant line (Fig. 60) to delete The cylinder must be programmed the entry. accordingly so that the registered users can now open the lock with the stored A message will then appear prompting opening options.
  • Page 10 Select the cylinder for which you have As soon as the programming has been set up changes (I) (Fig. 69). completed successfully, you will receive a corresponding feedback. Confirm the Note: If you have several cylinders and name with "OK" (Fig. 75). have created changes for each, please only select the cylinder within the Blue- If the process failed, repeat the steps...
  • Page 11 After retrieval, a confirmation message Reading out the log file/history appears, which you confirm with "OK" (Fig. 85). An entry is automatically created in a log file, the history, for every opening or Go back one step in the menu and tap closing process.
  • Page 12 From inside the door, push the cylinder secuENTRY 5000 CYL installation into the mortise lock (Fig. 93). The installation of the secuENTRY 5000 CYL is explained below. Prior to installation, please read the installation instructions carefully. Remove the existing door lock cylinder by loosening the forend screw in the door and pulling out the cylinder with Fig.
  • Page 13 Battery status display and replacing the batteries Compatibility with other secuENTRY products Whether for one front door, several doors or a complete locking system: Simply configure your The battery status is shown on the dis- individual unit with the secuENTRY modular system . play each time a secuENTRY cylinder is activated via the KeyApp (Fig.

  • Page 14: Warranty

    Warranty Notes In order to deliver a flawless and high quality product to you and to better assist you in case of service or repair, it is necessary that faulty or defective devices along with the valid administrator code and the QR code(s) be presented to your dealer together with the original documentation. When returning goods due to your right of withdrawal, all parts of the appliance must also be in their factory settings.
  • Page 15 ENTRY HOME ENTRY 5000 CYL BURG-WÄCHTER KG Altenhofer Weg 15 58300 Wetter Germany www.burg.biz www.burg.biz...
