1. Insert lower end tube assemblies (part 5)
with caster weld nuts facing down into low-
er tube assemblies (part 4). Adjust to size of
clamp being used and fasten four knob screw
(part 7) into lower tube assembly.
Assembly Instructions
1
Model no. 316111
Part
Decription
1
Upper tube assembly
2
Upper end tube assembly
3
End caps
4
Lower tube assembly
5
Lower end tube assembly
6
Locking caster
7
Knob screw
8
Non-locking caster
9
Wrench
Qty
2
2
8
2
2
2
10
2
1
Advertisement
Related Manuals for Global Industrial 316111
Summary of Contents for Global Industrial 316111
- Page 1 Mobile Plan Center Model no. 316111 Assembly Instructions Part Decription Upper tube assembly Upper end tube assembly End caps Lower tube assembly Lower end tube assembly Locking caster Knob screw Non-locking caster Wrench 1. Insert lower end tube assemblies (part 5) with caster weld nuts facing down into low- er tube assemblies (part 4).
- Page 2 2. Screw casters (part 6 and part 8) into lower end tube assembly and tighten with wrench (Part 9). 3. Insert upper end tube assemblies (part 2) into upper tube assemblies (part 1). Adjust to size of clamp being used. Fasten four knob screws (part 7) into upper tube assembly (part 1).
