Installation Manual:
RoofGuard RoofStep Ladder Series
RoofGuard RoofStep Crossover Series
Gargoyle Ladder Series
Gargoyle Crossover Series
This Installation Manual is intended to meet the Manufacturer's Instructions requirements and should be used as part of
an employee training program.
WARNINGS AND CONDITIONS
These instructions must be provided to the installer of this system. The installer must read and understand these
instructions and follow.
Failure to follow these instructions or the details of the unique layout drawing provided may result in serious injury or
death. If you have any questions about this system's use or care, please contact the manufacturer: 1-800-977-2005.
RoofStep Ladder Series Systems, RoofStep Crossover Series Systems, Gargoyle Ladder Series, Gargoyle
Crossover Series Manual RGC-RS
Guardrail System
Model Numbers:
RoofStep 5x5 XS, RoofStep 5x4 XS,
RoofStep 5x3 LD, RoofStep 5x2 LD,
RoofStep 5x1 LD, RoofStep 4x4 XS,
RoofStep 4x3 LD, RoofStep 4x2 LD,
RoofStep 4x1 LD, RoofStep 3x3 XS,
RoofStep 3x2 LD, RoofStep 3x1 LD
Advertisement
Related Manuals for Liftsafe Fall Protection RoofStep Series
Summary of Contents for Liftsafe Fall Protection RoofStep Series
- Page 1 Guardrail System Model Numbers: RoofStep 5x5 XS, RoofStep 5x4 XS, RoofStep 5x3 LD, RoofStep 5x2 LD, Installation Manual: RoofStep 5x1 LD, RoofStep 4x4 XS, RoofStep 4x3 LD, RoofStep 4x2 LD, RoofGuard RoofStep Ladder Series RoofStep 4x1 LD, RoofStep 3x3 XS, RoofGuard RoofStep Crossover Series RoofStep 3x2 LD, RoofStep 3x1 LD Gargoyle Ladder Series...
-
Page 2: Table Of Contents
Table of Contents Component Identification............2 Typical Layout (Crossover Series)..........3 Typical Layout (Ladder Series)..........4 Ladder Assembly (STEP 1)............5 Platform Assembly (STEP 2)............6 Diagonal Bracing for Crossover Series (STEP 3a).......7 Tie-back for Upper Level of Ladder Series (STEP 3b)....8 Post/Base Connection...............9 IMPROPER USE OR INSTALLATION OF THIS EQUIPMENT MAY CAUSE WARNING INJURY OR DEATH Failure to Read, Understand, and Follow the Installation Manual may result in injury or death... -
Page 3: Component Identification
Figure 1 - Component Identification Failure to Read, Understand, and Follow the Installation Manual WARNING may result in injury or death... -
Page 4: Typical Layout (Crossover Series)
Figure 2A - Typical Layout - Crossover Series Typical Layout • Install on a flat (5-degrees or less), clean, dry surface, only when the change in elevation between roof levels is 2 feet or less. • Ladder support posts must be 6’ (2.4m) from any parallel fall hazard/edge. •... -
Page 5: Typical Layout (Ladder Series)
Figure 2B - Typical Layout - Ladder Series Typical Layout • Install on a flat (5-degrees or less), clean, dry surface, only when the change in elevation between roof levels is over 2 feet (one side is > 2 feet above the other). •... -
Page 6: Ladder Assembly (Step 1)
Figure 3 - Ladder Assembly - STEP 1 Ladder Assembly - STEP 1 • Position RGF-145 just above 3rd rung or as shown in system specific drawing, before securing all needed rungs. • Ensure all rungs are facing the same direction. •... -
Page 7: Platform Assembly (Step 2)
Figure 4 - Platform Assembly - STEP 2 Ladder Assembly - STEP 2 • Align ladder sections facing each other and connect the platform to the back of the top rung on each side, using supplied bolts. • Slide fittings / handrails onto posts to complete connecting the two sides. •... -
Page 8: Diagonal Bracing For Crossover Series (Step 3A)
Figure 5 - Diagonal Bracing for Crossover Series - STEP 3a Diagonal Bracing for Crossover Series - STEP 3a • Set screws in all fittings should be tightened to approximately 18 ft-lbs. If torque wrench is not available, tighten set screw until it contacts pipe, then tighten one more full revolution. •... -
Page 9: Tie-Back For Upper Level Of Ladder Series (Step 3B)
Figure 6 - Tie-back for Ladder Series - Upper Level - STEP 3b Tie-back for Ladder Series - STEP 3b • Set screws in all fittings should be tightened to approximately 18 ft-lbs. If torque wrench is not available, tighten set screw until it contacts pipe, then tighten one more full revolution. •... -
Page 10: Post/Base Connection
Figure 7 - Post/Base Connection - Diagonal Bracing and Tie-back Post/Base Connection - Diagonal Bracing and Tie-back • Post into base – diagonal brace or tie-back – two baseplates. • Post may be installed in any of the 3 holes to prevent tripping or positioning base near existing features. •... - Page 11 IMPROPER USE OR INSTALLATION OF THIS EQUIPMENT MAY CAUSE WARNING INJURY OR DEATH Failure to Read, Understand, and Follow the Installation Manual may result in injury or death DO NOT lean on the railing DO NOT stand or climb on the railing DO NOT use rail as a tie-off point DO NOT use rail for lifting or hoisting DO NOT install railing within 10-feet of any electrical lines...
- Page 12 Factory Supply Liftsafe Fall Protection 8001 Tower Point Drive 409 Harmony Road Charlotte, NC 28227 Ayr, Ontario N0B 1E0 1(888) 242-3045 1(800) 977-2005 sales@factorysupply.com info@liftsafeinspections.com www.factorysupply.com www.fallsafetysolutions.com...
