- Page 1 User Instruction Guide for RoofGuard Classic RGC-UM RGC-TB Liftsafe Fall Protection Inc. RoofGuard Classic Instruction Manual RGC-UM-3.3...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Section Page Number 1.0 Application 2.0 System Requirements 3.0 Components 4.0 System Layout 5.0 Installation 6.0 Add-On Toe-Board Kit 7.0 Detailed Inspection and Maintenance Log 8.0 Warranty 9.0 Notes... - Page 3 Alterations or misuses of this system or failure to follow instructions may result in serious injury or death. If you have any questions on the use or care of this system please contact Liftsafe Fall Protection Inc. at 1-800-977-2005.
-
Page 4: Application
2.0 SYSTEM REQUIREMENTS 2.1 The RoofGuard Classic system is designed to be used on flat roofs (up to 5% grade) where the baseplate can sit flat on the roof surface. Depending on the roof surface, a rubber pad or ultra-light paving stone may be used under the baseplates to facilitate safe/stable contact with the roof surface, as freestanding systems rely on friction between the baseplates and the roofing materials. -
Page 5: Components
3.0 COMPONENTS 3.1 Baseplates are cast steel and hot dip galvanized for long-term outdoor use. These baseplates only weigh 40 lbs and are designed to stack together, making them easy to move and ship. Cone point stainless steel set screws secure the guardrail into the baseplates. Figure 1: Baseplate with set screws and assembly tool 3.2 Vertical posts are supplied with fittings and caps for a variety of configurations:... - Page 6 3.3 Horizontal rails are available in two standard sizes, 9-ft leading edge, and 6-foot return sections. For other sizes, the aluminum pipe is easily cut-to-fit on-site. The 6-ft sections of rail are used for the tie-backs to provide the counter weight for the system. This may also be used along the leading edge where a 9-ft section is too long.
-
Page 7: System Layout
4.0 SYSTEM LAYOUT 4.1 Install baseplates and rails on a flat, clean and dry surface. Clean the area where baseplates will be installed, to ensure good contact with the roof surface. 4.2 If curb or parapet is 4” or more above the top of the baseplate, then bases can be positioned against the parapet. -
Page 8: Installation
5.3 The RoofGuard baseplate has 3 holes, and for RoofGuard Classic, any of the 3 holes is acceptable. Use of the center hole is typical, but for tight areas, or for convenience, an outside hole may be useful. - Page 9 5.5 Use a 3/16” hex drive bit or Allen wrench (provided), and torque baseplate screws to 25ft-lbs. All set screws for stacked plates must be secured against the wall of the vertical posts. 5.6 Once torqued, the set screw can be ‘marked’ with the blue crayon (provided) to provide a visual indicator that the screw has been secured and warn of tam- pering.
- Page 10 IMAGES OF A COMPLETE CLASSIC ROOFGUARD SYSTEM Figure 10: Complete RoofGuard System Figure 11: Complete RoofGuard System Page 10...
-
Page 11: Add-On Toe-Board Kit
RoofGuard Classic Railing System, precautions must be taken to prevent tools/ materials from being able to fall (primarily construction applications). 6.1-B If the RoofGuard Classic system is placed near the parapet of a rooftop area, and the existing parapet wall is 152mm (6”) or higher, the toe-board kit may not be required- consult LFP to verify local requirements. - Page 12 & tape measure RoofGuard fitting tool (3/16” hex drive key or driver) 6.3-B The RoofGuard Classic Toe-Board Kit consists of the following items: RGF-155 – Toe-Board Bracket (w two SS ¼” bolts/nuts/washers) 5”x 1/8” Aluminum Toe-Board plate in 10-foot sections.
- Page 13 6.4 INSTALLATION 6.4-A With the RoofGuard baseplate as shown in Figure 1, slide the RGF-155 fitting down the post to almost touching the baseplate. (For existing systems the post may be temporarily removed from the baseplate and the fitting slid up from the bottom).
- Page 14 WARNING Warning – Do NOT lean on, or climb on guardrails. Guardrails MUST NOT be used as an anchor for fall restraint or fall arrest, and shall not be used for hoisting or tie-off. Attachment of banners / signs / equipment is not permitted. Excess force applied to the top rail could cause tipping, resulting in injury or death.
-
Page 15: Detailed Inspection And Maintenance Log
7.0 DETAILED INSPECTION AND MAINTENANCE LOG Inspection Inspection Items Noted Corrective Action Taken Maintenance Approved Date Performed... -
Page 16: Warranty
8.0 LIFTSAFE FALL PROTECTION WARRANTY Equipment offered by Liftsafe Fall Protection (LFP) is warranted against factory defects in workmanship and materials for a period of one year from date of installation or use by the owner, provided that this period shall not exceed 18 months from date of shipment. -
Page 17: Notes
9.0 NOTES Page 17... - Page 18 9.0 NOTES Page 18...
- Page 19 9.0 NOTES Page 19...
- Page 20 Liftsafe Fall Protection Inc. 409 Harmony Road Ayr, Ontario N0B 1E0 TF.: 1(800) 977-2005 (519) 896-2430 (519) 896-2085 E.: info@liftsafeinspections.com W.: www.fallsafetysolutions.com...
