Type 500X
441-622-015
Electro-Pneumatic Transducer (I/P, E/P)
Installation, Operation and
Maintenance Instructions
Type 500X
Contents
Section
Description
1.0
2.0
3.0
4.0
5.0
6.0
8 Columbia Drive, Amherst, New Hampshire 03031 USA
Phone: (603) 886-9400  Fax: (603) 889-1844
sales@controlair.com  www.controlair.com
Page 2
Page
2
3
4
6
6
6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 500X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for controlair 500X

Summary of Contents for controlair 500X

  • Page 1 Electro-Pneumatic Transducer (I/P, E/P) Type 500X Installation, Operation and Maintenance Instructions Contents Section Description Page Specifications Description & Installation Operation Maintenance Troubleshooting Warranty 8 Columbia Drive, Amherst, New Hampshire 03031 USA Phone: (603) 886-9400  Fax: (603) 889-1844 sales@controlair.com  www.controlair.com...
  • Page 2 Supply Pressure <± 0.1% of span per psig (<± 0.15% of span per 0.1 bar) <± 0.1% of span per psig, Sensitivity ± 2.0% max. Physical Specifications Housing NEMA 1 (standard); NEMA 4X (IP65) (optional) 441-622-015 Type 500X Page 2...
  • Page 3 2.2 Principle of Operation 2.2.1 The Type 500X is a force balance device in which a coil is suspended in the field of a magnet by a flexure. Current flowing through the coil generates axial movement of the coil and flexure. The flexure moves towards the nozzle and creates back pressure which acts as a pilot pressure to an integral booster relay.
  • Page 4 (4mA) to get maximum output then with maximum input (20mA) to get minimum output. Repeat as necessary. FM Approvals approved units must be ordered per specific model code. Figure 2 Electrical Schematic (E/P) Electrical Schematic (I/P) 441-622-015 Type 500X Page 4...
  • Page 5 3.2 Dimensional Drawings (Dimensions are in/mm) 3.3 Intrinsically Safe Operation 3.3.1 ControlAir LLC offers FM Approvals Intrinsically Safe/NEMA 4X Order input option ‘A’ 4-20 mA and option ‘H’. NOTES: 1. INSTALLATION TO BE IN ACCORDANCE WITH THE NATIONAL ELECTRIC CODE, NFPA 70, ARTICLE 504, AND ANSI/ISA RP 12.6.
  • Page 6 6. WARRANTY & DISCLAIMER ControlAir LLC products are warranted to be free from defects in materials and workmanship for a period of eighteen months from the date of sale, provided said products are used according to ControlAir LLC recommended usages.
