LINK-MI LM-YH02 Operating Instructions

Hdmi converter

HDMI Converter

MODEL:LM-YH02

Operating Instructions

Dear Customer

Thank you for purchasing this product. For optimum performance and safety, please

read these instructions carefully before connecting, operating or adjusting this product.

Please keep this manual for future reference.

FEATURES

• Transforms HD component video YPbPr and Audio R/L signal to HDMI output

• Hardware conversion, plug and play without any software drive

• Upscale composite up to 1080p

• Supports full range of Component Video Resolutions:480i, 480p, 576i, 576p, 720p,

1080i

• HDMI output resolution:720p/60Hz ,1080P/ 60Hz.

• Support PAL / NTSC standard

• Compliant HDCP .

• Uses 5V power

Table of Contents

Need help?

Do you have a question about the LM-YH02 and is the answer not in the manual?

Page 1 HDMI Converter MODEL:LM-YH02 Operating Instructions Dear Customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. FEATURES • Transforms HD component video YPbPr and Audio R/L signal to HDMI output •...
Page 2 NOTICE Our company reserve the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. TABLE OF CONTENTS Specifications Package Contents Panel Descriptions Connecting and Operating Maintenance Product service Warranty SPECIFICATIONS Operating Temperature -5 to +35℃(+23 to +95℉) Operating Humidity 5 to 90%RH (No Condensation) Range...
Page 3 2) DC5V 1A Power Supply. 3) Operating Instructions PANEL DESCRIPTIONS Input Panel Output Panel 1) Video input: YPbPr Video input 2) Audio input: Audio L/R input 3) Power input 4) HDMI output port 5) Indicator of power Input 6) 720p/1080p:Select 720p or 1080p output Connecting and Operating 1.
Page 4 Typical Application MAINTENANCE Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to clean this unit. PRODUCT SERVICE 1) Damage requiring service: The unit should be serviced by qualified service personnel if: (a)The DC power supply cord or AC adaptor has been damaged; (b)Objects or liquids have gotten into the unit;...
