NB2- Bookcase Assembly Instructions
Note: If you have two of the same cabinet each cabinet will have a different cabinet number.
Panel Stickers/Labels –Do not remove any cabinet stickers from the panels until the
units have been built, as these will assist with assembly. Most of the stickers are placed
on the "back" or underside of the cabinet and will not be seen once assembled.
NB2 Bookcase Cabinetry Panels
End Panel
Back Panel
Top & Bottom Panel
End Panel
Fixed Shelf
Kick Panel
1
