XOUT

Output X-10 powerline control codes to a PL513 or TW523 powerline
interface module.
usage: XOUT mpin,zpin,[house\keyorcommand{\cycles,...]
Mpin will be made a low output and is the modulation control.
Zpin will be made an input and is the zero-crossing detect.
House is the house code (0-15 is 'A'-'P').
Keyorcommand is a key (0-15 is '1'-'16') or command (see table below).
Cycles is an optional number which overrides the default of two; this
should only be used with 'dim' and 'bright' commands.
X-10 Command (symbol)
UNITON
UNITOFF
UNITSOFF
LIGHTSON
DIM
BRIGHT
The following chart gives the wiring connections for connecting the
Stamp II to a PL513 or TW523 powerline interface module.
Powerline Interface Pin
1
2
3
4
Application note #1 gives a good description of the X-10 system, as
well as how to use it with the Stamp II.
Page 68 • BASIC Stamp II Manual 0.94 • Parallax, Inc. • (916) 624-8333
BASIC Stamp II
Value
%10010
%11010
%11100
%10100
%11110
%10110
Stamp II Pin
Zpin
GND
GND
Mpin
