ANALOX 1371 MK2 Instruction Manual

Surveyor carbon dioxide monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR
Analox Sensor Techn
15 Ellerbeck Court
Stokesley Business Park
STOKESLEY.
Cleveland
TS9 5PT
Telephone
: +44 (0)1642 711400
Fax
: +44 (0)1642 713900
1371-810-03 User Manual, August 2007
ANALOX 1371 MK2 SURVEYOR
CARBON DIOXIDE MONITOR
INSTRUCTION MANUAL
117

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1371 MK2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ANALOX 1371 MK2

Summary of Contents for ANALOX 1371 MK2

  • Page 1 ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR ANALOX 1371 MK2 SURVEYOR CARBON DIOXIDE MONITOR INSTRUCTION MANUAL Analox Sensor Techn 15 Ellerbeck Court Stokesley Business Park STOKESLEY. Cleveland TS9 5PT Telephone : +44 (0)1642 711400 : +44 (0)1642 713900 1371-810-03 User Manual, August 2007...

  • Page 2: Table Of Contents

    ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR LIST OF CONTENTS Section Page Number INTRODUCTION ........................5 SPECIFICATIONS........................6 GENERAL........................6 OPERATIONAL....................... 6 OUTPUTS ........................7 MECHANICAL........................ 7 INSTALLATION AND COMMISSIONING................8 INSTALLATION......................8 CONNECTIONS ......................9 COMMISSIONING ......................9 OPERATION..........................
  • Page 3 ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR IMPORTANT NOTES Any adjustments or repairs to the ANALOX 1300 range of instruments should only be carried out by a competent electronic engineer, familiar with Instrument technology. S.A.E.P. Ltd. WILL NOT ACCEPT RESPONSIBILITY FOR ANY EVENTS OCCURRING AS A RESULT OF UNAUTHORISED ADJUSTMENTS OR REPAIRS TO THE INSTRUMENTS.
  • Page 4 ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR 1371-810-03 User Manual, August 2007...

  • Page 5: Introduction

    ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR INTRODUCTION The ANALOX 1371 SURVEYOR provides a clear Digital Display of Carbon Dioxide concentration in a gas sample. It can be employed either as an ambient monitor, using its internal pump to draw the sample, or as an 'On-Line' monitor if the gas to be checked is flowing through a pipe.

  • Page 6: Specifications

    ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR SPECIFICATIONS GENERAL Ranges Available : 0 to 0.5%,1%, 2%, 5%, 10%, 20%, 100% CO Linearity : 1% FS Repeatability : 1% FS Resolution : ± 1 Digit on Display Zero Drift : 2% FSD / week max...

  • Page 7: Outputs

    ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR : c) 12V DC Power Consumption : 18 VA Maximum OUTPUTS Relays : Low Flow Alarm : SPCO Contacts NO NC COM (HI Alarm) : SPCO Contacts NO NC COM (LO Alarm)

  • Page 8: Installation And Commissioning

    ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR INSTALLATION AND COMMISSIONING INSTALLATION 3.1.1 The 1371 Surveyor should be mounted on a vertical surface using 3 off M4 machine screws or No. 8 woodscrews. Make sure that the chosen mounting position allows sufficient room on the Left of the Instrument, to permit the hinged front cover to be fully opened, and below the unit to allow cables and pipework to be correctly fitted.

  • Page 9: Connections

    ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR Figure 1. Fixing Centres. CONNECTIONS 3.2.1 Connections to remote equipment, eg Flashing beacons or High powered Sounders and data recording devices are made through two cable glands, to the screw terminals in the middle area of the terminal compartment.

  • Page 10: Operation

    ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR OPERATION ALARM SETPOINTS 4.1.1 The Instrument incorporates two completely independent alarm circuits, which may be adjusted by the user, to any point within the full range of the instrument. Both alarm circuits are configured to operate when the measured gas concentration Exceeds the setpoint - ie they are High going alarms.

  • Page 11: Calibration

    ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR CALIBRATION GENERAL COMMENTS Calibration requires gases to be fed from cylinders of certified concentration. These gases MUST NOT be delivered directly at cylinder pressure to the Instrument, otherwise the internal pump will be damaged. Scottish Anglo E.P. Ltd. supply calibration kits for the 1371 Instrument, comprising two cylinders of gas, a cylinder mounted flowmeter with control valve and suitable tubing.
  • Page 12 ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR 5.2.4 It is important to realise that the Analyser in this Instrument responds to the partial pressure of Carbon Dioxide in the gas sample and that the calibration is strictly valid only at the temperature and pressure at which the calibration was done.

  • Page 13: Maintenance

    ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR MAINTENANCE GENERAL Routine maintenance should be carried out at six monthly intervals to ensure continued reliable operation. The procedure detailed below should be followed and should not take more than about 20 minutes. It is strongly recommended that the procedures be carried out by a technician or engineer, familiar with Electronic Instrumentation.

  • Page 14: Principle Of Operation

    The family of Transducers used in the ANALOX 1371 MK 2 range of Instruments are based on a measurement and reference sensor principle, utilising sample path lengths of between 1mm and 100mm in length, depending on the concentration to be measured, and wavelength selection by a carefully specified narrow band interference filter.

  • Page 15: Warranty & Repair

    ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR WARRANTY & REPAIR WARRANTY We provide the following Warranties for the Analox 1371: A 1 year sensor warranty. A 1 year electronics warranty. In both cases the Warranty period runs from the date of our Invoice.

  • Page 16: Repair

    ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR We reserve the right to require from you proof of dispatch to us of the notification of Warranty claim by any of the above alternative means. The equipment should not be sent to us without our prior written authority.

  • Page 17: Transducer Replacement

    ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR TRANSDUCER REPLACEMENT The Infra-Red Transducer (CO Sensor) is constructed as a complete Module which permits rapid, relatively straightforward, field replacement, in the unlikely event of the Transducer requiring service. It is strongly recommended that this operation is only carried out by personnel who have attended a relevant training course at Scottish Anglo, or Qualified Electronics Engineer, with guidance from Scottish Anglo E.P.

  • Page 18: Fault Finding

    ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR FAULT FINDING The list below is intended to assist in tracing elementary faults, which can probably be corrected by the user or a Technician. It is not an exhaustive list of all possible conditions. If any difficulty is experienced, contact either the agent who supplied the Instrument or Scottish Anglo E.P.

  • Page 19: Spares

    ANALOX 1371 MK 2 SURVEYOR CARBON DIOXIDE MONITOR SPARES 10.1 CALIBRATION KITS Instrument Range Kit Part Number 0.5% FS SA7 D03 0P5 1.0% FS SA7 D03 1P0 2.0% FS SA7 D03 2P0 5.0% FS SA7 D03 5P0 10% FS SA7 D03 10P...
