Chapter 1 S3740F Introduction

The section describes the characteristics and parameters of
overview of S3740F .

1.1 Appearance Description for Standard Configuration

The built-in ports of
ports, 8 10G Ethernet SFP+ ports, 1 Console port. See table 1-1.
built-in port
Gigabit Ethernet TX port
Gigabit Ethernet optical port
10G Ethernet optical port
Console port
Table 1-2 Parts at the front template of the S3740F switch
No. Abbrev.
1 PWR
2 SYS
S3740F Hardware Installation Manual
are: 8 gigabit Ethernet TX ports, 24 Gigabit Ethernet optical
S3740F
Port
Figure 1-1 Front template of the S3740F switch
Name
Power indicator
System indicator
Attribute
RJ45 interface, LINK/ACT indicator
SFP interface, LINK/ACT indicator
SFP+ interface, LINK/ACT indicator
A rate of 9600bps, mini USB interface
If the switch is powered on, the
indicator is on.
If the indicator is always on, the
system is normally started up.
If the indicator flickers, the system
works normally.
and gives an
S3740F
Table 1-1 Attributes of the
Description
- 1 -
