Hakko Electronics FX-888D Instruction Manual

FX-888D-17BY

Packing List:

(Standard Unit)
FX-888D Station with British Power Cord +
Instruction Manual
FX8801 Soldering Iron with T18-B Standard
Soldering Tip
FH800 Iron Stand
A1559 Cleaning Sponge
A1561 Cleaning Wire

Specifications:

Model No.
FX-888D
Power consumption 70W
Temperature range 50 to 480ºC
Temperature stability ±1ºC at idle temperature (When set
to 200 to 480ºC)
FX-888D Soldering Station
Output voltage AC 26V
Dimensions 100(W)×120(H)×120(D)mm
Weight 1.2kg

Tips:

The FX8801 supplied with the FX-888D soldering station requires the T18 Series Tips which are available in a variety of shapes and sizes.
Note: A Standard tip is included with this soldering station. Alternate tips may be purchased separately.
Shape BC / C
H K Wentworth Ltd, Ashby Park, Coalfield Way, Ashby de la Zouch, Leicestershire, LE65 1JR, T +44 (0)1530 448950 W hakko.co.uk
(UK Voltage)
FX8801 Soldering Iron
Power consumption
Tip to ground resistance
Tip to ground potential
Heating element
Standard tip
Cord length
Total length
Weight
* Total length and weight (w/o cord)
65W (26V)
<2Ω
<2mV
Ceramic heater
Shape-B (No.T18-B)
1.2m
217mm (with B tip)
46g (with B tip)
